Rtech TIG201 Manuel utilisateur

www.r-techwelding.co.uk

email: sales@r-techwelding.co.uk

Tel: 01452 733933 Fax 01452 733939

TIG201 AC/DC INVERTER TIG WELDER

OPERATION INSTRUCTIONS

Version 2014-1

Thank you for selecting the R-Tech Tig201 Inverter AC/DC TIG Welder.

The Tig201 has many benefits over traditional TIG welders, including 250Hz AC frequency

adjustment, AC squarewave balance control, full pulse welding, slope up/down, remote foot

option and an industrial 60% duty cycle

We want you to take pride in operating our Tig201 as much pride as we have taken in

making this product for you. Please read all information in this manual before operation

PLEASE EXAMNINE CARTON AND EQUIPMENT FOR DAMAGE IMMEDIATELY

When this equipment is shipped, title passes to the purchaser upon receipt from the courier.

Consequently all claims for material damaged in shipment must be made by purchaser against the

transportation company used.

Please record your equipment identification below for future reference. This information can be found on

data plate at rear of machine.

Product TIG201

Serial No. ___________________________________

Date of Purchase _____________________________

Where Purchased _____________________________

Whenever you request replacement parts or information on this equipment please always supply

information you have recorded above

This product is covered by 2 years parts and labour warranty, we will cover cost of collecting, repair and

returning item to you (UK mainland only, other areas are RTB). External items, torch, earth lead etc are

covered by 3 months warranty. Any faults/damage found caused by customer will be charged pro-rata

Pay particular attention to the safety instructions we have provided you for your protection

The level of seriousness to be applied to each section is explained below

WARNING

This statement appears where the information must be followed exactly to avoid serious personal

injury.

CAUTION

This statement appears where the information must be following to avoid a minor personal injury or

damage to this equipment.

Introduction

The R-Tech Tig201 is a member of our field acclaimed family of welding products. Premium

features include:-

1. Inverter power source – more efficient to operate, provides smoother weld characteristics.

2. AC squarewave frequency adjustment to 250Hz

3. AC squarewave balance control

4. Full featured pulse welding in both AC and DC modes

5. Patented HF Microstart – Reduces electronic interference to local area

6. Slope up / slope down

7. Remote foot pedal option

8. Digital amp meter

9. Industrial 60% Duty cycle at 200 Amps @ 40C

Recommended Processes

The R-Tech Tig201 is recommended for the TIG welding processes within its output capacity of 200

Amps

Equipment Limitations

The R-Tech Tig201 is protected from overloads beyond the output ratings and duty cycle as per

machine specifications with thermostat protection of the output coils and rectifiers.

Welding Capability – Duty Cycle

The R-Tech Tig201 is rated at 200 Amps at 60% duty cycle on a ten minute basis. If the duty cycle

is exceeded a thermal protector will shut machine off until the machine cools.

Technical Specifications

Model No.

R-Tech TIG201

Input (volts/amps)

240V AC 60Hz (16A Tig) (32A MMA)

MMA

No-load Voltage

60V – 80V

Current Range

5A – 160A

Rated Output Current

160A

Duty Cycle

35%

TIG

No-load Voltage

60V – 80V

Current Range

(AC 20A – 200A) (DC 5-200A)

Rated Output Current

200A

Duty Cycle

60% @40c

SP% AC Balance

30 – 70

Up-Slope Time

10 Seconds

Down-Slope Time

10 Seconds

Pulse Current Range

5A – 200A

Pulse Width Range

0.1 – 0.9 Seconds

Pulse Frequency Range

0.5Hz – 25Hz

Gross Weight

25 KG

Insulation

IP21S

Dimensions mm

430 x 200 x 290

Safety Precautions

Read entire section before starting installation

WARNING!

Electric Shock can kill – Only qualified personnel should perform this installation. Turn off input

power at the fuse box before working on this equipment. Do not touch electrically live parts. Always

connect the machine to an earthed mains supply as per national recommended standards.

Select suitable location

Place the welder where clean cooling air can freely circulate in and out of the front & rear louver

vents. Dirt, dust or any foreign material that can be drawn through vents into welder must be kept to

a minimum. Failure to observe these precautions can result in excessive operating temperatures

which can lead to plant failure.

Grinding

Do not direct grinding particles towards the welder. An abundance of conductive material can cause

plant failure.

Stacking

This machine cannot be stacked.

Transport – Unloading

Never underestimate the weight of equipment, never move or leave suspended in the air above

people. Use recommended lifting equipment at all times.

WARNING!

Falling Equipment can cause injury. Never lift welder with gas bottle attached. Never lift above

personnel.

Tilting

Machine must be placed on a secure level surface or on a recommended undercarriage/trolley.

This machine may topple over if this procedure is not followed.

Environmental Rating

The welding power source carries the IP21S rating. It may be used in normal industrial and

commercial environments. Avoid using in areas where water / rain is around.

Read and follow the ‘Electric Shock Warnings’ in the safety section if welding must be performed

under electrically hazardous conditions such as welding in wet areas or water on the work piece.

Electrical Installation

WARNING!

ELECTRIC SHOCK CAN KILL

Machine grounding and High Frequency Interference Protection

This welder must be grounded to earth. See national electrical codes fro proper grounding

methods.

The high frequency generator being similar to a radio transmitter may cause interference to radio,

TV and other electronic equipment. These problems may be the result of radiated interference.

Proper grounding methods can reduce or eliminate this.

Radiated interference can develop in the following ways

1. Direct interference from welder power source

2. Direct interference from the welding leads

3. Direct interference radiated from feedback into power lines

4. Interference from re-radiation by un-grounded metallic objects.

Keeping these contributing factors in mind, installing equipment as per following instructions should

minimize problems.

1. Keep the welder input power lines as short as possible and enclose as much of them as

possible in metal conduit or equivalent shielding. There should be a good electrical contact

between this conduit and ground (Earth).

2. Keep the work and electrode leads as short as possible. Tape the leads together where

practical.

3. Be sure the torch and earth leads rubber coverings are free from cuts and cracks that allow

welding power leakage

4. Keep earth lead connection to work in good condition – Clean area on workbench where

earth clamp is situated on a regular basis.

Input Connections

Make sure the voltage, phase and frequency of input power is as specified on machine rating plate

located at rear of machine.

Have a qualified electrician provide suitable input power as per national electrical codes. Make sure

machine is earthed / grounded.

Make sure fuse or circuit breaker is correct rating for machine. Using fuses or circuit breakers

smaller than recommended will result in ‘nuisance’ shut off from welder inrush currents even if

welding at low amperages.

Failure to follow these instructions can cause immediate failure within the welder and void

machines warranty.

Turn the input power OFF at the mains switch & fuse box before working on this equipment.

Have a qualified electrician install & service this equipment.

Allow machine to sit for 5 minutes minimum to allow the power capacitors to discharge before

working inside this equipment. Do not touch electrically live parts

The TIG201 Inverter TIG Welder requires a 240V 50/60Hz supply. It requires a 16A supply for TIG

operation and a 28A supply for MMA welding. It comes with a 3 metre mains cable attached.

Connect wires according to national coding.

Brown wire – Live

Blue wire – Neutral

Green/Yellow Wire – Earth (Ground)

Connecting to a mains electrical supply

THIS MACHINE IS OF AN INDUSTRIAL SPECIFICATION AND MUST BE

FITTED TO A 16AMP 240V MAINS INPUT

Connecting to an Engine Driven Generator

If connecting this machine to an engine driven generator please ensure the

following

Minimum Generator KVA Output – 6.5 KVA continuous

Generator to be fitted with AVR (automatic voltage regulation)

DO NOT USE ON A GENERATOR WITHOUT AVR

Connecting to a generator without the above minimum requirements will in-

validate your warranty.

Connections for Tig201

Rear machine connections

Fig 1

1. On/Off Switch

2. Auxiliary 240V AC output

For water cooler – Maximum load 3A – Do not connect to power tools etc

3. Fuse Holder

3A fuse for water cooling socket

4. Mains input cable

Fit required plug as per your electrical installation

5. Gas input connector

Connect input gas hose ensuring connection is tight

6. Earth for chassis

If experiencing localized interference when using machine, connect workbench to this point

using correct graded earth wire (not normally used)

Connections for TIG (GTAW) Welding

Fig 2

1. Positive power connector +

Connect the earth lead to by inserting and twisting until tight and the earth clamp to

work/bench.

2. Gas outlet

Connect the torch gas hose

3. Negative power connector -

Connect TIG Torch Dinze to power connector by inserting and twisting until tight

4. Torch control socket 7-Pin

Connect torch control plug

To avoid a High Frequency shock keep the TIG torch in good condition and replace if any of the

insulation is damaged.

Connect the gas input hose to gas regulator and use ‘Pure Argon’ Gas, available from local

suppliers. Set gas flow/pressure to 8-12 LPM.

Make sure gas bottle is secured to avoid injury.

Remote Foot Pedal connection.

Disconnect TIG Torch switch plug from torch control socket (Fig2.4) and connect plug from foot

pedal.

Connections for STICK MMA (SMAW) Welding

Fig 3

1. Positive power connector +

Connect the electrode holder by inserting and twisting until tight

2. Not used in MMA mode

3. Negative power connector -

Connect the earth lead to by inserting and twisting until tight and the earth clamp to

work/bench.

4. Not used in MMA mode
