INSTRUCTION MANUAL

Model GP-204

Portable Combustible Gas Monitor

The accompanying instrument is sold and serviced in the USA by RKI Instruments, Inc. Please contact RKI

Instruments for any follow up service needs, including questions, warranty issues, repairs, and spare parts

and sensors. Thank you for selecting this fine instrument for your use. With proper care and maintenance,

it will provide you with many years of reliable service.

Gas Detection For Life

RKI Instruments, Inc. •33248 Central Ave. Union City, CA •Phone (510) 441-5656 •(800) 754-5165 •Fax (510) 441-5650

World Leader In Gas Detection & Sensor Technology

www.rkiinstruments.com

1. GENERAL DESCRIPTION

The model GP-204 HAND HELD PORTABLE COMBUSTIBLE GAS DETECTOR is a compact battery

operated portable instrument used for taking an air sample and indicating the presence and concentration of

combustible gas. Samples of the air under test are drawn by means or a rubber aspirator bulb and analyzed

for combustible gas content on a heated platinum filament in a Wheatstone bridge measuring circuit. A

built-in meter indicates combustible gas content in units of explosibility. Power for operation or the

instrument is provided by two size “D” alkaline or Ni-Cad batteries. A probe and extension hose permit

withdrawal of samples from remote locations and the instrument fits in a compact leather case with over the

shoulder carrying strap. The model GP-204 is suitable and recommended for testing tanks, manholes,

vessels, pressure cylinders, pipelines, and other closed systems or confined spaces to determine presence

or absence of combustible gas. It is a valuable aid for safety of operations whenever combustible gases or

vapors are handled.

2. OPERATION

Before taking instrument on the job, check battery voltage. To check, put switch in VOLT ADJ position.

Meter should rise to the "CHECK" position near top of scale. Lift and turn VOLT ADJ control clockwise to

determine maximum voltage setting. If it cannot be set beyond mark, batteries need recharging or

replacement. Do not attempt to use instrument at all if voltage reading cannot be set up to mark.

If voltage is satisfactory, continue with the next steps of preliminary adjustment as follows:

A. Confirm operation of pilot light/meter illuminating lamp.

B. With sample inlet in fresh air, squeeze bulb several times to flush out any remaining gas.

C. Check zero setting by turning switch to ON position. Meter should read close to zero. Lift and

turn ZERO knob to bring reading to exactly 0.

D. Couple sampling hose to instrument inlet on left hand end, and connect probe to end of hose.

Hold finger over probe to block flow and squeeze bulb. Bulb should remain squeezed while finger

blocks inlet.

E. Admit a sample of some combustible gas to end of probe, and confirm that meter rises upscale.

Instrument is adjusted and ready to use. lt may be turned off and carried to the job.

To make a gas test, proceed as follows:

1) Turn to VOLT ADJ. position, adjust voltage if necessary, then turn to ON.

2) Hold probe within space to be tested. Squeeze bulb several times while watching meter, and

observe maximum reading.

3) After completion of test, remove probe from test space, flush with fresh air for 4 or 5 squeezes of

bulb, and turn off.

Gas Detection For Life

RKI Instruments, Inc. •33248 Central Ave. Union City, CA •Phone (510) 441-5656 •(800) 754-5165 •Fax (510) 441-5650

World Leader In Gas Detection & Sensor Technology

www.rkiinstruments.com

3. INTERPRETATION

Meter readings are taken on a scale graduated 0 - 100% LEL. The abbreviation L.E.L. stands for Lower

Explosive Limit, and represents the lowest concentration, which can be ignited by a source of ignition, hence

the lowest concentration which can produce an explosion. This quantity is also spoken of as the Lower

Flammable Limit (L. F. L.).

The model GP-204 is calibrated before shipment to read directly in percent L.E.L. of methane in air, based

on the known L.E.L. for methane of 5.0% by volume. That is, a 5.0% by volume will produce a reading of

100%, and smaller concentrations will read in proportion.

Other combustible gases will read in approximate terms of explosibility. For maximum accuracy, the unit

should be calibrated to the gas intended to be detected.

Concentrations may also be interpreted in terms of volume percent by multiplying the percent L.E.L. in the

sample (determined from the meter reading and the curve) by the published figure for L.E.L. in volume

percent. as noted on the curve. The maximum concentration allowable in a space where men are working

or where welding operations are carried out is primarily a matter of local regulation and of judgement based

on knowledge of conditions. A maximum reading of 10% or 20% is usually allowed. If 20% is selected, this

is often spoken of as a factor safety of 5, as the concentration must be increased five times before explosive

conditions are reached.

4. MAINTENANCE

A. Calibration and Adjustment

In addition to the normal operating controls found on the top panel, the following auxiliary controls are

available.

Calibration Potentiometer

This adjustment is used to set the meter reading to the desired level, while sampling a known

concentration or combustible gas. To access this adjustment, the top plate must be removed by

taking out the screws in each corner. The calibration potentiometer is a slotted-shaft control located

above the right upper corner of meter. Turn clockwise to increase meter reading.

B. Sensor replacement

The sensor assembly consists of an active filament and a similar but enclosed reference filament,

potted into a flame arrestor. It should be replaced if zero cannot be set within the range of the ZERO

ADJ., or if reading cannot be set high enough on a calibration gas sample using calibration

potentiometer. To replace:

1) Loosen the two panel hold-down screws. Remove and invert top panel.

2) With switch off, loosen (do not remove) the three screws holding the terminals for red,

black and white wires. Pull wires from terminals.

3) Remove the four screws holding the rectangular sensor plate. Pull out sensor and replace

with the new one in same position. Check that the gasket is in place on chamber before

installation of new sensor. Install wires on terminals as before.

4) Turn instrument on and adjust zero.

Gas Detection For Life

RKI Instruments, Inc. •33248 Central Ave. Union City, CA •Phone (510) 441-5656 •(800) 754-5165 •Fax (510) 441-5650

World Leader In Gas Detection & Sensor Technology

www.rkiinstruments.com

5) Recalibrate the new sensor using span gas.

C. Batteries

The model GP-204 is furnished with two standard size D batteries, either alkaline or Ni-Cad. These

batteries will give 4 to 5 hours of operating life before replacement or recharge.

When meter cannot be set as high as the "CHECK" line with switch in VOLT ADJ. position and VOLT

ADJ. knob all the way clockwise. batteries require replacement or recharging.

To replace batteries, remove instrument from leather case, and loosen the coin slotted captive screw

found in center of bottom plate. Remove plate, exposing batteries in their spring contact holders.

Pull old batteries out, and install new ones in the same position, observing polarity as marked on

holder.

D. Sample system

1) Hose

The hose used is teflon-lined, synthetic rubber jacketed, and immune to absorption or attack

by any combustible vapors or solvents. Keep hose clean and be sure that couplings make air

tight contact, checking occasionally by holding finger over hose inlet. Bulb should remain

flattened after squeezing if there is no leak. Extension hoses in various lengths are available.

2) Flame arrestor / Sensor assembly

The active filament is installed within a sintered bronze porous metal cup, which acts as a

flame arrestor to retain explosions that may occur when sampling explosive gas and air

mixtures. The flame arrestor is part of the sensor assembly, which may be removed by taking

out the four screws that hold the sensor plate. If the flame arrestor is dusty, wet, oily or

corroded, it must replaced by replacing the sensor assembly. Before reinstalling sensor in

instrument, be sure that the reaction chamber cavity and incoming lines are clean and dry.

E. Meter lamp

The meter lamp is on whenever the instrument is on, and provides illumination to permit meter

reading in dark places. If lamp fails, it should be replaced as follows:

Remove four screws holding top plate to the top panel. Take off top plate exposing lamp. Loosen

set screws, which lock lamp wires to terminals, and pull lamp out. Install new lamp in the same

position.

5. PRECAUTIONS AND NOTES ON OPERATION

A. Heated samples

When sampling spaces such as hot tanks that are warmer than the instrument, remember that

condensation can occur as the sample passes through the cool sample line. Water vapor condensed

in this way can block the flow system and corrode the flame arrestor. A water trap can be used to

control this, and is available as an accessory.

If heated hydrocarbon vapors of the heavier hydrocarbons (flash point 90° F or above) are present,

they may also condense in the sample line and fail to reached the filament. Thus an erroneous low

reading may be obtained.

B. Element poisoning

Gas Detection For Life

RKI Instruments, Inc. •33248 Central Ave. Union City, CA •Phone (510) 441-5656 •(800) 754-5165 •Fax (510) 441-5650

World Leader In Gas Detection & Sensor Technology

www.rkiinstruments.com

Certain substances have the property of desensitizing the catalytic surface of the platinum filament.

These substances are termed “catalyst poisons” and can result in reduced sensitivity or in failure to

give a reading on samples containing combustible gas. The most commonly encountered catalyst

poisons are silicone vapors, and samples containing such vapors even in small proportions should be

avoided.

Occasional calibration checks on known gas samples are necessary, especially if the possibility

exists of exposure to silicones. A calibration check on a known methane gas concentration is the

most dependable as an indication of normal sensitivity. A convenient calibration kit is available and

described under “Accessories”.

C. Rich mixtures

When high concentrations of gas are sampled, especially those above the considerable heat is

liberated at the filament. This heat may cause damage to the filament or tend to shorten its life, so

sustained testing of samples beyond the meter range should be avoided. When sampling rich

mixtures, the following instrument action may be expected:

1) Mixtures up to 100% L.E.L. reading on scale.

2) Mixtures between L.E.L. and Upper Explosion Limit (U.E.L.) readings at top of meter.

3) Mixtures above U.E.L. - As sampling continues the meter first goes to top of scale, then

comes back down on scale, depending upon concentration.

4) Oxygen deficient mixtures

Samples which do not have the normal proportion of oxygen may tend to read low, if there is

not enough oxygen to react with all combustible gas present in the sample.

As a general rule, samples containing 10% oxygen or more have enough oxygen to give a full

reading on any combustible gas sample up to the L.E.L.

5) Oxygen - Enrich mixtures

Sample having more than the normal proportion or oxygen will give a normal reading.

However, they should be avoided because the flame arrestor used is not dense enough to

arrest flames from combustible gas in oxygen, which can be much more intense than those in

air. DO NOT ATTEMPT TO USE THE MODEL GP-204 ON SAMPLES OF COMBUSTIBLE

GAS IN OXYGEN.

Instruments for measurement of oxygen concentration are available from RKI Instruments Inc.

6. ACCESSORIES

A. Extension hoses

Additional lengths of hose may be used for sampling from deep tanks and manholes. The

polyurethane hoses are satisfactory for most samples including natural gas, hydrogen, propane, and

gasoline vapors.

B. Water trap (Option)

Where there is danger or water being drawn into the instrument, a water trap should be used. This

glass bodied trap with sintered metal filter couples to indicator inlet and will collect water that is drawn

into or condensed in the sample hose. Inspect trap periodically while in use, and empty or clean

Gas Detection For Life

RKI Instruments, Inc. •33248 Central Ave. Union City, CA •Phone (510) 441-5656 •(800) 754-5165 •Fax (510) 441-5650

World Leader In Gas Detection & Sensor Technology

www.rkiinstruments.com

bowl and filter whenever visible water or dust accumulate. Regular sample hoses connect to inlet of

trap when it is installed on instrument.

7. PARTS LIST

The foIIowing parts are considered as normal repair or replacement items (Option) and may be ordered

separately, by description and number. Always specify model and serial number of instrument for which

parts and accessories are required. For problems with parts not listed, write RKI Instruments Inc. for

information or request shipping instructions for return or the instrument for repair.

Part Number Description

30-0401RK Aspirator bulb

49-1140RK Battery, size D, Alkaline

49-1240RK Battery, size D, Ni-Cad

62-0110RK Sensor / flame arrestor assembly

80-0150RK Sampling probe, 10”, plastic

80-0001RK Hose, 1 m teflon-lined, complete with couplings

80-0002RK Hose, 2 m teflon-lined, complete with couplings

80-0007RK-10 Hose, 10 ft. polyurethane, complete with couplings

80-0007RK-15 Hose, 15 ft. polyurethane, complete with couplings

80-0007RK-20 Hose, 20 ft. polyurethane, complete with couplings

80-0007RK-30 Hose, 30 ft. polyurethane, complete with couplings

0-0220RK Water trap

81-GP204 Cal Kit for GP-204, 2.5% Methane in Air

Gas Detection For Life

RKI Instruments, Inc. •33248 Central Ave. Union City, CA •Phone (510) 441-5656 •(800) 754-5165 •Fax (510) 441-5650

World Leader In Gas Detection & Sensor Technology

www.rkiinstruments.com

Product Warranty

RKI Instruments, Inc. warranties gas alarm equipment sold by us to be free from defects in materials,

workmanship, and performance for a period of one year* from the date of shipment from RKI Instruments,

Inc. Any parts found defective within that period will be repaired or replaced, at our option, free of charge.

Parts must be returned to RKI Instruments, Inc. for repair or replacement. This warranty does not apply to

those items which by their nature are subject to deterioration or consumption in normal service, and which

must be cleaned, repaired or replaced on a routine basis.

Examples of such items are:

a) Pump diaphragms and valves

b) Fuses

c) Batteries

d) Filter elements

Warranty is voided by abuse including mechanical damage, alteration, rough handling, or repair procedures

not in accordance with instruction manual. This warranty indicates the full extend of our liability, and we are

not responsible for removal or replacement costs, local repair costs, transportation costs, or contingent

expenses incurred without our prior approval.

THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER WARRANTIES AND

REPRESENTATIONS, EXPRESSED OR IMPLIED, AND ALL OTHER OBLIGATIONS OR LIABILITIES ON

THE PART OF RKI INSTRUMENTS, INC. INCLUDING BUT NOT LIMITED TO, THE WARRANTY OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL RKI

INSTRUMENTS, INC. BE LIABLE FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL LOSS OR

DAMAGE OF ANY KIND CONNECTED WITH THE USE OF ITS PRODUCTS OR FAILURE OF ITS

PRODUCTS TO FUNCTION OR OPERATE PROPERLY.

This warranty covers instruments and parts sold to users only by authorized distributors, dealers and

representatives as appointed by RKI Instruments, Inc.

We do not assume indemnification for any accident or damage caused by the operation of this gas monitor

and our warranty is limited to the replacement of parts or our complete goods. Warranty covers parts and

labor performed at RKI Instruments, Inc. only, and does not cover field labor or shipment of parts back to

RKI.

* The Models GX-2001 and GasWatch 2 carry a two year warranty. The two year warranty applies to the

instrument including original sensors. Replacement parts and sensors have a standard one year warranty.

Table des matières

Autres manuels RKI Instruments Détecteur de gaz

RKI Instruments

RKI Instruments GD-70DST Manuel utilisateur

RKI Instruments

RKI Instruments 65-2495RK Manuel utilisateur

RKI Instruments

RKI Instruments GasWatch 3 Manuel utilisateur

RKI Instruments

RKI Instruments 61-1006RK Manuel utilisateur

RKI Instruments

RKI Instruments GasWatch 2 Manuel utilisateur

RKI Instruments

RKI Instruments 35-3001A-05 Series Manuel utilisateur

RKI Instruments

RKI Instruments 35-3010RK-07 Manuel utilisateur

RKI Instruments

RKI Instruments 65-2437RK-05 Manuel utilisateur

RKI Instruments

RKI Instruments VOC Pro Manuel utilisateur

RKI Instruments

RKI Instruments GX-3R Pro Manuel utilisateur

RKI Instruments

RKI Instruments RI-600 Manuel utilisateur

RKI Instruments

RKI Instruments 65-2438 Manuel utilisateur

RKI Instruments

RKI Instruments 65-2380 Manuel utilisateur

RKI Instruments

RKI Instruments SD-1GH Manuel utilisateur

RKI Instruments

RKI Instruments AirLink 7032 Manuel utilisateur

RKI Instruments

RKI Instruments 65-2422RK-05 Manuel utilisateur

RKI Instruments

RKI Instruments 35-3001-01 Manuel utilisateur

RKI Instruments

RKI Instruments CO-01 Manuel utilisateur

RKI Instruments

RKI Instruments GX-2009 Manuel utilisateur

RKI Instruments

RKI Instruments 72-2102-07 Manuel utilisateur

RKI Instruments

RKI Instruments Beacon 3200 Manuel utilisateur

RKI Instruments

RKI Instruments GX-82A Manuel utilisateur

RKI Instruments

RKI Instruments EAGLE 2 Manuel utilisateur

RKI Instruments

RKI Instruments AirLink 9850 Manuel utilisateur

Manuels Détecteur de gaz populaires d'autres marques

Macurco

Macurco GD-6 Manuel utilisateur

Evikon

Evikon E2632 Manuel utilisateur

Critical Environment Technologies

Critical Environment Technologies CGAS-A Series Manuel utilisateur

MSA

MSA altair 5 Manuel utilisateur

DOD Technologies

DOD Technologies ChemLogic CL96 Manuel utilisateur

DEGA

DEGA NS III LCD Series Manuel utilisateur

PEMTECH

PEMTECH PT2008 Series Manuel utilisateur

Coster

Coster RGS 328 Manuel utilisateur

Sygonix

Sygonix 2483186 Manuel utilisateur

Perry

Perry 1GA 50917MET/P Manuel utilisateur

isweek

isweek AS8900 Manuel utilisateur

Oldham

Oldham OLC 10 Manuel utilisateur

Wizmart

Wizmart NB983 Manuel utilisateur

Beacon

Beacon MEGA Manuel

RKI

RKI GX-6000 Manuel utilisateur

Dräger

Dräger PIR 7000 Manuel utilisateur

GDS

GDS GASMAX EC Manuel utilisateur

Seitron

Seitron BE COOL R1 Manuel utilisateur
