Trusted TMR 35 to 120 Vdc Digital Input Module –

40 Channel

Product Overview

The Trusted®TMR 120 Vdc Digital Input Module interfaces to 40 field input devices. Fault tolerance

is achieved through a Triple Modular Redundant (TMR) architecture within the Module for each of

the 40 input channels.

Each field input is triplicated and the input voltage is measured using a sigma-delta input circuit.

The resulting field voltage measurement is compared to user configurable threshold voltages to

determine the reported field input state. When a line-monitoring device is installed at the field

switch, the Module can detect open and short circuit field cables. Line monitoring functions are

independently configured for each input channel. The triplicated voltage measurement, coupled

with on-board diagnostic testing, provides comprehensive fault detection and tolerance.

The Module provides on-board Sequence of Events (SOE) reporting with a resolution of 1 ms. A

change of state triggers an SOE entry. States are determined by voltage thresholds that can be

configured on a per channel basis.

Features:

•40 Triple Modular Redundant (TMR) input channels per Module.

•Comprehensive, automatic diagnostics and self-test.

•Selectable line monitoring per channel to detect open circuit and short circuit field wiring

faults.

•2500 V impulse withstand opto/galvanic isolation barrier.

•On-board Sequence of Events (SOE) reporting with 1 ms resolution.

•Module can be hot-replaced on-line using dedicated Companion (adjacent) Slot or SmartSlot

(one spare slot for many modules) configurations.

•Front Panel input status LEDs for each channel indicate input status and field wiring faults.

Trusted ICSTT-RM046A-EN-E (PD-T8425)

Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425) Issue 1

•Front panel module status LEDs indicate module health and operational mode (Active,

Standby, Educated).

•TϋV Certified IEC 61508 SIL 3.

Trusted TMR 35 to 120 Vdc Digital Input Module – 40 Channel PREFACE

Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425) Issue 1 i

PREFACE

In no event will Rockwell Automation be responsible or liable for indirect or consequential damages

resulting from the use or application of this equipment. The examples given in this manual are

included solely for illustrative purposes. Because of the many variables and requirements related to

any particular installation, Rockwell Automation does not assume responsibility or reliability for

actual use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, with respect to use of information, circuits,

equipment, or software described in this manual.

Allen-Bradley, LISTEN. THINK. SOLVE., Rockwell Automation, TechConnect, and Trusted are

trademarks of Rockwell Automation, Inc.

Trademarks not belonging to Rockwell Automation are property of their respective companies.

All trademarks are acknowledged.

DISCLAIMER

It is not intended that the information in this publication covers every possible detail about the

construction, operation, or maintenance of a control system installation. You should also refer to

your own local (or supplied) system safety manual, installation and operator/maintenance manuals.

REVISION AND UPDATING POLICY

This document is based on information available at the time of its publication. The document

contents are subject to change from time to time. The latest versions of the manuals are available at

the Rockwell Automation Literature Library under "Product Information" information "Critical

Process Control & Safety Systems".

TRUSTED RELEASE

This technical manual was updated for Trusted Release 4.0.

LATEST PRODUCT INFORMATION

For the latest information about this product review the Product Notifications and Technical Notes

issued by technical support. Product Notifications and product support are available at the Rockwell

Automation Support Centre at

http://rockwellautomation.custhelp.com

At the Search Knowledgebase tab select the option "By Product" then scroll down and select the

Trusted product.

Some of the Answer ID’s in the Knowledge Base require a TechConnect℠Support Contract. For more

information about TechConnect Support Contract Access Level and Features, click on the following

link:

https://rockwellautomation.custhelp.com/app/answers/detail/a_id/50871

PREFACE Trusted TMR 35 to 120 Vdc Digital Input Module – 40 Channel

ii Issue 1 Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425)

This will get you to the login page where you must enter your login details.

IMPORTANT A login is required to access the link. If you do not have an account then you can create one

using the "Sign Up" link at the top right of the web page.

DOCUMENTATION FEEDBACK

Your comments will help us serve your documentation needs better. If you have any suggestions on

how to improve this document, complete the How Are We Doing? form at

https://literature.rockwellautomation.com/idc/groups/literature/documents/du/ra-du002_-en-e.pd

Trusted TMR 35 to 120 Vdc Digital Input Module – 40 Channel PREFACE

Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425) Issue 1 iii

SCOPE

This manual specifies the maintenance requirements and describes the procedures to assist

troubleshooting and maintenance of a Trusted system.

WHO SHOULD USE THIS MANUAL

This manual is for plant maintenance personnel who are experienced in the operation and

maintenance of electronic equipment and are trained to work with safety systems.

SYMBOLS

In this manual we will use these notices to tell you about safety considerations.

SHOCK HAZARD: Identifies an electrical shock hazard. If a warning label is fitted, it

can be on or inside the equipment.

WARNING: Identifies information about practices or circumstances that can cause

an explosion in a hazardous environment, which can cause injury or death,

property damage or economic loss.

ATTENTION: Identifies information about practices or circumstances that can cause

injury or death.

CAUTION: Identifies information about practices or circumstances that can cause

property damage or economic loss.

BURN HAZARD: Identifies where a surface can reach dangerous temperatures. If a

warning label is fitted, it can be on or inside the equipment.

This symbol identifies items which must be thought about and put in place when

designing and assembling a Trusted controller for use in a Safety Instrumented

Function (SIF). It appears extensively in the Trusted Safety Manual.

IMPORTANT Identifies information that is critical for successful application and understanding of

the product.

NOTE Provides key information about the product or service.

TIP Tips give helpful information about using or setting up the equipment.

PREFACE Trusted TMR 35 to 120 Vdc Digital Input Module – 40 Channel

iv Issue 1 Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425)

WARNINGS AND CAUTIONS

WARNING: EXPLOSION RISK

Do not connect or disconnect equipment while the circuit is live or unless the area is

known to be free of ignitable concentrations or equivalent

AVERTISSEMENT - RISQUE D’EXPLOSION

Ne pas connecter ou déconnecter l’équipement alors qu’il est sous tension, sauf si

l’environnement est exempt de concentrations inflammables ou équivalente

MAINTENANCE

Maintenance must be carried out only by qualified personnel. Failure to follow these

instructions may result in personal injury.

CAUTION: RADIO FREQUENCY INTERFERENCE

Most electronic equipment is influenced by Radio Frequency Interference. Caution

should be exercised with regard to the use of portable communications equipment

around such equipment. Signs should be posted in the vicinity of the equipment

cautioning against the use of portable communications equipment.

CAUTION:

The module PCBs contains static sensitive components. Static handling precautions

must be observed. DO NOT touch exposed connector pins or attempt to dismantle a

module.

Trusted TMR 35 to 120 Vdc Digital Input Module – 40 Channel PREFACE

Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425) Issue 1 v

ISSUE RECORD

Issue Date Comments

1 Jul 19 First issue

PREFACE Trusted TMR 35 to 120 Vdc Digital Input Module – 40 Channel

vi Issue 1 Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425)

Page intentionally left blank

Trusted TMR 35 to 120 Vdc Digital Input Module – 40 Channel Table of Contents

Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425) Issue 1 1

Table of Contents

1. Description .............................................................................................................3

1.1. Field Termination Unit (FTU)....................................................................................................... 4

1.2. Field Interface Unit (FIU).............................................................................................................5

1.3. Host Interface Unit (HIU) ............................................................................................................ 5

1.4. Front Panel Unit (FPU) ................................................................................................................ 6

1.5. Line Monitoring Thresholds ........................................................................................................ 6

1.6. Housekeeping.............................................................................................................................. 9

1.7. Fault Detection and Testing ........................................................................................................9

1.8. Sequence of Events Characteristics .......................................................................................... 10

2. Installation...........................................................................................................12

2.1. Module Insertion/Removal .......................................................................................................12

2.2. Field Cable Selection .................................................................................................................12

2.3. Module Pin-out Connections ....................................................................................................13

2.4. Trusted Module Polarisation/Keying. .......................................................................................14

3. Application ...........................................................................................................16

3.1. Module Configuration...............................................................................................................16

3.2. T8425 Complex Equipment Definition ...................................................................................... 16

3.2.1. Rack 1: DI...........................................................................................................................18

3.2.2. Rack 2: STATE ....................................................................................................................

3.2.3. Rack 3: AI ...........................................................................................................................19

3.2.4. Rack 4: SPARE ....................................................................................................................20

3.2.5. Rack 5: LINE_FLT................................................................................................................20

3.2.6. Rack 6: DISCREP.................................................................................................................20

3.2.7. Rack 7: HKEEPING..............................................................................................................21

3.2.8. Rack 8: Information ........................................................................................................... 23

3.3. Sequence of Events Configuration............................................................................................25

3.4. System.INI File Configuration....................................................................................................25

4. Operation .............................................................................................................28

4.1. Front Panel ................................................................................................................................28

4.2. Module Status LEDs...................................................................................................................29

4.3. I/O Status LEDs..........................................................................................................................30

5. Fault Finding and Maintenance..............................................................................32

5.1. Fault Reporting..........................................................................................................................32

5.2. Field Wiring Faults.....................................................................................................................32

Table of Contents Trusted TMR 35 to 120 Vdc Digital Input Module – 40 Channel

2 Issue 1 Rockwell Automation Publication ICSTT-RM046A-EN-E (PD-T8425)

5.3. Module Faults ...........................................................................................................................32

5.4. Companion Slot.........................................................................................................................33

5.5. SmartSlot...................................................................................................................................33

5.6. Cold Start...................................................................................................................................33

5.7. Transfer between Active and Standby Modules.......................................................................34

6. Specifications........................................................................................................36

Autres manuels pour Trusted TMR

Table des matières

Autres manuels Rockwell Automation Système de sécurité

Rockwell Automation

Rockwell Automation Bulletin 855BS LED Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
