Rocket Fish TRFQX5 Manuel utilisateur

Noise Cancelling Wireless Headset

RF-QX5

User Guide

2RF-QX5 Noise Cancelling Wireless Headset

Noise Cancelling Wireless

Headset

Contents

Important safety instructions .......................................... 3

Introduction ........................................................................... 4

Features.................................................................................... 4

Package contents.......................................................... 4

Components ................................................................... 5

Using the headset ................................................................ 6

Headset functions......................................................... 6

Charging the battery ................................................... 6

Turning the headset on or off................................... 6

Pairing the headset with a compatible phone... 7

Disconnecting the headset from the phone....... 7

Reconnecting the headset to the phone ............. 8

Making a call ................................................................... 8

Answering or ending a call........................................ 8

Rejecting a call ............................................................... 8

Redialing the last number dialed............................ 8

Muting a call ................................................................... 9

Using voice dialing ....................................................... 9

Adjusting the earpiece volume................................ 9

Switching between the headset and phone....... 9

RF-QX5 Noise Cancelling Wireless Headset

Erasing all pairing information................................. 9

Turning the LED indicator on or off......................10

Checking the battery status....................................10

Resetting the headset ...............................................10

Maintaining ..........................................................................10

Troubleshooting .................................................................11

Specifications.......................................................................11

Legal notices ........................................................................12

One-year limited warranty..............................................13

Important safety instructions

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not expose the headset to water.

6Clean only with a dry cloth.

7Do not plug in the wall charger near any heat sources such as radiators,

heat registers, stoves, or other chargers that produce heat.

8Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The

wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

9Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

charger.

10 Only use attachments/accessories specified by the manufacturer.

11 Unplug this charger during lightning storms or when unused for long

periods of time.

12 Refer all servicing to qualified service personnel. Servicing is required

when the apparatus has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

4RF-QX5 Noise Cancelling Wireless Headset

13 To reduce the risk of fire or electric shock, do not expose the charger to

rain, moisture, dripping, or splashing.

14 An apparatus with a three-prong, grounding-type plug is a Class I

apparatus, which needs to be grounded to prevent possible electric

shock. Make sure that you connect this Class I device to a

grounding-type, three-prong outlet.

15 In order to charge your headset correctly, the wall outlet must be in

correct working condition.

16 Batteries should not be exposed to excessive heat.

Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type.

Introduction

Congratulations on your purchase of the RF-QX5 wireless headset.

This headset represents the state of the art in wireless headset design

and is designed for reliable and trouble-free performance.

Features

Package contents

• QX5 noise cancelling wireless headset

• Ear loop

• USB charging cable and A/C wall charger

• Earbuds (small, medium, and large)

• Quick Setup Guide

Note: The ear loop and medium earbud come preattached.

RF-QX5 Noise Cancelling Wireless Headset

Components

#Component Description

1Volume down Press to decrease the earpiece volume.

Power/Send/End button • Switches the headset on and off.

• Answers incoming calls.

•Endsactivecalls.

• Rejects incoming calls.

•Voicedials.

Indicator light Power on—Lights solid yellow-green for 1 second and the headset beeps

once.

Pairing mode—Rapidly flashes yellow-green.

The flashing continues for approximately three minutes or until the headset is

connected to a compatible phone. If the headset is not connected to a phone

during this time, the headset enter connectable status.

Connectable—Flashes yellow-green once every 2.5 seconds.

Connection active—Flashes yellow-green every 5 seconds.

Incoming call—Flashes yellow-green two times every 1 second.

Active call—Flashes yellow-green every 5 seconds.

Power off—Lights solid red for 1 second and the headset beeps once.

Low battery—Alternately flashes yellow-green and red, and the headset

beeps every 300 seconds.

4Charger connector Connect the charger to this jack and to a power outlet to charge the battery.

5Volume up Press to increase the earpiece volume.

6Earpiece Transmits the callers voice.

6RF-QX5 Noise Cancelling Wireless Headset

Using the headset

Headset functions

Charging the battery

Before using the headset, you must charge the battery for

approximately two hours. When the battery is fully charged, it

provides up to 5 hours of talk time or up to 200 hours of standby

time.

To charge the battery:

• Connect the charger to the headset and to an power outlet. While the

battery is charging the indicator lights red. When the battery is fully

charged, the indicator lights yellow-green.

Note: You may also charge the headset with the USB cable by plugging the cable into

an USB port on your laptop or desktop computer.

Turning the headset on or off

To turn the headset on or off:

1To turn on the headset, press and hold the power button for about two

seconds. The headset beeps and the indicator blinks yellow-green. (The

first time you turn on the headset, you have to press and hold the power

button for five seconds.)

2To turn off the headset, press and hold the power button for about four

seconds. The headset beeps and the indicator briefly lights red.

Headset function Button presses

Voice dial Press the power/send/end button.

Redial Double-press the power/send/end button.

Answer a call Press the power/send/end button.

End (cancel) a call Press and hold the power/send/end button for two

seconds.

Reject a call Double-press the power/send/end button.

Transfer a call between connected

devices

Double-press the power/send/end button while in

a call to transfer call to handset.

Mute or unmute Press volume up and volume down buttons at the

same time for about two seconds.

Adjust the earpiece volume Press volume up or volume down button.

Erase all pairing information When the headset is turned off, press and hold the

power/send/end and volume up buttons until the

indicator flashes red and yellow-green alternately.

Turn the indicator on or off When the headset is connected to a phone, press

and hold the power/send/end and volume up

buttons for four seconds.

Check the battery status Press and hold the power/send/end for two

seconds.

RF-QX5 Noise Cancelling Wireless Headset

Pairing the headset with a compatible phone

Pairing is the process of linking the headset with a Bluetooth-enabled

mobile phone. After you pair the headset with a phone, you can only

use the headset with the paired phone. If you want to use the

headset with a different phone, you must repeat the pairing process

with the new phone. The headset can be paired with up to eight

compatible phones, but it can be connected to only one phone at a

time.

To pair the headset with a compatible phone:

1Make sure that the compatible phone is turned on and within 33 feet

(10 meters) of the headset.

2Turn on the headset and make sure that the battery is fully charged.

3Press and hold the power/send/end button for about four seconds. The

indicator rapidly flashes yellow-green.

4Release the button. The headset is now in pairing mode.

5Activate the Bluetooth connection from the phone. See the

documentation that came with the phone for instructions.

6Set the phone to start searching for Bluetooth devices.

7Select RF-QX3 from the list of found devices displayed on the phone.

8If neccessary, enter a PIN code 0000 to pair and connect the headset with

your phone. With some phones, you need to make a connection

separately after pairing.

Disconnecting the headset from the phone

To disconnect the headset from the phone:

• Turn off the headset.

Or,

• Disconnect the headset in the phone’s menu.

Or,

• Move the headset more than 33 feet (10 meters) away from the phone.

Note: You do not need to delete the pairing with the headset to disconnect the

headset. When you reconnect the headset to a phone it has be paired with, you do

not have to enter the code 0000 again.

8RF-QX5 Noise Cancelling Wireless Headset

Reconnecting the headset to the phone

Note: The headset connects to the last connected phone by default. If the last phone is

out of the Bluetooth operating range or you are not using the last phone, the headset

searches and connects to the other paired phones.

To reconnect the headset to the last phone used:

• If the headset is turned off, turn it on. It automatically connects to the

phone.

Note: If the headset is out of Bluetooth operating range (33 feet/10 meters) for less

than two minutes, the headset sounds a warning tone and the indicator flashes

yellow-green every 2.5 seconds. If you move the headset back into operating range, it

automatically reconnects with the phone.

If the headset is out of Bluetooth operating range for more that two minutes, press

and hold the power/send/end button until a beep sounds to indicate the connection

is reactivated.

Making a call

To make a call:

• Use the phone in the normal way. See the phone’s documentation for

instructions.

Answering or ending a call

When you receive a call, you hear a ringing tone through the headset.

To answer or end a call:

• Press the power/send/end button to answer a call. Press the

power/send/end button for about two seconds to end the currently

active call.

Note: Some phones have an Auto Answer function. If the phone has this function, you

can use it with the headset.

Rejecting a call

To reject a call:

• Double-press the power/send/end button.

Redialing the last number dialed

To redial the last number dialed:

• While no call is in progress, double-press the power/send/end button.

RF-QX5 Noise Cancelling Wireless Headset

Muting a call

To mute a call:

• Press the volume up and volume down button at the same time for

about two seconds to mute current call. Press the volume up and volume

down buttons at the same time for about two seconds again to unmute

the call.

Using voice dialing

If the paired phone has a voice dialing feature, you can use it with the

headset.

To use voice dialing:

• When no call is in progress, briefly press the power/send/end button. A

tone indicates that you can start saying the voice tag. The phone plays

the voice tag and dials the related phone number.

Adjusting the earpiece volume

To adjust the earpiece volume:

• Press the volume up or volume down button.

Switching between the headset and phone

To switch between the headset and phone:

• While a call is in progress, double-press the power/send/end button or

use the switching function on the phone.

Erasing all pairing information

To erase all pairing information:

1Turn off the headset.

2At the same time, press and hold the power/send/end and volume up

buttons until the indicator flashes. After erasing all pairing information,

the headset enters pairing mode automatically.

10 RF-QX5 Noise Cancelling Wireless Headset

Turning the LED indicator on or off

You can turn the LED indicator on or off when the headset is

connected to a phone or during a call.

To turn the LED indicator on or off:

• At the same time, press the power/send/end button and the volume up

button for about four seconds. The LED indicator turns off. Repeat this

step to turn the LED indicator back on.

Checking the battery status

When the headset is paired and connnected to a phone, press and

hold the power/send/end button for about two seconds:

• If the indicator flashes once yellow-green, the battery level is over half of

battery capacity.

• If the indicator flashes once yellow-green and red, the battery level is less

than half, but has more than one hour of talk time.

• If the indicator flashes once red, the battery level has less than one hour

talk time.

Resetting the headset

To reset the headset:

• Connect the charger. The headset is turned off and reset.

Note: You should only use the reset function when the headset operates unusually.

When you reset the headset, pairing information is not erased.

Maintaining

• Do not store the headset in cold areas. When the headset returns to

normal temperature, moisture can form inside the headset and damage

eclectronic circuit boards.

• Do not drop, knock, or shake the headset. Rough handling can break

internal circuit boards and fine mechanics.

• Do not use harsh chemicals, cleaning solvents, or strong detergents to

clean the headset.

• Do not paint the headset. Paint can prevent correct operation.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Rocket Fish casque

Rocket Fish

Rocket Fish RF-QX5 Manuel utilisateur

Rocket Fish

Rocket Fish RF-QX3 Manuel de la liste des pièces

Rocket Fish

Rocket Fish RE-GUV1202 Manuel utilisateur

Rocket Fish

Rocket Fish RF-QX3 Guide de démarrage rapide

Rocket Fish

Rocket Fish RF-QX3 Manuel d'installation et d'exploitation

Rocket Fish

Rocket Fish RF-BTHP01 Guide de démarrage rapide

Rocket Fish

Rocket Fish RF-GPS3007 Manuel utilisateur

Rocket Fish

Rocket Fish RF-QX3 Manuel utilisateur

Rocket Fish

Rocket Fish RF-BTHP02 Manuel utilisateur

Rocket Fish

Rocket Fish RF-QX4-T Manuel utilisateur

Rocket Fish

Rocket Fish RF-EX7 Manuel utilisateur

Rocket Fish

Rocket Fish RF-CNA3 Manuel utilisateur

Rocket Fish

Rocket Fish RF-JJX15 Manuel utilisateur

Rocket Fish

Rocket Fish RF-MAB2 Manuel utilisateur

Rocket Fish

Rocket Fish RF-GPS31201 Manuel de la liste des pièces

Rocket Fish

Rocket Fish EX7 Manuel utilisateur

Rocket Fish

Rocket Fish RF-GUV1202 Manuel utilisateur

Rocket Fish

Rocket Fish RF-MAB2 Guide de démarrage rapide

Rocket Fish

Rocket Fish RF-BTHP02 Manuel de la liste des pièces

Rocket Fish

Rocket Fish RF-BTHP02 Guide de démarrage rapide

Rocket Fish

Rocket Fish RF-GPS31104 Manuel utilisateur

Rocket Fish

Rocket Fish RF-PH4101 Manuel d'installation et d'exploitation

Rocket Fish

Rocket Fish RF-GPS31104 Manuel utilisateur

Rocket Fish

Rocket Fish RF-MAB2 Guide de démarrage rapide

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Plantronics

Plantronics Blackwire 3200 Series Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur
