Rosco BRAQ CUBE Manuel utilisateur

USER’S MANUAL

BRAQ CUBE®

Table of Contents

Your Braq Cube

Product Description....................................................................................... 5

What’s In the Box............................................................................................ 7

Braq Cube Interface........................................................................................8

Braq Cube Series

Braq Cube WNC/3W....................................................................................... 11

Braq Cube 4C & 4CA.......................................................................................... 9

Braq Cube Modes

DMX Mode........................................................................................................12

Color Wash Mode........................................................................................... 20

Spread Lens.................................................................................................. 24

Manual Mode.................................................................................................. 17

Beam Angles

Changing the Spread Lens.........................................................................25

Serial Mode......................................................................................................23

Table of Contents

Mounting and Configuration

Linear Array..................................................................................................... 26

Safety Cables.................................................................................................. 28

Braq Cube Support

General Precautions...................................................................................... 30

FCC Warning.................................................................................................... 29

Warning Messages..........................................................................................31

Product Description

Braq Cube®

Rosco's innovative Braq Cube series of LED wash lights packs 100

watts outputting more than 7100 lumens into a compact and portable

5 inch cube! The sleek yet rugged, geometric design of the Braq Cube

is perfectly at home in entertainment environments, museums, stores

and lobbies, built into sets, truss and lighting rigs of all styles.

These luminaires oer the flexibility and versatility needed for any type

of lighting challenge. No expensive external power supply or ballast is

required, the Braq Cube plugs directly into the wall anywhere in the

world, automatically adjusting to mains power from 90-240vAC 50-60hz.

Drawing less than an amp of current, more than 20 Braq Cubes can

be plugged into a single 20A circuit!

An intuitive LCD control panel sets virtually every aspect of the lights

including a master-slave configuration for fast lighting set-ups.

Completely flicker free diming is available via DMX (in 8 or 16 bit

resolution).

Product Description

Weighing just 3-1/2 pounds, mounting these compact 5 inch cubes is

limited only by the imagination of the installer. The novel through

bolted yoke design allows units to be easily ganged into multi-unit

strips and arrays for greater output and coverage. With a simple cable

jumper you can use Braqs to output power to the adjacent fixtures.

Available in versions that oer full quad chip color mixing and tuneable

color temperature white light, the Braq Cube luminaires are the

smallest, most feature packed and aordable, professional grade LED

wash lights on the market.

What’s In the Box

[1] Braq Cube

[2] Power Option Set of Symmetrical

Spread Lenses

[3]

Braq Cube Interface

BRAQ CUBE

D ES I G N ED BY TH E BLA CK TA N K

M E N U O K

PW R

PWR

IN DMX OUT

POWER LIGHT

LCD DISPLAY

MENU KEY

DMX IN DMX OUT POWER OUT CONNECTOR

KEY

OK KEY

OUT

PWR

POWER IN CONNECTOR

Braq Cube 4C & 4CA

From walls to washes to uplighters, the

Braq Cube 4C & 4CA color mixing wash

light oers a designer maximum creativity

in a tiny package. The best-in-class

quad-chip emitters inside the Braq Cube

RGBW 4C and the RGBA 4CA produce a

gorgeous palette of saturated, mid-tone

and pale tint colors. The 4C and 4CA can

also mix an attractive, full spectrum white light in warm and cool color

temperatures - not the unflattering compromise found in other

color-mixing LED lights.

The Braq Cube 4CA features a unique, phosphor-converted amber

emitter – not found in any other RGBA fixture this size. This enables it

to produce an expanded palette of saturated colors and rich,

warm-tones of full-spectrum white light.

Smart programming in the Braq Cube 4C & 4CA includes a stand-alone

color wash mode or allows multiple units to be easily slaved together,

synchronized and oset using self-generated DMX for color chases and

other dynamic lighting patterns without a console. Use it alone,

configured in strips & arrays or built-in for virtually any application

needing colored light - from stage, studios and location, bars and

casinos, to stores, windows and lobbies.

From walls to washes to uplighters, the

Braq Cube 4C & 4CA color mixing wash

light oers a designer maximum creativity

in a tiny package. The best-in-class

quad-chip emitters inside the Braq Cube

RGBW 4C and the RGBA 4CA produce a

gorgeous palette of saturated, mid-tone

and pale tint colors. The 4C and 4CA can

also mix an attractive, full spectrum white light in warm and cool color

temperatures - not the unflattering compromise found in other

color-mixing LED lights.

The Braq Cube 4CA features a unique, phosphor-converted amber

emitter – not found in any other RGBA fixture this size. This enables it

to produce an expanded palette of saturated colors and rich,

warm-tones of full-spectrum white light.

Smart programming in the Braq Cube 4C & 4CA includes a stand-alone

NOTE: The luminaire should be positioned so that prolonged staring

into the luminaire at a distance closer than 3.3m is not expected.

color wash mode or allows multiple units to be easily slaved together,

synchronized and oset using self-generated DMX for color chases and

other dynamic lighting patterns without a console. Use it alone,

configured in strips & arrays or built-in for virtually any application

needing colored light - from stage, studios and location, bars and

casinos, to stores, windows and lobbies.
