RTI Barracuda Manuel utilisateur

Reference Manual - English - Version 4.3A

Barracuda

QABrowser

RTI article number: 9620501-00

Welcome to Barracuda

and the QABrowser

The Barracuda is an X-ray Analyser/Multimeter for

everybody working with Quality Assurance and

Service of X-ray systems.

NOTICE

Palm, palmOne, and TUNGSTEN are trademarks of PalmOne, Inc.

HotSync and Graffiti are trademarks of ACCESS CO., LTD

Microsoft, Windows, Win32, Windows XP, 2003, Vista, and 7 are either registered trademarks or

trademarks of Microsoft Corporation in the United States and/or other countries.

BLUETOOTH is a trademark owned by Bluetooth SIG, Inc., USA.

Notice

RTI Electronics Inc.

33 Jacksonville Road, Bldg. 1,

Towaco, NJ 07082,

USA

Phone: 800-222-7537 (Toll free)

Int. +1-973-439-0242

Fax: Int. +1-973-439-0248

E-mail

Sales: [email protected]

Support: [email protected]

Service: [email protected]

Web site: http://www.rti.se

Contact Information -

United States

RTI Electronics AB reserves all rights to make changes in the Barracuda, the

QABrowser, and the information in this document without prior notice.

RTI Electronics AB assumes no responsibility for any errors or consequential

damages that may result from the use or misinterpretation of any information

contained in this document.

Content of this document may not be reproduced for any other purpose than

supporting the use of the product without prior permission from RTI Electronics

AB.

RTI Electronics AB

Flöjelbergsgatan 8 C

SE-431 37 MÖLNDAL

Sweden

Phone: Int. +46 31 7463600

Fax: Int. +46 31 270573

E-mail

Sales: [email protected]

Support: [email protected]

Service: [email protected]

Web site: http://www.rti.se

Contact Information -

World-Wide

Barracuda & QABrowser Reference Manual

2012-10/4.3A

III

Intended Use of the Barracuda System

Accessory to diagnostic X-ray equipment to be used as an electrometer. Together with external

probes it is to be used for independent service and quality control, as well as measurements of

kerma, kerma rate, kVp, tube current, exposure time, luminance, and illuminance within

limitations stated below.

If installed according to accompanying documents, the product is intended to be used together

with all diagnostic X-ray equipment except for:

- therapeutical X-ray sources.

- X-ray equipment with tube potential below 20 kV.

- X-ray equipment on which the instrument cannot be mounted properly, e.g. equipment where

the beam field size is narrower than the active part of the detector.

- specific types of X-ray equipment listed in the instructions for use or in additional information

from the manufacturer.

With the X-ray installation in stand-by conditions without patients present, the product is intended

to be used:

- to provide the operator with information on radiation beam parameters that might influence

further steps in an examination but not an ongoing exposure.

- for assessing the performance of the X-ray equipment.

- for evaluation of examination techniques and procedures.

- for service and maintenance measurements.

- for quality control measurements.

- for educational purposes, authority supervision etc.

The product is intended to be used by hospital physicists, X-ray engineers, manufacturer's service

teams, and other professionals with similar tasks and competencies. The operator needs a short

training to be able to use the product as intended. This training can be achieved either by careful

study of the manual, studies of the built-in help function in measurement software or, on request,

in a short course ordered from the manufacturer.

The product is intended to be used inside X-ray rooms ready for clinical use and can safely be left

switched on and in any measuring mode in the vicinity of patients.

The product is NOT intended to be used:

- for direct control of diagnostic X-ray equipment performance during irradiation of a patient.

- so that patients or other unqualified persons can change settings of operating parameters during

and immediately before and after measurements.

Barracuda & QABrowser Reference Manual 2012-10/4.3A

Intended Use

Barracuda & QABrowser Reference Manual

2012-10/4.3A
