Rolls RM67 Manuel utilisateur

The RM67 is a single rack space mixer designed for the install/contractor market.

The unit mixes three balanced microphones with four stereo sources to mono or

stereo balanced outputs.

The XLR Microphone Inputs have Mic/Line level switches, a send/return Insert

jack, and individually switchable +12 VDC phantom power. Priority talkover is avail-

able on one microphone for paging, and on one Source input for use on a jukebox.

telephone system, etc.

Each Microphone input has a level and tone control, and each Source input has a

level control. Bass and Treble controls have been provided for all the sources, and a

Master Output Level control adjusts the level of all mixed signals.

A pre-Master RCA output has been provided for recording, and a Remote Volume

output jack is provided for connection to a 100K ohm linear taper potentiometer

and used as an external master level control.

FEATURES:

•

Three XLR Microphone Inputs

• Individually switchable phantom power

•

Four Stereo Source Inputs, Four RCA and one front panel stereo 3.5mm

•

T

one controls for each Mic Input / Bass and Treb

Tone controls for each Mic Input / Bass and TrebT

l

e controls for the Source Inputs

•

Stereo RCA Re

cord

Output

• Remote Volume control jack

• 1/4" TRS Mic Insert jack

SPECIFICATIONS

Input Impedance: Mic: 600 Ohms XLR balanced

Line: 22K Ohms

Source: 22K Ohms gold plated RCA

Mic Insert: 22K Ohms 1/4” TS unbal.

Max Input Level: Mic: -14 dBV Mic level

+20 dB Line levl

Source: 24 dBV

Connectors: 3: XLR, 6: Stereo RCA, 3: 1/4” TRS, 1: 1/4” TS, 1: 3.5mm

Phantom Power: +12 VDC

Output Level: +17 dBV max

Output Impedance: 51 Ohms

Nose Floor: - 80 dB, THD: <.025%, S/N Ratio: 96 dB

Max Gain: Mic: 60 dB

Source: 26 dB

Tone Controls: +/-12 dB 100 Hz Bass

+/-12 dB 11kHz Treble

Size: 19” x 1.75” x 6” (48.3 x 4.5 x 15 cm)

Weight: 5 lbs. (2.3 kg)

ROLLS Coporation

5968 South 350 West, Salt Lake City, UT, 84107

(801) 263-9053 FAX (801) 263-9068

[email protected] • www.rolls.com

RM67 Mic/Source Mixer
