Attentions
1.Please check the gas source carefully whether gas source is accordant with the
label on the gas hob; Forbid to install or use wrong gas source;
2.The gas connector must use special rubber tube and replace it at least once every
year. It’s better to use the rubber tube with 1-1.5m. Don’t bend or squash rubber
tube. Forbid to use defective or aged rubber tube. Please pay attention to the
connection of rubber tube which must be fixed and locked by anchor ear to avoid
from fire or poisoning.
Warning: It must use special rubber tube to connect gas hob with gas source. (
For example, good quality of composited premier or butyronitrile rubber tube). Forbid
to use rubber tube made by normal rubber tube will react with ozone, liquid oil, etc. It
will make normal rubber tube aged or crack to leakage and cause fire.
3.Don’t rotate fixed screw nut connecting with inlet gas pipe arbitrary. It must be
tested leakage after rotating the direction or inlet gas pipe. (Method:paint tenuous
and neuter cleaning solution on the connecting part, then open the valve. If there is
air bladder, please close the valve and tighten screw nut; Test it again until there is
nothing leakage).
4. If use anti-deciduous metal soft tube, the operator must install this product strictly
according to manual instructions on the package of anti-deciduous metal soft tube.(It
must be installed by appointed professional operator and test leakage. (The testing
method refer to above).
3 4
5.The gas hob should be installed under good ventilated place, but don't allow to
ventilate by strong wind.
6.Don't allow to hide flame by baffle. Don't put flammable thing around gas hob.
And gas hob can't be used to dry wipe or clothes, etc.
7.Don't allow to touch pan standing, copper cover or cooktop during operation or
flame out right now because of still high temperature.
8.Don't beat cooktop strongly. Put on or put down gas hob lightly in order not to
destroy cooktop during moving or installation.
9.If find leakage of gas hob, turn off the gas immediately, open the window and
exchange the air. Prohibit exhasting air with fan, range hood or other appliances.
Don’t operate appliances knob avoiding from fume and fire, then contact our local after-
service office simultaneity.
10.The burner is on backfire when the gas hob whishes and its flame become weak,
turbid or other issue when using or igniting. Turn off the gas hob immediately. Check if
the burner cap, copper core are positioned correctly, cut down or turn off the damper,
and then reignite the gas hob a half minute later.
11.The ignition time should be less than 20 seconds every time avoiding from explode;
Please contact our local after-service office if failure ignition more than 5 times.
12.Forbid children to use gas hob avoiding from accident.
13.Don’t dissemble, maintain or repair the accessories by unprofessional person.
14.Make your head away from the burner when ignition. After operation, please turn off
gas valve or knob avoiding from accident.
15.During the operation, gas hob will become hot, please don’t touch hot part. Don’t put
metal tools on the cooktop, such as knife, fork or cap, because they maybe become hot.
Product Features
1.Please deal with battery properly if use up, avoiding from pollution.
2.This product use environmental-protection package and it’s recyclable, please deal
with package carefully to reduce waste.
3.If gas hob can’t be used again, it may something useful materials, please assist to
dispose or make up.
Statement
Gas Hob Gas Hob
1.Fashionable appearance: design clings to fashionable trend and comply with modern
kitchen;
2.Top grade of parts and durable quality, more safe and effective;
3.Pluse ignition with flame failure safety device, easy to operate;
4.Full air in flow, supply air from cooktop, flexible air door and abundant burning;
