R2 mk4 Smart Tabletop Radio
R2 mk4 Smart Tabletop Radio
User guide
DA Brugervejledning - DE Bedienungsanleitung - ES Guía del usuario - FR Manuel de l’utilisateur
IT Guida utente - - NL Gebruikershandleiding
NO Brukerveiledning - PL Poradnik użytkownika - RU Руководство пользователя - 用户指南
EN
DA
DE
ES
FR
IT
JA
KO
NL
NO
PL
ZH
XX
Important information
about the AC power adapter
Model DYS830-140200W-K
Input 100-240V~50/60Hz 0.8A MAX
Output 14.0V 2.00A
Class II, Eciency Level VI
•This AC adapter is for audio & video equipment use
only and complies with IEC 62368 safety standard.
•The supplied 3-pin plug adapter complies with
BS 1363-1 and the supplied 2-pin plug adapter
complies with EN 50075.
•Before using the AC adapter, ensure the mains
voltage is within the rated supply voltage range.
•The output power taken from this AC adapter must
not exceed its rated output power.
•DO NOT disassemble or modify the AC adapter.
•DO NOT drop or throw the AC adapter.
•The external exible cable cannot be replaced and
if the cord is damaged, the AC adapter must be
replaced.
•DO NOT expose the AC adapter to dripping or
splashing water, and do not place objects lled with
liquids, such as vases, on or near the device.
•DO NOT leave the AC adapter in a hot location, such
as near re or under strong sunlight.
•DO NOT cover ventilation openings on the device.
•Unplug the AC adapter during lightning storms or
when unused for long periods of time to prevent
damage.
•Ensure that the AC adapter is readily accessible when
plugged into the mains. If an abnormal condition
occurs while using it, immediately turn off the
connected device and disconnect the mains adapter
from the mains.
•DO NOT dispose this AC adapter as general
household waste or unsorted municipal waste,
dispose of it according to local regulations.
1
2
3
4
5
4
EN
1. Controls
2. OLED display
3. Ambient light sensor
4. 75mm NS+ driver
5. Ambientlightsensor
DA
1. Kontroller
2. OLED-skærm
3. Lysdetektor
4. 75mm NS+ højttaler
5. Lysdetektor
DE
1. Kontrollen
2. OLED-Anzeige
3. Lichtdetektor
4. 75mm NS+ Lautsprecher
5. Lichtdetektor
ES
1. Controles
2. Pantalla OLED
3. Detector de luz
4. Altavoz NS+ de 75mm
5. Detectordeluz
FR
1. Contrôles
2. Écran OLED
3. Détecteur de lumière
4. Haut-parleur NS+ 75mm
5. Détecteur de lumière
IT
1. Controlli
2. Display OLED
3. Rilevatore di luce
4. Altoparlante NS+ da 75mm
5. Rilevatore di luce
JA
1. コ ント ロ ー ル
2. OLEDディスプレイ
3. 光検出器
4. 75mmNS+スピーカー
5. 光検出器
KO
NL
1. Besturing
2. OLED-scherm
3. Licht detector
4. 75mm NS+ luidspreker
5. Licht detector
NO
1. Kontroller
2. OLED-skjerm
3. Lysdetektor
4. 75mm NS+ høyttaler
5. Lysdetektor
PL
1. Sterownik
2. Wyświetlacz OLED
3. Detektor światła
4. Głośnik 75 mm NS+
5. Detektor światła
ZH
1. 控制项
2. OLED显示器
3. 光探测器
4. 75毫米NS+扬声器
5. 光探测器
EN
DA
DE
ES
FR
IT
JA
KO
NL
NO
PL
ZH
XX
7
9
10
8
6
11
EN
1. DAB-FMantenna
2. USBC
3. DCinput
4. Lineinput
5. Headphoneoutput
6. Securityslot
DA
7. Optiskindgang
8. DAB-FM-antenne
9. USBC
10. DC-indgang
11. Linjeindgang
12. Linje/Subudgang
13. Hovedtelefonudgang
DE
7. OptischerEingang
8. DAB-FM-Antenne
9. USBC
10. Gleichstromeingang
11. Audio-Eingang
12. Audio-Ausgang/Sub
13. Kopfhörerausgang
ES
7. Entradaóptica
8. AntenaDAB-FM
9. USBC
10. EntradadeCC
11. Entradadelínea
12. Salidadelínea/sub
13. Tomadeauriculares
FR
7. Entréeoptique
8. AntenneDAB-FM
9. USBC
10. EntréeCC
11. Prisedeligne
12. Sortiedeligne/Sub
13. Sortiecasque
IT
7. Ingressoottico
8. AntennaDAB-FM
9. USBC
10. IngressoCC
11. Ingressodilinea
12. Uscitadilinea/sub
13. Presapercue
JA
7. 光入力
8. DAB-FMアンテナ
9. USBC
10. DC入力
11. ライン入力
12. ライン出力/サブ出力
13. ヘ ッド フォ ンソ ケット
KO
NL
7. Optischeingang
8. DAB-FM-antenne
9. USBC
10. DC-ingang
11. Lijningang
12. Lijn/subuitgang
13. Koptelefoonuitgang
NO
7. Optiskinngang
8. DAB-FM-antenne
9. USBC
10. DC-inngang
11. Linjeinngang
12. Linje/subutgang
13. Hodetelefonutgang
PL
7. Wejście optyczne
8. Antena DAB-FM
9. USB C
10. Wejście DC
11. Wejście liniowe
12. Wyjście liniowe/sub
13. Wyjście słuchawkowe
ZH
7. 光纤输入
8. DAB-FM天线
9. USBC
10. 直流输入
11. 线路输入
12. 线路输出/重低音輸出
13. 耳机输出
1 2
3 4
100-240V AC
50/60Hz
14V DC
2A
EN
DA
DE
ES
FR
IT
JA
KO
NL
NO
PL
ZH
XX
5 6
Setup wizard
Follow the setup wizard to congure your R2.
Rotate the CONTROL KNOB until your preferred choice
is shown, then press the CONTROL KNOB to SELECT.
Need more help?
For more information, see
www.ruarkaudio.com/support
App control
You can also control your R2 using the companion app
UNDOK. Find it on the Apple/Android app store.
For more information visit www.ruarkaudio.com/app
Controls
1. – STANDBY
2. CONTROL KNOB / SELECT
Rotate to adjust volume from a Now Playing screen.
Rotate to browse menus or station lists.
Press to SELECT.
Press to SNOOZE a sounding alarm. Press it again to
increase the snooze time or press and hold to cancel.
3. – press to skip to next DAB station, track, or seek
next FM station. In standby, press to increase display
brightness.
4. – press to skip to previous DAB station, track, or
seek next FM station. In standby, press to decrease
display brightness.
5. PRESET – press to recall a saved station or playlist, press
and hold for two seconds to save a currently playing
station or playlist.
6. SOURCE – press to change audio source.
7. – press to play/pause a track or mute audio.
8. MENU – press to view the options menu, press to go
back to previous screen when already in a menu.
9. ALARM– press to set an alarm or sleep. Press and hold
to quick-access sleep timer.
10.LED – indicates radio is on and ashes when Bluetooth
is ready to connect or pair.
8
1
10 2
3
6
7
5
4
9
Tips
You can also press or to browse menus,
sources or station lists.
Currently saved settings are highlighted with an
asterisk, eg “Radio text * ”.
Press = tap or press and immediately release.
Press and hold = press and release after two seconds.
EN
DA
DE
ES
FR
IT
JA
KO
NL
NO
PL
ZH
XX
Specications
Ampliers and drivers
2 × 75mm Ruark NS+ drivers
18W Class AB power amplier
3D audio processor
Tuner
DAB, DAB+ and FM Tuner with RDS
75Ohm F-type DAB/FM connector with telescopic aerial
Digital and streaming audio
Internet radio, Spotify Connect, Deezer, Amazon Music
Wi-Fi 802.11b/g/n WEP, WPA, WPA2
USB MP3 48kHz 320kbps
Bluetooth V5.2, SBC, A2DP
Inputs and outputs
Line input (RCA) 2.3Vrms
USB 2.0, FAT32, 5W (5V 1A)
3.5mm headphone jack, 25mW into 16-32Ohm
Power
AC mains adapter input: 100-240V AC 50/60Hz 0.8A
AC mains adapter output: 14V DC 2.00A
Nominal 4W
Standby 1.7W (with USB disconnected)
Physical
H175 x W340 x D135mm (H6.9 x W13.4 x D5.3in)
2.9kg (6.4lbs)
Specications subject to change without notice.
Troubleshooting
For help with your product, please refer to the FAQ
(Frequently Asked Questions) page in the support
area of our website. For more information visit
www.ruarkaudio.com/support
Factory reset
If you accidentally select the incorrect language you can
factory reset your radio by pressing and holding the
standby key for 10s.
Music streaming services
Spotify Connect
Use your phone, tablet or computer as a remote control
for Spotify. Go to spotify.com/connect to learn how.
Amazon Music
For more details, visit www.amazon.com
Deezer
For more details, visit dzr.fm/airable
The range of supported music services may change
without notice.
Common functions
Switch on and standby
Press STANDBY to turn your radio on from standby.
Press again to switch back to standby.
Now Playing screen
Unless you’re in a menu, station/track list or
adjusting a setting, the screen will look like the
example below.
3
2
1
5
4
6
1. Source
2. Alarm icon
3. Station / track info
4. Status icons, eg wi, track repeat/shue
5. Clock
6. Sleep timer icon
Menu screens
To change a setting, press MENU to display the list of
available options, rotate the CONTROL KNOB to scroll
through the list, and then press the knob to conrm
your selection.
8
7
7. Menu title
8. Selected menu option
To change settings –press MENU
To scroll through options – rotate CONTROL KNOB
To select option – press CONTROL KNOB
To go back or exit – press MENU to go back to the
previous screen until you get back to the Now Playing
screen, or wait for a few seconds
EN
DA
DE
ES
FR
IT
JA
KO
NL
NO
PL
ZH
XX
Adjust volume
Rotate the CONTROL KNOB from any Now Playing
screen.
Speaker volume and headphone volume are adjusted
separately.
Please note that rotating the CONTROL KNOB when a
menu or station list is displayed will scroll through the
options or stations and not change the volume.
Change audio source
Press SOURCE to view the current source, rotate the
CONTROL KNOB or press or to scroll through
the available sources, then press the CONTROL KNOB
to select one. (You can also press SOURCE repeatedly
to cycle through the list of sources.)
Change Internet radio station
Press MENU, select Last listened or Station list and
select a station.
Change DAB radio station
Press or to tune to the next or previous
station or press MENU, select Station list and select
a station.
Change FM radio station
Press or to seek the next or previous station.
Save preset
You can save 8 presets in DAB, FM, Internet radio,
Spotify, Amazon Music and Deezer.
Press and hold PRESET for two seconds and select a
preset to save the station, track or playlist.
Empty presets are marked as “[Not set]”.
If you save a new preset over an existing preset, the
new one will replace it.
Recall preset
Press PRESET, and select a preset station, track or
playlist.
Connect a Bluetooth device
Your R2 will attempt to automatically connect to the
last connected device. If you have not yet paired your
device or the previous device is not available, your R2
will enter into pairing mode. See Bluetooth section
for more details.
Station or track information
MENU > Info
Select the type of station / track information shown.
Table des matières
Autres manuels Ruark Audio Radio
Ruark Audio
Ruark Audio R1S Smart Manuel utilisateur
Ruark Audio
Ruark Audio R2 mk3 Manuel utilisateur
Ruark Audio
Ruark Audio R7 Manuel utilisateur
Ruark Audio
Ruark Audio R1 mk4 Manuel utilisateur
Ruark Audio
Ruark Audio R1mk3 Manuel utilisateur
Ruark Audio
Ruark Audio R1 mk4 Manuel utilisateur
Ruark Audio
Ruark Audio R1 mk3 Manuel utilisateur
Ruark Audio
Ruark Audio R1 Manuel utilisateur
Ruark Audio
Ruark Audio R1 Manuel utilisateur
Ruark Audio
Ruark Audio R2i Manuel utilisateur
