RoMedic EasyBelt Manuel utilisateur
Manual no: 00802En Ver. 1 090129
EasyBelt and FlexiBelt are used as support in different transfer situations. They are not to be used as assistive devices for
lifting. The inside of the EasyBelt is lined with nylon, making it easy to launder or wipe clean with disinfectant. FlexiBelt’s
soft inside feels comfortable against the skin. Both materials have an anti-slip function.
EasyBelt and FlexiBelt are part of a series of different transfer assistive devices. The choice of model and material is
determined by the patient’s functional capacity and the situations in which the product is to be used.
RoMedic’s products together form the SystemRoMedic concept, which takes a holistic approach to patient transfers.
SystemRoMedic has four categories of transfers: transfer, positioning, support and lifting.
Visual inspection
Check the condition and function of the product regularly, and always after laundering. Check to ensure that the fabric is
not worn, damaged or bleached. If there are signs of wear, the product must be discarded.
Mechanical load
Test clasp function and handles by applying tension to ensure that the product withstands heavy load (page 2).
Read instructions for all assistive devices used in connection with transfers.
To prevent discomfort, exercise care and caution when using the product.
Functional inspection
Always read the instructions
Manual
Ver.1 090129
Functional testing of EasyBelt/FlexiBelt
Pull hard on the handles in different directions (1).
Fasten the belt, place one foot in it, and then pull on one of the handles (2). Repeat
the procedure with all handles.
1. Apply the belt around the patient, below the waist but above the hips.
2. Fasten the belt and tighten it.
Release the clasp, first loosening any straps, and then remove the belt.
Placement of EasyBelt/FlexiBelt
Removing EasyBelt/FlexiBelt
2
MANUAL
1
2
Ver.1 090129
Caregivers can work in pairs or alone, depending on the patient’s needs,
since EasyBelt/FlexiBelt have several vertical and horizontal handles. Cross-
grips at the back provide support and enable a good working stance (1 and
2).
When two caregivers are assisting, it is appropriate if one caregiver stands
on each side, grasping the cross-grips at the back and holding the patient by
the hand at the front (3).
EasyBelt/FlexiBelt provide good support during transfers between wheel-
chair and bed (4).
Using EasyBelt/FlexiBelt
3
MANUAL
3
4
1
2
Size:
Size XS S M L XL
Rec. lbs -66 55-121 110-165 154-242 231-
patientweight kg - 30 25-55 50-75 70-110 105-
Material:
EasyBelt: Polyamide, nylon
FlexiBelt: Polyamide, polyester
Care of the product:
Read the product label.
Do not use rinsing agent. To ensure
maximum material life, hang dry or
tumble dry on low heat.
When in doubt, contact your RoMedic representative for product trials, advice or information.
If you require additional information, contact your transfer specialist or our representative, or visit www.romedic.com. Make
sure you always have the most recent version of the manual. Manuals are available for downloading from our website;
http://www.romedic.com
RoMedic AB
Box 640 Tel: +46 (0)8-594 773 33 Internet: www.romedic.com
SWEDEN
6012 EasyBelt XS 75 x 12 cm
6013 EasyBelt S 105 x 12 cm
6014 EasyBelt M 120 x 12 cm
6015 EasyBelt L 135 x 12 cm
6023 FlexiBelt S 105 x 12 cm
6024 FlexiBelt M 120 x 12 cm
6025 FlexiBelt L 135 x 12 cm
6026 FlexiBelt XL 150 x 12 cm
