INSTALLATION AND CARE GUIDE
VANITY
E031127
E031139
E031151
E031178
170609ronbow.eu | ronbow.comINSTALLATION SHEET
1
NOCE Vanity
Model : E031127
E031139
E031151
E031178
Designed By: MATTEO THUN & ANTONIO RODRIGUEZ | ITALY
Tools Required
PRE-INSTALLATION
Materials Included
E031127 & E031139
12 long screws for the leg
4 short screws for the two front legs
4 solid wood legs
4 leg levelers
E031151 & E031178
16 long screws for the legs
4 short screws for the two front legs
5 solid wood legs
5 leg levelers
NOTE: Team work required
Materials Required
E031127 & E031139
1 2x6 beam cut to size
3 2-1/2” wood screws
E031151 & E031178
1 2x6 beam cut to size
6 2-1/2” wood screws
170609ronbow.eu | ronbow.comINSTALLATION SHEET
2
NOCE Vanity
Model : E031127
E031139
E031151
E031178
Designed By: MATTEO THUN & ANTONIO RODRIGUEZ | ITALY
Figure 2.
Figure 3.
Figure 1.
Step 2:
Step 3:
Use the short screws for top two
holes on the front legs, and long
screws for the bottom two holes in
each leg.
Carefully lay down the cabinet on
its back.
Line up the leg with the holes located
on the cabinet.
Step 1:
INSTALLATION
Step 4:
Install the leg leveler to each leg.
NOTE:For the 51” or 78” repeat steps
1-2 to install the fifth leg.
See Figure 1.
See Figure 2.
See Figure 3.
See Figure 1.
Fasten each leg leveler to the bottom
of each leg.
Long Screw
Short Screw
170609ronbow.eu | ronbow.comINSTALLATION SHEET
3
NOCE Vanity
Model : E031127
E031139
E031151
E031178
Designed By: MATTEO THUN & ANTONIO RODRIGUEZ | ITALY
Figure 4.
Mark the location of the supporting
beam.
The cabinet should always handled by
two person while moving to the desire
location.
NOTE: Team work required
Note: It is important to attach to the
wall to properly secure the vanity.
Step 7:
Stand the cabinet upright.
Determine the ideal position of the
vanity and place the horizontal studs
into the wall
NOTE: the location needs at least two
studs. Front notch the studs and install
the 2x6 horizontal beam 30-3/4” from
the floor.
See Figure 4.
Step 6:
Determine the ideal location of your
new vanity.
Step 5:
For the 27” or 39” vanity, please
remove the drawers prior secure the
vanity to the wall.
NOTE: Please see Pg.6 for instruction
on how to remove the drawers.
Step 8:
170609ronbow.eu | ronbow.comINSTALLATION SHEET
4
NOCE Vanity
Model : E031127
E031139
E031151
E031178
Designed By: MATTEO THUN & ANTONIO RODRIGUEZ | ITALY
Figure 5.
Step 9: Position the cabinet against the wall
and line up with the supporting beam
location.
Fasten the long screws into
the wall from the inside of the cabinet
NOTE: For 27” or 39” or 51”, it requires
3pcs of 2-1/2” wood screws. For 78”
vanity, it requires 6pcs 2-1/2” wood
screws.
See Figure 5.
Figure 6.
Step 2: Position the top over the vanity and
press firmly.
Follow the directions on the silicone
product to allow for ample
drying time.
Position the vanity top over the vanity.
Verify the top is level.
NOTE: Team work required
Apply a small bead of silicone as
shown in diagram on the right.
Step 1:
INSTALLING THE VANITY TOP
See Figure 6.
170609ronbow.eu | ronbow.comINSTALLATION SHEET
5
NOCE Vanity
Model : E031127
E031139
E031151
E031178
Designed By: MATTEO THUN & ANTONIO RODRIGUEZ | ITALY
Figure 7.
Locate the screw nearest the hinge
cup and rotate clockwise or counter-
clockwise to move the door from side
to side.
Locate the screw furthest away from
the hinge cup and turn the screw
clockwise or counter-clockwise to
move the door from front to back.
Locate the screw pictured in Figure 6.
Turn the screw clockwise or counter-
clockwise to move the door from top
to bottom.
ADJUST DOOR HINGE
Figure 8.
Figure 9.
NOTE: When adjusting the door hinges keep in mind
to adjust the other hinges.
Side to Side
Front to Back
Top to Bottom
See Figure 7.
See Figure 8.
See Figure 9.
Side
Depth
Height
170609ronbow.eu | ronbow.comINSTALLATION SHEET
6
NOCE Vanity
Model : E031127
E031139
E031151
E031178
Designed By: MATTEO THUN & ANTONIO RODRIGUEZ | ITALY
Figure 10.
Step 2:
Step 2:
Open the drawer and lift
upwards from the drawer face
to remove the drawer.
Re-attach the screws that hold
the wire harness in back of
the vanity.
Remove the 3 screws holding the wire
harness in the back of the vanity.
Line up the drawer with the slides and
slide inward towards the vanity until
the hook in the back locks the drawer
in to place.
See Figure 10.
See Figure 11.
Step 1:
Step 1:
REMOVE DRAWER
REINSTALL DRAWER
Figure 11. Hook
170609ronbow.eu | ronbow.comINSTALLATION SHEET
7
NOCE Vanity
Model : E031127
E031139
E031151
E031178
Designed By: MATTEO THUN & ANTONIO RODRIGUEZ | ITALY
Wood Surfaces
Recommended Products
The fine furniture finish of your new vanity, mirror or other bathroom accessories are designed to
protect against normal home use. With proper care, your product will provide years of use and beauty
in your home.
General Care Tips
PRODUCT CARE AND MAINTENANCE
• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause
greater damage.
• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the
finish will eventually crack.
• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.
Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid
these extremes.
• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general
cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the
wood’s chacteristics.
• Pledge Orange Oil, or similar
• Orange-Glo Wood Cleaner
DISCLAIMERS: Wood naturally ages, darkens and changes color over time due to several environmental conditions that may cause materials to vary from their
original color and/or to warp, split or crack. These variations are considered to be the nature of the material in relation to their environmental exposure and may
be significant over a long period of time. The eectiveness of cleaning Ronbow product is dependant on various factors that include sunlight, smoke, moisture,
household cleaners and/or amount of cleaning product used over time. Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• Test cleaning product on small, discrete area prior to applying to entire surface.
• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.
• Do not allow liquids and moisture to accumulate on the surface of products.
• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service
Department at (510) 713-1188.
170609ronbow.eu | ronbow.comINSTALLATION SHEET
8
NOCE Vanity
Model : E031127
E031139
E031151
E031178
Designed By: MATTEO THUN & ANTONIO RODRIGUEZ | ITALY
TechStone™
Recommended Products
• Clean up any spills or liquids immediately. Never allow liquids of any kind to remain on surface.
• Use a non-abrasive, damp cloth to wipe down surfaces.
• Use a gentle (pH balanced) detergent with warm water to clean the surface of your vanity top.
• DO NOT use any abrasive cleaning products that contain any of the following chemicals:
trichloroethane or methylene chloride (such as paint removers or strippers), hydrofluoric acid, liquid
bluing or gentian violet.
• Simple Green Stone Cleaner
DISCLAIMERS: Eectiveness of cleaning your Ronbow products is dependent on various factors that include: water temperature, concentration and/or amounts
of cleansers. Because of these many dierent conditions, Ronbow cannot guarantee that the above Product Care & Maintenance methods will eectively clean
your product.
170614
40650 Encyclopedia Circle
Fremont, CA 94538
T 510.713.1188
F 510.657.9388 ronbow.eu | ronbow.com
