■Table of Contents
Preface---------------------------------------------------------------1
Safety Alert Signs----------------------------------------------------2
Safety precautions---------------------------------------------------4
Management---------------------------------------------------------5
Names and Function of Each Part----------------------------------6
User’s Guide----------------------------------------------------------7
Problems-------------------------------------------------------------10
References------------------------------------------------------------11
Management and Inspection----------------------------------------11
Fuse Replacement----------------------------------------------------11
Warranty Period----------------------------------------------------13
Precautions When Using-------------------------------------------13
Storage After Use & Maintenance --------------------------------14
Detailed Description------------------------------------------------14
Rough Map of company ------------------------------------------------15
■Preface
Thank you for purchasing the Refraction Table RT 13S.
Please read this manual carefully and make sure you are familiar
with the contents before using the equipment.
-2-
Operating Environment
Use the system under the following normal conditions:
Operation : +5 to +40°C, 30 to 80% r.h., 70 to 106 kPa
Make sure the system is properly plugged into the power
source before use.
Use the Power Supply (SMPS) within the range of 220-240V~
50/60Hz.
Always turn OFF this system when not in use.
■Safety Alert Signs
This manual provides important information to prevent improper
operation leading to human injury or property damage to the user or
another person.
Please read the “Safety Precautions”carefully and follow all safety
indications and symbols.
Safety Marks and Definitions
Warning
This symbol indicates information that, if not adhered
to, could possibly result in serious personal injury or
even death due to incorrect handling.
Caution
This symbol indicates information that, if not adhered
to, could result in minor or moderate injury or
property damage.
-3-
Symbols and Definitions
Template for a prohibition sign (red circle and diagonal);
The black symbol or text shall be placed centrally on the
background and shall not obliterate the cross bar, or a
supplementary text next to the sign.
Template for a mandatory action sign (blue background); The
white symbol or text shall be placed centrally on the background,
or a supplementary text next to the sign.
Template for a warning sign (yellow background and black
triangle); The black symbol or text shall be placed centrally on
the background, or a supplementary text next to the sign.
Warning - Disposal of waste products
1. When this crossed-out wheeled bin symbol is attached to a
product it means the product is covered by the European
Directive 2012/19/EU.
2. All electrical and electronic products should be disposed of
separately from the municipal waste stream via designated
collection facilities appointed by the government or the local
authorities.
3. The correct disposal of your waste products will help prevent
potential negative consequences for the environment and
human health.
4. For more detailed information about disposal of your waste
products, please contact your city office, waste disposal service
or the shop where you purchased the product.
Follow instructions for use
Manufacturer
Serial no.
-4-
■Safety Precautions
Symbol
Description
Do not disassemble the table for repair.
Electric shock may occur.
Contact the sales shop for repairs.
Do not place the table near water or another area with liquid.
Fire or electric shock may occur.
!
Connect the table to a single-phase AC power plug.
Otherwise, it can cause a fire or electric shock.
!
Replace the fuse only after the power cord is unplugged.
Otherwise, an electric shock may occur.
Use the appropriate fuse.
Unplug the power cord immediately when smoke or any other
problem occurs.
Otherwise, there is a danger of fire.
Please contact the sales shop for repairs.
Do not place the equipment on an unstable foundation or
slanted more than 5˚.
It may cause injury.
Do not place heavy materials exceeding the specified weight.
It may cause injury.
Do not put your fingers around moving or rotating machinery
objects. It may cause injury.
Do not open the cover, as electric shock may result.
Contact the sales shop when repairs are needed.
Other than those supplied by the manufacturer of the product
safety when using the power line is not guaranteed.
-5-
■Management
Operator’s Management
Other than what is indicated in this manual, for safety reasons, do not
perform administrative maintenance tasks on the equipment; have
qualified service people complete all maintenance and repairs.
The items listed below can be managed by customers:
Fuse Replacement
The fuse is a replaceable item.
Refer to its handling method in the manual.
Disclaimers
We are not responsible for damages caused by fire, earthquakes,
acts by third parties, or other accidents, or damage caused by
negligence or use under abnormal conditions.
We are not responsible for damages caused by abnormal use of the
machine not described in the instruction manual.
-6-
■Name & Function of Each Part
-7-
Name & Function of Each Part
①TABLE: Mounting base
②MAIN POWER Switch: The switch to turn ON & OFF the MAIN
POWER
③UP & DOWN Switch: The switch to turn UP & DOWN the table
④BASE: Used to secure to the table to the floor
⑤CASTER: Movable or stoppable wheels are fixed hereto.
⑥COLUMN
⑦POWER INLET SOCKET: Used to connect power cords
FUSE 250V F5AL 2EA
※Check the following standard accessories:
User’s Guide (1 EA)
Glass tube fuse 250V F5AL (2 EA)
■User’s Guide
※Protection would be impaired if the equipment is used in a
manner not specified in the manual by the manufacturer.
Before Use
①Check the power voltage. (220-240V~ 50/60Hz)
②Check that all switches are positioned properly.
③After connecting the power, check the machine for proper
operation.
-8-
Operation Method and Procedures
①Insert the POWER CABLE into the input socket at the bottom of
the equipment and connect it to a commercial power supply.
②Push the green switch on the control panel at the left of the
product to the “O”position. The light will turn green (POWER ON).
-9-
③Press the UP(▲)/DOWN(▼) Switch at the lower of the table to
adjust the table’s height.
④Press the UP(▲)/DOWN(▼) switch to return the height of table to its
original position.
⑤Push the POWER switch on the control panel to the “I” position.
The green light will turn off (POWER OFF).
⑥Remove the POWER CABLE from the commercial power supply.
