RTK RoyalTek BV-3200 Manuel utilisateur
1
RTK Sports Navigation
User’s Manual
2
Table of Contents
Chapter 1 Features and Specifications .................................................................................. 4
1.1 RoyalTek BV-3200 PND features.......................................................................... 4
1.2 General Usage.......................................................................................................... 4
1.3 Specification............................................................................................................. 4
1.4 Button / I/O/Slot...................................................................................................... 5
1.5 RF Function............................................................................................................. 6
1.6 Power function ........................................................................................................ 6
Chapter 2 Getting Started ..................................................................................................... 7
2.1 Hardware overview................................................................................................. 7
2.1.1
Packing
list
....................................................................................................... 7
2.2 Basic Operation, Knowing your BV-3200 ............................................................ 8
2.3 Starting Operation on your bicycle..................................................................... 11
2.4 Starting Operation on your Motorcycle. ............................................................12
2.5 Starting Operation on your Automobile............................................................. 14
2.6 Charging your BV-3200 device............................................................................15
Chapter 3 Using the BV-3200.............................................................................................. 16
3.1 BV-3200 Operating Basics ................................................................................... 16
3.2 To configure system settings:............................................................................... 16
3.3 Additional System settings...................................................................................18
3.4 Reset....................................................................................................................... 18
3.5 System Information ..............................................................................................20
3.6 Volume................................................................................................................... 20
3.7 Backlight................................................................................................................ 21
3.8 To set the favorite application category: ............................................................ 22
3.9 Power Supply......................................................................................................... 23
3.10 Charge.................................................................................................................... 23
Chapter 4 Entertainment..................................................................................................... 24
4.1. BV-3200 Multimedia Player................................................................................. 24
4.2. Music player.......................................................................................................... 24
4.2.1.
Using
the
Music
player.
................................................................................. 24
4.3. Photo Viewer ......................................................................................................... 28
4.3.1.
Viewing files in Slide Show mode
................................................................. 28
4.3.2.
Using the Photo Album
................................................................................. 28
Chapter 5 Communications..............................................................................................30
5.1. BV-3200 Bluetooth................................................................................................ 30
5.2. Bluetooth connection ............................................................................................ 30
Chapter 6 Troubleshooting and Maintenance ...................................................................33
6.1. General troubleshooting....................................................................................... 33
6.1.1.
If
your
device
does
not
respond,
do
a
“hard
reset.”
................................... 33
6.1.2.
Users can also perform a “system reset.”
.................................................... 33
6.1.3.
Screen responds slowly
................................................................................. 33
6.1.4.
Inaccurate response to taps.
......................................................................... 33
6.1.5.
Connection Problems with PC.
.................................................................... 33
6.1.6.
No GPS connection
........................................................................................ 33
6.1.7.
No sound coming from the device.
............................................................... 33
3
6.1.8.
Can’t I see my photos.
................................................................................... 33
6.1.9.
Takes longer than normal time to get a GPS fix.
........................................ 33
6.1.10.
Factory reset does mean a GPS reset.
.......................................................... 33
6.2. Maintenance .......................................................................................................... 34
6.2.1.
Storage precautions
....................................................................................... 34
6.2.2.
Accessories and repair precautions
............................................................. 34
4
Chapter 1 Features and Specifications
1.1 RoyalTek BV-3200 PND features
The
RoyalTek
BV-3200
Portable
Navigation
D
evice
is
a
powerful
multifunction
GPS/multimedia
navigation
and
entertainment
device.
‧
3.5”with TSP (Touch Screen Panel)
‧
Sun light readable
‧
High sensitivity Broadcom GPS
‧
2.4GHz ANT+ communication
‧
Bluetooth audio communication
‧
MP3 player/Photo viewer
‧
Recharge and replace battery
‧
IPX7 water proof in out door application
‧
Installation available on bicycle/motorcycle/car.
1.2 General Usage
1.2 General usage
Environment
The BV-3200 is mainly intended for Outdoor GPS navigation,
Bluetooth, and 2.4G ANT+ SPORT communication functionality.
Temperature Operating Temperature : -10 °C to +55 °C
Storage Temperature : -30 °C to +70 °C
Operation The BV-3200 will be carried with bike player. The screen shall be 3.5”
TFT LCD transflective type and sun-readable panel, in addition, it
include big size flash memory to record navigation map data.
Language English / Simplified Chinese / Traditional Chinese / German / French /
Spanish / Italian / Japanese
Weight 190 g
Dimension L: 105 mm, W: 81.9 mm, H: 26.2 mm
1.3 Specification
1.3.1 Chassis
Chassis
Form Factor Embedded GPS patch Antenna, Minimalist design
Material ABS+PC with UV-proof.
Specifications Chassis is made of sunlight/UV-proof material and coating.
Meet IPX7 waterproof standard
Color Green and Gray
5
1.3.2 System overview and description
Component BV-3100 hardware specification
CPU Samsung S3C2416@400MHz
Operation System Windows CE 5.0 core version
GPS Broadcom BCH-4750 host based chipset
+ external patch antenna. ( Patch size : 20mm X 6mm )
TFT LCD LG TFT, 3.5”, 240x320 QVGA
SDRAM
Samsung 64/128 MB 1.8 V Mobile DDR
NAND Flash memory
Samsung MLC 2 GB
Battery 1800 mAh rechargeable ad replaceable Li-ion
Power Management Maxim 8662 and Atmel mega 48 MCU
I/O MiniUSB Client connector
MicroSD card
Button Power button x 1
1.3.3 Display
Display
Supplier LG or Casio
Screen Type TFT-LCD with touch panel
Screen Size 3.5”
Resolution 240 x 320 pixel QVGA
Color 65536 colures
Backlight Most 6 LED backlight
Touch Panel Yes
1.3.4 USB Function
USB
USB Device Controller Embedded in Samsung SC32416A USB 2.0
USB Connector MiniUSB B-type connector for factory test, battery charging, and power
supply
1.4 Button / I/O/Slot
Button / Slot
Power button Yes for power on and off
Mini-USB Slot Yes for factory test, battery charging and power supply
Micro SD/MMC Slot Yes for software update and data copy
External GPS Antenna Connector No
Earphone Connector No
External Power Jack No
6
1.5 RF Function
1.5.1 GPS Specification
GPS receiver
Module Broadcom
Chipset BCM-4750 host based
Firmware Broadcom supplied with library and virtual com port driver
Channel 24
Time to Fix First time
(Open sky) Hot: 5 Sec Warm: 60 Sec Cold: 90 Sec
Accuracy 10M @ 90% on open sky
Protocol NMEA v3.0
Baud Rate 38400 bps
Sensitivity Acquisition: -157 dBm, Tracking : -162 dBm
Embedded Antenna Patch Antenna; Dimension: 20mm x 6mm
1.5.2 2.4GHz Wireless Data Communication Specification
2.4GHz Wireless Data/Audio Transceiver
Frequency band 2.4~2.5 GHz
Application Short range ANT+ data communication
Air data rate <2M bps
Tx power consumption 11.3mA@0dBm
Rx power consumption 13.5mA@ 2Mbps
Standby current 26uA
1.6 Power function
1.6.1 Power management
Power management
Chipset Maxim 8662
Efficiency Totally 90% above
Protect function a. Over Voltage protect
b. Over Current Protect
c. Power Reverse Protect.
Charger IC Build in Li-Ion Battery charger
Backlight Driver Yes
DC-Jack No
Power input Power supplied from USB
Power management Atmel mega 48 MCU
Power Consumption <450mA/3.3V typical on turning on default back light with GPS locked,
2.4G RF, and BT
7
Chapter 2 Getting Started
This
chapter
describes
the
hardware
interface
of
the
RoyalTek
BV-3200
and its
peripherals.
Instructions
for
setting
up
the
device
and
some
basic
system operations
are
also
discussed.
2.1 Hardware overview
This section introduces the BV-3200 PND external features and hardware components.
2.1.1
Packing
list
1 Device, BV-3200
2 Cradle
3 USB cable
4 AC adapter
5 Quick Start Guide
6 User Manual CD
Standard package
7 Warranty Statement Card(Optional Document)
1 Handlebar base accessories
2 Double-socket arm
3 Knob
Motorcycle
4 Base Plate
Bike 1 Bike mount
1 Car mount
Car 2 Car Charger
8
2.2 Basic Operation, Knowing your BV-3200
Front View
Rear View
Table
1:
Function controls
NO Function Description
1 Touch Screen Displays the applications, data, and map images.
2 USB Port/Docking
connector
Mini-USB connector serves as the power connector for
charging the device or as the dock for uploading files from
computers.
3 Power Button Long press 5 seconds to turn on/off the PND.
4 Speaker Emits system sounds.
5 Coin-Plug To tighten the rear cover.
1
2
3
4
5
9
Rear View (without rear cover)
Component Description
1 Battery Slot Put the battery on the slot, before use the device.
2 Micro SD slot Accepts Micro SD storage cards, allowing you use audio and
image files stored in it for use with internal applications
1
2
10
Assembly your BV-3200:
1. Put the battery on your BV-3200
2. Insert the Battery in your BV-3200 (Photo 1-1)
3. Put on the rear cover on your BV-3200 (Photo 1-2)
4. Fix the lock button
Photo 1
-
1
Photo 1
-
2
