Universal Automatic Notebook Power Adapter RMNA-11001
User Manual
Universal Automatic Notebook Power Adapter RMNA-11001 User Manual
1
Thank you for buying this universal power adapter.
Please read the manual carefully before using. Don't connect the adapter to your laptop before the output voltage is
confirmed. Be sure that the output voltage of the adapter should be the input voltage of the requirement of the laptop.
Any improper operation may cause damage to your laptop.
Feature:
110~240 Automatic voltage, for notebooks usage only
Different voltage to suit most brand name notebook currently in the market
Special design ofAC Adapter to offer convenient power cord storage
OPP/OCP/OVP/SCP protection
Tips available for notebook brand ASUS, ACER, Sony, DELTA, IBM, DELL, Compaq, HP,NEC, Liteon, Toshiba,
Gateway, SHARP
ETL certification
Specification
Note :
Please check with the Manufacturer Product Page for the compatible Notebook Model list.
Compatibility :
13 tips(Including Special tips for DELL and HP) with varied models ofASUS, ACER, Sony, DELTA, IBM,
DELL, Compaq, HP,NEC, Liteon, Toshiba, Gateway, SHARP
AC Adapter Voltage : 15-24V, Automatic
AC Adapter Output Power: 90W
Product Dimension : 5.27" x 2.24" x 1.24"
Weight : 1.03 lbs.
Warranty : 1 Year Limited
Universal Automatic Notebook Power Adapter RMNA-11001 User Manual
2
User Instructions
1, Use an AC power cord to connect the laptop to the power socket .the LED light will be blinking Indicating the laptops
working.
2, Select the correct tip and connect it to the terminal of the DC cable, confirm the voltage
if it is the right, one correspondent to the voltage requirement for your laptop
3, Connect to your laptop.
How to confirm the required voltage for your laptop
1, Refer to the instruction of your laptop.
2, you can also find it out from the rating label (or sticker) in the back(or front) of the laptop.
How to find out a right tip
You have to confirm the required input voltage for your laptop first, refer to the figure printed on the tip, and check it
one by one to find the right
Warning 1, Do not expose the unit in rain or a wet environment.
2, Do not try to open or disassemble the unit yourself.
3 keep away from children
Environment friendly disposal
You can help protect the environment! Please remember to respect the local regulations:
Hand in the non-working electrical equipments to an appropriate waste disposal centre. The
packaging material is recyclable. Dispose of the packaging in an environmentally friendly manner and make it
available for the recyclable material collection-service.
Universal Automatic Notebook Power Adapter RMNA-11001 User Manual
3
Appendix 1
13 tips Compatable Power model
OUTSIDE
SIZE(MM)
Inner size
(mm)
output
voltage compatible models
NO.1 6.5 4.4 16V SONY 16 4A, Sony 16V 3.75A,Fujitsu 16V 3.36A, Fujitsu 16V 3.75A
NO.2 6.5 4.4 19.5V Sony 19.5V 4.1A ,SONY 19.5V 4.7A,SONY 19V 3.9A ,Fujitsu 19V 3.16A,SONY 19.5V
2.15A,SONY 19.5V 3A,SONY 19V 3.16A ,
NO.3 6.3 3.0 15V TOSHIBA 15V 5A,TOSHIBA 15V 6A,NEC 15V 4A，TOSHIBA 15V 3A,TOSHIBA 15V 4A,
NO.4 5.5 2.5 16V IBM 16V 3.36A,IBM 16V 3.5A,IBM 16V 4.5A
NO.5 5.5 2.5 19V
IBM 19V 4.2A ,FUJITSU 19V 4.22A,Compaq 19V 4.8A,Compaq 19V 4.9A,LS 20V 4.5A, Toshiba
19V 4.74A,TOSHIBA 19V 3.95A, Gateway 19V 4.74A,DELTA 19V 4.74A,Acer 19V
4.74A,HP/Compaq 18.5V 4.9A,HP/Compaq 19V 4.74A,HP 19V 3.95A ,ASUS 19V 4.74A,
DELTA 19V 4.47A ,LITEON 19V 3.95A ,LITEON 19V 4.74A
NO.6 3pin 3pin 20V Dell 20V 4.5A,Dell 19V 2.64A, Dell 20V 3.5A,
NO.8 4.8 1.7 18.5V
HP/Compaq 18.5V 4.9A,Acer 19V 4.74A,LG 19V 4.74A , HP/Compaq 19V 4.74A ,COMPAQ
18.5V 4.9A,ASUS 19V 2.1A,Compaq 18.5V 2.7A,Compaq 18.5V 3.8A,HP/Compaq 18.5V
3.5A,LG 18.5V 3.5A,Delta 19V 2.64A,Asus 19V 2.64A,NEC 19V 2.64A
NO.9 7.4 5.0 19.5V Dell 19.5V 4.62A ,Dell 19.5V 3.34A ,DELL 19.5V 2.64A
NO.10 7.4 5.0 19V HP 19V 4.74A ,HP/Compaq 18.5V 3.5A
NO.11 5.5 2.1 19V Acer 19V 3.16A,Acer 19V 3.42A
NO.13 5.3 3.0 19V SAMSUNG 19V 4.22A ,19V 3.15A ,19V 4.74A ,19V 2.1A
NO.15 7.9 5.5 20V IBM 20V 4.5A ,IBM 20V 3.25A
NO.35 3.5 1.35 22V SHARP 19V 2.64A
Thank you for purchasing a quality Rosewill Product.
Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
