ROBINHOOD RHDW4345W Manuel utilisateur
Issue 1
Description:
Model Numbers:
Robinhood 4 Program Freestanding Dishwasher
RHDW4345W, RHDW4345X
Models Pictured: RHDW4345W, RHDW4345X
Dear Customer,
Read this Manual
•
Please carefully read this manual before using the
dishwasher, it will help you to use and maintain the
dishwasher properly.
•
Keep it for reference in future.
•
Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions,
Operating Instructions, Installation Instructions and
Troubleshooting Tips etc.
�
BeforeCallingforService
•
To review the section on troubleshooting Tips
will help you to solve some common problems
by yourself.
•
If you cannot solve the problems by yourself,
please ask for the help from professional technicians.
A NOTE:
The manufacturer, following a policy of constant
development and updating of the product, may
make modifications without giving prior notice.
Index....................................................... ………..1
Important Safety Instructions..................... 2
Installation Instruction. .............................. 3-5
Operating Instruction. .................................. 6-7
Detergent Filling.............................................8-10
Basket and Rack Shelves. ..........................11-12
Loading........................................................13
Wash Program...........................................14-15
Maintenance and Cleaning. ........................16-20
Trouble Shooting Tips. ..............................21-24
Appliance Details………………………………………..25
Disposal. ......................................................26
Loading the Basket........................................27
Warranty Card. ........................................ 28-29
Loading the baskets according to
(*AS/NZS 2007.1)
Index
1
Important Safety Instructions
1. This appliance is intended to be used in household and similar applications , such as:
-staff kitchen areas in shops, offices and other working environments;
-farm houses;
-by clients in hotels, motels and other residentialtype environments;
-bed and breakfast type environments.
2. The appliance is not to be used by persons (including children) with reduced Physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction. Children being supervised not to play with the
appliance.
3. The door is not left in the open position since this could present a tripping hazard.
4. When loading items to be washed:
-Locate sharp items so that they are not likely to damage the door seal.
-WARNING: Knives and other utensils with sharp points must be loaded in the basket
with their points facing down or placed in a horizontal position.
5. If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
6. WARNING: Some dishwasher detergents are strongly alkaline. They can be extremely
dangerous if swallowed. Avoid contact with the skin and eyes and keep children away
from the dishwasher when the door is open. Check that the detergent receptacle is
empty after completion on the wash cycle.
7. Do not place any heavy objects on or stand on the door when it is open. The appliance
could tip forward.
8. Check that the detergent powder is empty after completion of the wash cycle.
9. Use only detergent and rinse additives designed for automatic dishwasher.
10. Do not operate your dishwasher unless all enclosure panels are properly in place.
11. Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
12. The appliance is to be connected to the water mains using new hose sets and that old
hose-sets should not be reused.
13. During installation, the power supply cord must not be excessively or dangerously bent
or flattened.
13. Maximum 12 place settings.
Maximum 1 MPa permissible inlet water pressure.
Minimum 0.04 0.04MPa.
This appliance is for indoor use only, for household use only. To protect against the risk of
electrical shock, do not immerse the unit, cord or plug in water or other liquid.
Please unplug before cleaning and maintenance the appliance .Use a soft cloth moisten with
mild soap, and then use a dry cloth to wipe it again.
2
Installation Instruction
Electrical Shock Hazard
Disconnect electrical power before installing dishwasher.
Failure to do so could result in death or electrical shock.
The installation of the pipes and electrical equipments should be done by professionals.
For personal safety:
Do not use an extension cord or an adapter plug with this appliance.
Do not, under any circumstances, cut or remove the earthing connection from the power cord.
Electrical requirements
Please look at the rating label to know the rating voltage and connect the dishwasher to the
appropriate power supply. Use the required fuse 10A/13A/16A, time delay fuse or circuit breaker
recommended and provide separate circuit serving only this appliance.
Electrical connection
Ensure the voltage and frequency of the power being corresponds to those on the rating plate.
Only insert the plug into an electrical socket which is earthed properly. If the electrical socket to
which the appliance must be connected is not appropriate for the plug, replace the socket,
rather than using an adaptors or the like as they could cause overheating and burns.
WARNING: Ensure that proper earthing exists before use.
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will
reduce the risk of an electric shock by providing a path of least resistance of electric current.
This appliance is equipped with a cord having an equipment-earthing conductor and an
earthing plug.
The plug must be plugged into an appropriate outlet that is installed and earthed in
accordance with all local codes and ordinances.
Improper connection of the equipment-earthing conductor can result in the risk of an electric
shock. Check with a qualified electrician or service representative if you are in doubt whether
the appliance is properly earthed.
Do not modify the plug provided with the appliance; If it does not fit the outlet. Have a
proper outlet installed by a qualifiedelectrician.
3
Installation Instruction
Position the appliance
Position the appliance in the desired location. The back should rest against the wall behind it,
and the sides, along the adjacent cabinets or walls. The dishwasher is equipped with water
supply and drain hoses that can be positioned either to the right or the left sides to facilitate
proper installation.
Levelling the appliance
Once the appliance is positioned for levelling,
the height of the dishwasher may be altered via
adjustment of the screwing level of the feet.
In any case, the appliance should not be inclined
more than 2°.
Note: Only apply to freestanding dishwasher.
Water Supply and Drain
Cold water connection
Connect the cold water supply hose to a threaded 3/4(inch)
connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an
extended period of time, let the water run to make sure that
the water is clear. This precaution is needed to avoid the
risk of the water inlet to be blocked and damage the
appliance.
4
Installation Instruction
Connection of Drain Hoses
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the
sink, making sure to avoid bending or crimping it. The height of drain pipe must be less than
1000mm. The free end of the hose must not be immersed in water to avoid the back flow of it.
Please securely fix the drain hose in either position A or position B
How to drain excess water from hoses
If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly
into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable
container that is held outside and lower than the sink.
Water outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water drain hose is not kinked or squashed.
Extension hose
If you need a drain hose extension, make sure to use a similar drain hose.
It must be no longer than 4 meters; otherwise the cleaning effect of the dishwasher
could be reduced.
Syphon connection
The waste connection must be at a height less than 100 cm (maximum) from the bottom of
the dish. The water drain hose should be fixed.
5
Operating Instruction
Control Panel
Operation (Button)
1 Power Press this button to turn on your dishwasher, the screen
lights up.
2 Program Select the appropriate washing program, the selected
program indicator will be lit.
3 Delay Press the button to set the delay time, corresponding
indicator will be lit.
4 Extra Drying To dry dishes more completely.(It can only be used with
Intensive, ECO and 90 mins.)
5 Start/Pause To start the selected washing program or pause it when
the dishwasher is working.
6
Operating Instruction
Indicator
6 Program
indicator
Intensive
For heaviest soiled crockery, such as pots, pans,
casserole dishes and dishes that have been sitting
with dried food on them for some time.
7 Warning
indicator
ECO
For normally soiled loads, such as pots, plates,
glasses and lightly soiled pans, standard everyday
cycle.
90 mins
For lightly soiled plates and pans that need quick
wash.
Rapid
A shorter wash for lightly soiled loads that do not
need drying.
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher
is low on dishwasher rinse aid and requires a refill.
Program end
When the program is end, the indicator will be lit.
Water Faucet
If the “ ” indicator is lit, it means the water
faucet closed.
8 Delay time To show the delay time (3h/6h/9h).
7
Function of The Rinse Aid And Detergent
The rinse aid is released during the final rinse to prevent water from forming droplets on your
dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off
the dishes. Your dishwasher is designed to use liquid rinse aids.
WARNING: Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with
any other substances (e.g. Dishwasher cleaning agent, liquid detergent). This would damage
the appliance.
When to refill the rinse aid dispenser
Unless the rinse-aid warning light ( ) on the control panel
is on, you can always estimate the amount from the color of
the optical level indicator located next to the cap.
When the rinse-aid container is full, the indicator will be fully
dark. The size of the dark dot decreases
as the rinse- aid diminishes. You should never let
the rinse aid level be less than 1/4 full.
As the rinse aid diminishes, the size of the black dot on the rinse aid level indicator changes,
as illustrated below.
8
Filling The Rinse Aid Reservoir
1. Remove the rinse aid reservoir cap by
rotating it counterclockwise.
2. Carefully pour in the rinse-aid into its
dispenser, whilst avoiding it to overflow.
3. Close the rinse aid reservoir cap by
rotating it clockwise.
NOTE:
Clean up any spilled rinse aid with an
absorbent cloth to avoid excessive foaming
during the next wash.
Adjusting the rinse aid reservoir
9
