Rush Pin 1 CW Manuel utilisateur
Pin 1 CW
User Manual
Professional Entertainment Technology
© 2013 Martin Professional A/S. Information subject to change without notice. Martin
Professional A/S and all affiliated companies disclaim liability for any injury, damage, direct
or indirect loss, consequential or economic loss or any other loss occasioned by the use of,
inability to use or reliance on the information contained in this manual. The Martin logo, the
RUSH by Martin logo, the RUSH by Martin name, the Martin name and all other
trademarks in this document pertaining to services or products by Martin Professional A/S
or its affiliates and subsidiaries are trademarks owned or licensed by Martin Professional
A/S or its affiliates or subsidiaries.
Manual: Revision B
RUSH Pin 1 CW user manual 3
Table of contents
Safety information............................................................................................. 4
Introduction ....................................................................................................... 7
Fixture overview................................................................................................ 7
Before using the product for the first time......................................................... 7
Physical installation .......................................................................................... 8
Fastening the fixture to a flat surface............................................................ 8
Mounting the fixture on a truss...................................................................... 8
AC power .......................................................................................................... 9
Maintenance ................................................................................................... 10
Cleaning ...................................................................................................... 10
Service and repairs ..................................................................................... 11
Troubleshooting .............................................................................................. 11
Specifications.................................................................................................. 12
RUSH Pin 1 CW user manual
4
Safety information
WARNING!
Read the safety precautions in this manual before installing,
powering, operating or servicing this product.
The following symbols are used to identify important safety information on the
product and in this manual:
Warning!
Safety hazard.
Risk of severe
injury or death.
Warning!
LED light
emission. Risk of
eye injury.
Warning!
Refer to manual
before installing,
powering or
servicing.
Warning!
Hazardous
voltage. Risk of
lethal or severe
electric shock.
Avoid looking directly into the LED light source beam and do not
view the light output with optical instruments or any device that
may concentrate the beam.
This product is for professional use only. It is not for household
use. It presents risks of severe injury or death due to fire
hazards, electric shock and falls.
Read this manual before installing, powering or servicing the
fixture, follow the safety precautions listed below and observe all
warnings in this manual and printed on the fixture. Keep this
manual for future use. If you have questions about how to
operate the fixture safely, please contact your RUSH by Martin™
dealer or call the Martin™ 24-hour service hotline on +45 8740
0000, or in the USA on 1-888-tech-180.
Protection from electric shock
Disconnect the fixture from AC power before carrying out any
installation or maintenance work and when not in use.
Ground (earth) the fixture electrically.
Use only a source of AC power that complies with local building
and electrical codes and has both overload and ground-fault
(earth-fault) protection.
RUSH Pin 1 CW user manual 5
Before using the fixture, check that all power distribution
equipment and cables are in perfect condition and rated for the
current requirements of all connected devices.
Isolate the fixture from power immediately if the power plug or
any seal, cover, cable, or other component is damaged,
defective, deformed, wet or showing signs of overheating. Do
not reapply power until repairs have been completed
Do not expose the fixture to rain or moisture.
Protection from burns and fire
Do not operate the fixture if the ambient temperature (Ta)
exceeds 40° C (104° F).
The surface of the product casing can get hot—up to 60° C
(140° F)—during operation. Avoid contact by persons and
materials. Keep flammable materials well away from the fixture.
Ensure that there is free and unobstructed airflow around the
fixture. Provide a minimum clearance of 100 mm (4 in.).
Do not illuminate surfaces within 200 mm (7.9 ins.) of the fixture.
Do not attempt to bypass thermostatic switches or fuses.
Do not stick filters, masks or other materials onto any optical
component.
Protection from eye injury
Do not look continuously at LEDs from a distance of less than
8.3 meters (27 ft. 3 inches) from the front surface of the fixture
without protective eyewear such as shade 4-5 welding goggles.
At less than this distance, the LED emission can cause eye
injury or irritation. At distances of 8.3 meters (27 ft. 3 inches) and
above, light output is harmless to the naked eye provided that
the eye’s natural aversion response is not overcome.
Do not look at LEDs with magnifiers, telescopes, binoculars or
similar optical instruments that may concentrate the light output.
To minimize the risk of eye irritation or injury, disconnect the
fixture from power at all times when the fixture is not in use, and
provide well-lit conditions to reduce the pupil diameter of anyone
working on or near the fixture.
RUSH Pin 1 CW user manual
6
Fasten the fixture securely to a fixed surface or structure when
in use. The fixture is not portable when installed.
Ensure that any supporting structure and/or hardware used can
hold at least 10 times the weight of all the devices they support.
If suspending from a rigging structure, fasten the fixture to a
rigging clamp. Do not use safety cables as the primary means of
support.
If the fixture is installed in a location where it may cause injury or
damage if it falls, install a secondary attachment such as a
safety cable that is approved by an official body such as TÜV as
a safety attachment for the weight that it secures. The safety
cable must comply with EN 60598-2-17 Section 17.6.6 and be
capable of bearing a static suspended load that is ten times the
weight of the fixture and all installed accessories.
Check that all external covers and rigging hardware are securely
fastened.
Block access below the work area and work from a stable
platform whenever installing, servicing or moving the fixture.
Do not operate the fixture with missing or damaged covers,
shields or any optical component.
In the event of an operating problem, stop using the fixture
immediately and disconnect it from power. Never attempt to use
a fixture that is obviously damaged.
Do not modify the fixture or install other than genuine RUSH by
Martin™ parts.
Refer any service operation not described in this manual to a
qualified technician.
RUSH Pin 1 CW user manual 7
Introduction
The Pin 1 CW is a small, powerful pinspot incorporating a single 10 W long-life
LED. It provides two focusable beam angles—7° and 11°—and is ideal for
projecting onto mirror balls or other applications for mobile DJ’s or small fixed
installations.
Fixture overview
1. Power inlet
2. Heat sink (do not cover)
3. Safety cable attachment point
4. Focus ring
Before using the product for the first time
1. Read Safety information on page 4 before installing, powering, operating
or servicing the fixture.
2. Unpack and ensure that there is no transportation damage before using
the fixture. Never attempt to operate a damaged fixture.
3. Install a local power plug (not supplied) on the power cable.
4. Before operating, ensure that the voltage and frequency of the power
supply match the power requirements of the fixture.
5. Check the Martin Professional website at www.martin.com for the most
recent user documentation and technical information about the fixture.
RUSH by Martin™ user manual revisions are identified by the revision
letter at the bottom of the inside cover.
RUSH Pin 1 CW user manual
8
Physical installation
The fixture is designed for indoor use only and must be used in a dry location
with adequate ventilation. Always ensure that the fixture’s heat sink is not
covered and always ensure that the product is firmly affixed.
The fixture should be mounted via its screw holes on the bracket.
Fastening the fixture to a flat surface
The fixture can be fastened to a hard fixed flat surface that is oriented at any
angle. Ensure that the surface can support at least 10 times the weight of all
fixtures and equipment to be installed on it.
Fasten the fixture securely. Do not stand it on a surface or leave it where it can
be moved or fall over. Attach a securely anchored safety cable to the fixture if it
is installed in any location where it may fall and cause injury or damage if the
primary attachment fails.
Mounting the fixture on a truss
The fixture can be clamped to a truss or similar rigging structure in any
orientation. When clamping a fixture to a truss:
1. Check that the rigging structure can support at least 10 times the weight of
all fixtures and equipment to be installed on it.
2. Block access under the work area.
3. Rig the fixture using clamps and hardware suitable for the purpose.
Working from a stable platform, hang the fixture on the truss. Tighten the
rigging clamps and hardware.
4. Secure the fixture against clamp failure with a secondary attachment such
as an approved safety cable that is rated for the weight of the fixture.
RUSH Pin 1 CW user manual 9
AC power
Read Safety information on page 4 before connecting the fixture
to AC mains power.
For protection from electric shock, the fixture must be grounded
(earthed). The power distribution circuit must be equipped with a
fuse or circuit breaker and ground-fault (earth-fault) protection.
Socket outlets or external power switches used to supply the
fixture with power must be located near the fixture and easily
accessible so that the fixtures can easily be disconnected from
power.
Do not insert or remove live connectors to apply or cut power, as
this may cause arcing at the terminals that will damage the
connectors.
Do not use an external dimming system to supply power to the
fixture, as this may cause damage to the fixture that is not
covered by the product warranty.
The fixture can be hard-wired to a building electrical installation if you want to
install it permanently, or a power plug (not supplied) that is suitable for the
local power outlets can be installed on the power cable.
The fixture has an auto-ranging power supply that accepts AC mains power at
100 – 240 V, 50/60 Hz. Do not apply AC mains power that is not within this
range.
RUSH Pin 1 CW user manual
10
Maintenance
Read Safety information on page 4 before servicing the fixture.
.
Refer any service operation not described in this user manual to
a qualified service technician.
Disconnect mains power before cleaning or servicing the fixture.
Fixtures must be serviced in an area where there is no risk of
personal injury from falling parts, tools or other materials.
Excessive dust, smoke fluid, and particle buildup degrades performance, can
cause overheating and can damage the fixture. Damage caused by
inadequate cleaning or maintenance is not covered by the product warranty.
Cleaning
The cleaning of external optical lenses must be carried out periodically to
optimize light output. Cleaning schedules for lighting fixtures vary greatly
depending on the operating environment. It is therefore impossible to specify
precise cleaning intervals for the fixture. Environmental factors that may result
in a need for frequent cleaning include:
•Use of smoke or fog machines.
•High airflow rates (near air conditioning vents, for example).
•Presence of cigarette smoke.
•Airborne dust (from stage effects, building structures and fittings or the
natural environment at outdoor events, for example).
If one or more of these factors is present, inspect fixtures within their first 100
hours of operation to see whether cleaning is necessary. Check again at
frequent intervals. This procedure will allow you to assess cleaning
requirements in your particular situation. If in doubt, consult your RUSH by
Martin™ dealer about a suitable maintenance schedule.
Use gentle pressure only when cleaning, and work in a clean, well-lit area. Do
not use any product that contains solvents or abrasives, as these can cause
surface damage.
Autres manuels pour Pin 1 CW
1
Table des matières
Manuels Mettre en lumière populaires d'autres marques
Guangzhou Yinhe Lighting&Sound Equipment Factory
Guangzhou Yinhe Lighting&Sound Equipment Factory NE-204 Manuel utilisateur
LIVARNO home
LIVARNO home 375304 2101 Instructions originales
Cameo
Cameo CLQS40WW Manuel utilisateur
Leviton
Leviton Ellipsoid 5/50 Manuel utilisateur
Monacor
Monacor img Stage Line PARL-56PDX/CR Manuel utilisateur
Vector
Vector SL3AKV Manuel utilisateur
EuroLite
EuroLite Akku flat light 1 Manuel utilisateur
Commercial Electric
Commercial Electric SPTM-1401 Manuel utilisateur
Vision & Control
Vision & Control SLB-500-W5K7-P-SL Manuel utilisateur
Teknik
Teknik FLEXI Manuel utilisateur
Craftsman
Craftsman CMXLSB10 Manuel utilisateur
EuroLite
EuroLite LED SLS-144 UV Floor Spot Manuel utilisateur
