Important Notices / Installation
B. IMPORTANT NOTICES
WARNING
WARNING. Read and adhere to the following
installation instructions. FAILURE TO DO SO MAY
RESULT IN SEVERE OR FATAL INJURY AND/OR
POSSIBLE VOIDING OF THE WARRANTY.
1. Read and follow the instructions in this manual.
2. Fans are to be installed and serviced only by qualied
personnel experienced in electrical and HVAC work.
3. Installation and wiring of the fan must adhere to all
applicable codes.
4. It is essential that any fan, that will be used in a hazardous
(classied) location, is equipped with an electric motor
approved for such service.
5. Do not operate fan in atmospheres which are corrosive to
steel or aluminum, unless it has been coated with a factory
approved protective coating.
6. Fan must be kept clean. When operating in a dirty
environment, regularly clean fan and fan guard. Follow
the recommended maintenance procedures. Refer to
SectionA. Fan Maintenance Checklist, page3 for
details.
7. Use factory approved replacement parts only.
8. If there are any questions or concerns regarding the fan,
contact the factory. Refer to the last page of this manual
for details.
9. Heater is to be used only in atmospheres having an
ignition temperature higher than the heater’s maximum
rated operating temperature as shown on the heater data
plate. Refer to applicable electrical codes for additional
information.
10. Installer to provide certied Ex “d” sealed ttings and
stopping boxes for the same gas groups as the apparatus.
C. INSTALLATION
The installation instructions provide a general guideline for the
installation and wiring of the exhaust fan. All applicable codes must
be adhered to.
C.1 Location
1. For optimum air exhaust, the fan(s) should be installed as
follows:
1.1 There are no obstructions that may impede the fans
air inlet or discharge.
1.2 The air discharge is directed away from building.
1.3 The air discharge is not directed at a thermostat.
1.4 For warehouses or large workshops it may be
acceptable to use fewer, larger fans.
2. This unit can exhaust warm or cool air depending on customer
conditions. Be aware of problems each can produce.
3. For installation within a Hazardous Location, cable
entries and conduit should be suitable for operations in
hazardous locations and rated IP 54.
C.2 Mounting
1. The Exhaust Fan is designed to be installed in an upright
and level position.
2. Fan(s) are designed to be mounted from the rear using four
3/8" holes. For fan dimensions, see Figure 1, page5.
3. The mounting structure must be strong enough to:
3.1 Support the fans weight (refer to Section E. General
Specications, page7).
3.2 Provide sufcient stiffness to prevent excessive
vibration.
3.3 Withstand abusive situations such as transportable
installations.
3.4 If Exhaust Fan is installed on a wall thinner than 4",
customer will need to install shims to bring face of
fan away from mounting surface.
4. Mounting Clearances
4.1 Leave at least 20" (500mm) clearance between the
rear of the motor and the nearest obstruction.
4.2 Clearance equal to the height of the fan shroud
above, or beneath is required for easy fan or motor
replacement.
C.3 Temperature Control
If required, the fan output may be thermostatically controlled by a
remotely mounted thermostat.
C.4 Final Inspection
1. Before application of electrical power:
1.1 Check that all connections are secured and comply
with the applicable wiring diagram and code
requirements.
1.2 Conrm the power supply is compatible with the
data plate rotating on motor.
1.3 Remove any foreign objects from fan.
1.4 Ensure all electrical covers are well secured.
1.5 Ensure the fan rotates freely counterclockwise when
viewed from the rear of the fan and air exits through
the dampers.
