For more information visit www.Runco.com or call 800-237-8626 or +1-503-748-1100.

Runco® CrystalSeries™

cx-70dhd lcd

Native Resolution: 1920 x 1080

Screen Size: 70.3 in. (diagonal)

Screen Aspect Ratio: 4:3, Letterbox, 16:9 Anamorphic, VirtualWide™

Available Aspect Ratios: See DHD Controller Specs below

Image Area (W x H inches): 61.56” W x 34.86”H

DTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Contrast Ratio: 1500:1

ISF Settings: Yes

Data/Graphics Compatibility: Up to 1366 x 768

Inputs (from DHD Controller): (1) RGB/Component (15-pin D-sub); (1) DVI with HDCP

(1) RS-232 (9-pin D-sub female)

Power Requirements: 100-240V AC, 50/60Hz

Power Consumption: 720 W (1.5 watts in standby), maximum

Operating Environment: 40 to 95ºF (5 to 35ºC); 20-80% humidity (non-condensing)

Dimensions (without stand): Width: 66.6 in. (1691 mm)

Height: 39.8 in. (1011 mm)

Depth: 5.84 in. (148 mm)

Weight: 158 lbs. (71.66kg)

Limited Warranty: (2) Two years parts and labor from the date of shipment from Runco.

RuncoCare™ and Runco RedCarpet™ plans are also available.

CX-70DHD Ships with: Power Cord (US only, 15ft.), remote control unit with (2) AAA batteries,

(1) one 20 foot RJ-11 to RJ-45 serial cable, (1) DVI (male) to HDMI

(Female) adapter, rack-mount hardware for DHD Controller, Manual,

Quick Start guide, (4) Four cable ties.

Runco proudly unveils its largest LCD at panel, the

Crystal Portfolio™ CX-70DHD. The Runco CX-70DHD

is a native 1080p HD LCD that is ideal for rooms of

distinction where a large screen size is desired, but where

ambient light makes front projection difcult and the glare

of a plasma screen simply unacceptable. Beyond its

exceptional contrast, the CX-70DHD features ISF™

calibration for an optimal picture in the most challenging

lighting conditions and the display’s elegant black bezel

matches any room décor.

For more information visit www.Runco.com or call 800-237-8626 or +1-503-748-1100.

Runco® CrystalSeries™

cx-70dhd lcd

Runco DHD 3 Controller Specications:

Aspect Ratios: 4:3, 16:9, Anamorphic, Letterbox, VirtualWide™, Cinema, Virtual

Cinema™, Native

Video Standards: NTSC, PAL, SECAM, ATSC

Inputs: (1) Composite; (2) S-Video; (1) HD Video/Computer, R (Pr), G (Y), B

(Pb), H, V – RCA connectors; (2) HD Video/Computer, R (Pr), G (Y), B

(Pb), H, V, – BNC’s; (1) HD Video/Computer – 15-pin D-Sub

connector; (2) HDMI with HDCP

Output Resolution: 1080p

Output: (1) HDMI, (1) RS-232

Communication Control Ports: Discrete infrared remote Serial commands via RS-232

Front-panel controls

Screen Trigger/Masking Outputs: (3) +12 VDC, each rated at 250 mA with overcurrent protection

Bandwidth: 170 Mega Samples per Second (MSPS)

Power Requirements: 100 – 240V AC (auto-sensing), 50/60 Hz, 40 watts

Operating Environment: 41°F – 104°F (5°C – 40°C), 0% – 85% Humidity (non-condensing)

Dimensions: Width = 17.50 inches (444.5 mm)

Depth = 11.19 inches (284.1 mm)

Height = 3.75 inches (95.3 mm)

Weight: 15.5 lbs. (7.0 kg)

Included Accessories: Rack mounting brackets

Regulatory Approvals: Complies with FCC, CE C-Tick

Limited Warranty: Projector: (2) Two years parts and labor from the date of shipment

from Runco. RuncoCare™ and Runco RedCarpet™ plans are

also available

Runco proudly unveils its largest LCD at panel, the

Crystal Portfolio™ CX-70DHD. The Runco CX-70DHD

is a native 1080p HD LCD that is ideal for rooms of

distinction where a large screen size is desired, but where

ambient light makes front projection difcult and the glare

of a plasma screen simply unacceptable. Beyond its

exceptional contrast, the CX-70DHD features ISF™

calibration for an optimal picture in the most challenging

lighting conditions and the display’s elegant black bezel

matches any room décor.
