Rointe Ecodesign BELIZE Manuel utilisateur

MANUAL DE INSTALACIÓN Y USO

Página 26

MANUAL DE INSTALAÇÃO E DE UTILIZAÇÃO

Página 48

INSTALLATION AND USER MANUAL

Page 03

INSTALLATIE- EN GEBRUIKERSHANDLEIDING

Page 70

BELIZE Digital radiator with Wi-Fi / Radiador digital con Wi-Fi /

Radiador digital com Wi-Fi / Digitale radiator met Wi-Fi

GUARANTEE / GARANTÍA

/ GARANTÍA / GARANTIE

ON THE BODY

EN EL CUERPO

NO CORPO

IN HET LICHAAM

YEARS / AÑOS

/ ANOS / JAAR

YEARS / AÑOS

/ ANOS / JAAR

ON ELECTRONICS

EN ELECTRÓNICA

NA ELECTRÓNICA

IN ELEKTRONICA

SYMBOLS

DANGER. This symbol indicates a medium-high risk hazard which can result in

serious injury or even death.

DO NOT COVER. Do not dry or leave clothes or towels on the radiator. Do not

leave or place magazines, spray cans, volatile substances, or similar objects

within 250 mm of the radiator.

HOT SURFACE. This symbol indicates that your surfaces are hot during and

immediately after use. These must not be touched: danger of burns.

OBSERVE THE INSTRUCTIONS IN THE MANUAL. Please read this manual

carefully before installing and using the product. Keep it for later use. Read all

instructions and safety warnings. Failure to follow these can result in electric

shock, re or serious injuries.

BELIZE DIGITAL RADIATOR WITH WI-FI

INDEX

1. General Warnings ............................................................................................................ 5

2. Technical information .................................................................................................... 8

3. Installation........................................................................................................................ 9

4. Screen & Keypad ............................................................................................................ 12

5. Functionality and programming ................................................................................. 13

5.1. ON & OFF ................................................................................................................ 13

5.2. Select the temperature.......................................................................................... 13

5.3. Temperature control ............................................................................................ 14

5.4. Lock / unlock button pad ...................................................................................... 14

5.5. Settings menu ....................................................................................................... 14

5.5.1. Settings submenu............................................................................................ 15

5.5.2. Energy submenu.............................................................................................. 16

5.5.3. Wi-Fi submenu................................................................................................. 17

5.5.4.Prog. mode ....................................................................................................... 18

6. Wi-Fi pairing....................................................................................................................22

7. Maintenance and cleaning ...........................................................................................22

8. European Regulation (WEEE) 2012/19/EU ................................................................22

9. Guarantee ......................................................................................................................23

10. How to register your product guarantee ..................................................................25

Directive ERP Commission Regulation ..........................................................................92

Declaration of conformity .................................................................................................93

1. GENERAL WARNINGS

WARNINGS

This product may be used by children over 8 years of age

and by persons with reduced physical, sensory, or mental

capabilities, or lack of experience and knowledge under strict

supervision or instruction in the safe use of the product and

if they understand the hazards involved. Children should not

plug, adjust, clean, play with, or perform maintenance on this

product. Children under 3 years of age should be kept away

from this product unless supervised.

DO NOT use the product in enclosed spaces if the persons

present cannot leave the room independently and are not

under constant supervision.

DO NOT COVER. To avoid overheating, do not cover the

radiator.

DO NOT place spray cans, volatile substances, or similar

objects within 250mm of the product.

DO NOT use insecticides, paints, or chemicals on or near the

product.

Some parts of this product could reach high temperatures

and cause burns. DO NOT touch the external parts of the

product when in operation.

DO NOT install near curtains or other ammable materials.

Particular attention should be paid when children and

vulnerable people are present.

BELIZE DIGITAL RADIATOR WITH WI-FI

When using electrical appliances, precautions should be

taken to reduce the risk of re, electric shock and injury.

Never insert ngers, body parts or objects inside the product.

Make sure that the voltage indicated on the product’s

technical information corresponds to the voltage output you

have at your socket.

Any repair or maintenance that requires the product to

be opened the product must be carried out by personnel

authorised by ROINTE, who must also be notied if a leak

is observed. Only ocial spare parts approved by ROINTE

should be used. Please observe the current and relevant

regulations when disposing of this product and its thermal

uid.

If the power cable is damaged, it must be replaced by

personnel authorised by ROINTE to prevent any damage.

To avoid the risk of suffocation, do not leave the packaging

including bags and other items within reach of babies or

children.

The product has an IP24 degree of protection and can be

used in bathrooms, but not in the vicinity of bathtubs, taps,

showers, water connections, toilets, swimming pools or other

masses of water. The product must never be installed where

it, the switches or the control panel are within the reach of

people in the water. Never use the product with wet hands.

Do not place any water containers (glasses, vases, etc.) on or

near the product.

IMPORTANT

Disconnect the product from the power supply and make

sure the product is at room temperature before any cleaning

or maintenance. Do not use any abrasive substances on

the product, such as (but not limited to) chemicals, coarse

cloths, brushes, hard bristle, or wire/steel wool.

To disconnect the product from the power source, remove

the mains plug from the socket. Do not pull on the cable.

ROINTE cannot be held responsible for incorrect sizing of

the product unless it has been followed by an ocial ROINTE

technical study.

Before the rst start-up, or before the start of winter, or when

the product has not been used for many days, the appliance

should be cleaned (follow the steps in the “maintenance”

section of this manual).

Do not sit or lean on the product.

Temperature contrasts can generate “clicks” or noises in

the device. This is not a fault of the product, but due to the

expansion/contraction of the materials.

When disposing of the product, the requirements set out in

the legislation for the waste treatment and recycling must be

followed. See WEEE in section 8.

BELIZE DIGITAL RADIATOR WITH WI-FI

2. TECHNICAL INFORMATION

MODEL BRI0330RAD BRI0550RAD BRI0770RAD BRI0990RAD BRI1210RAD BRI1430RAD BRI1600RAD

Number of elements 3 5 7 9 11 13 15

DIMENSIONS, WEIGHTS & FINISHES

Width (mm) 340 500 660 820 980 1,140 1,300

Height (mm) 575 575 575 575 575 575 575

Depth (mm) 95 95 95 95 95 95 95

Installed depth (mm) 118 118 118 118 118 118 118

Weight (kg) 8.0 12.0 16.0 20.0 24.0 28.0 32.0

Finish White RAL 9010

ELECTRICAL CHARACTERISTICS

Nominal power (W) 330 550 770 990 1,210 1,430 1,600

Effective power (W) 132 220 308 396 484 572 640

Voltage (V) 230 ~V 230 ~V 230 ~V 230 ~V 230 ~V 230 ~V 230 ~V

Current (A) 1.4 2.3 3.3 4.3 5.2 6.2 6.9

SAFETY & INSTALLATION

Safety thermostat

Template & Installation Kit

Grade of protection IP 24 IP 24 IP 24 IP 24 IP 24 IP 24 IP 24

EAN Code 8435556138723 8435556138730 8435556138747 8435556138754 8435556138761 8435556138778 8435556138785

3. INSTALLATION

We recommend using a trusted Rointe supplier for installation of the product. Find the

nearest one by calling us on 0203 321 5929 or using the locator on www.rointe.co.uk.

IMPORTANT: Prior to installation, please locate the metal tag located at the back of the

product and note the product reference and serial number. You will need this information

to register your guarantee. See section 10 for help on how to register the guarantee.

WARNING: Do not install the product directly over an electrical outlet or junction box.

Do not install the product or use it outdoors. Do not install directly under a shelf. This

product is designed to be installed on an interior wall using the ROINTE template, the

installation kit and the xings supplied. Do not install the product in such a way that it

encounters the power cable.

The product must be mounted on the wall in the position

shown in the accompanying image using the brackets

and with the xings supplied.

Our products transfer heat through the natural air

convection. If the product is covered, this will disrupt

the airow and could cause overheating. It must be

positioned in accordance with the minimum distances

shown in the accompanying picture.

WARNING: The product has an IP24 degree of protection and can be used in bathrooms,

but not in the vicinity of bathtubs, taps, showers, water connections, toilets, swimming

pools or other masses of water. The product can only be installed in zone 3 of the

accompanying picture. The product must never be installed where it, the switches or the

control panel are within the reach of people in the water. Never use the product with wet

hands. Do not place any water containers (glasses, vases, etc.) on or near the product.

ZONA EXTERIOR ZONA EXTERIOR

2.25 m

0.6 m 0.6 m

0.6 m

BELIZE DIGITAL RADIATOR WITH WI-FI

An installation kit is included in the product packaging. You will need a drill, a rubber mallet,

a spirit level and a pencil to complete the installation.

WARNING: The weight of some of the products may be heavy. The installation

may require two people.

IMPORTANT: Please follow these instructions carefully.

1. Remove the packaging and check that the installation

contains brackets, screws, rawl plugs and a cardboard

template.

2. Select a suitable location on the wall. Place the

template on the wall and mark the holes for the

brackets and screws. Observe the minimum distance

requirements from the previous page.

Use the oor as a base for the template, not the

skirting board.

3. Remove the template and carefully drill out the

marked holes.

4. Secure the upper brackets with the rawl plugs

and screws provided. Then x the lower bracket. To

distinguish it, the lower bracket has a different design

from the top ones.

Top bracket

5. Slide the product up and down over the xed

brackets.

6. Check the straightness with a spirit level and adjust

the supports accordingly if necessary.

Bottom bracket

7. Connect your product to the power supply and

switch it on.

8. See section 5 for operating instructions.

IMPORTANT: Template measurements per model

0330RAD - 3 elements 0550RAD - 5 elements

80 mm

661 mm

218 mm

240 mm

80 mm

661 mm

218 mm

0770RAD - 7 elements 0990RAD - 9 elements

400 mm

160 mm

661 mm

218 mm

560 mm

240 mm

661 mm

218 mm

Floor

Autres manuels pour ecodesign BELIZE

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Rointe Chauffage

Rointe

Rointe TN030SEB Manuel utilisateur

Rointe

Rointe SYGMA STN030SEB2 Guide de configuration

Rointe

Rointe Tovare aqua Manuel utilisateur

Rointe

Rointe SYGMA Manuel utilisateur

Rointe

Rointe Sygma SRI0330RAD2 Manuel utilisateur

Rointe

Rointe Palaos 1000RAD Fiche technique

Rointe

Rointe DELTA ULTIMATE Manuel utilisateur

Rointe

Rointe D SERIES Manuel d'utilisation et d'entretien

Rointe

Rointe ecodesign D Series Manuel utilisateur

Rointe

Rointe Napoli aqua Manuel utilisateur

Rointe

Rointe TN030SEB Manuel utilisateur

Rointe

Rointe D SERIES Mode d'emploi

Rointe

Rointe Circe electric OVAL 482 Manuel utilisateur

Rointe

Rointe Lyon electric OVAL 500 Manuel utilisateur

Rointe

Rointe Lyon electric pro Manuel utilisateur

Rointe

Rointe D SERIES Manuel utilisateur

Rointe

Rointe Kyros Manuel

Rointe

Rointe Tovare electric OVAL 500 Manuel utilisateur

Rointe

Rointe Elba OVAL 400 Manuel utilisateur

Rointe

Rointe Belize 0330RAD Manuel utilisateur

Rointe

Rointe Kyros Manuel utilisateur

Rointe

Rointe ecodesign BELIZE BAS Manuel utilisateur

Rointe

Rointe SYGMA SRI1100RADC2 Manuel utilisateur

Rointe

Rointe ecodeisgn SYGMA SRF0500RAD2 Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur

Rointe ecodesign BELIZE Manuel utilisateur

Manuels Chauffage populaires d'autres marques
