RIP TUNES MP1898 Manuel utilisateur
Digital Music
Player (MP3/MP4)
User Manuel
Manuel d’usario
Mode d’emploi
Model: MP1898
Music
EN
ES
FR
2
INTRODUCTION
Thank you for purchasing this quality RipTunes digital music player. Please
read all the operating instructions before operating the unit and keep this
manual in a safe place for later consultation.
UNIT SPECIFICATIONS
• 1.8" 128x160 color screen
• 8GB internal storage capacity
• MicroSD card expansion slot
• MP3/WMA/WAV audio format support
• AMV video format support
• ID3 tag support
• Lyric le support
• FM radio built-in
• EQ modes and repeat functions
• Integrated microphone for audio recordings
• TXT le reader
• Digital photo album
• Multi-lingual menus
EN
ES
FR
3
UNIT OVERVIEW
1. Power switch
2. M: select button; press and hold to return to
main menu
3. : select the previous menu or option; press & hold
to rewind
4. : select the next menu or option; press & hold
to fast forward
5. : press to play or press to pause; press & hold
to place unit in standby mode
6. Vol +/–: Press to increase (+) or decrease (–) play-
back volume
Note: press and hold implies keeping the button depressed for more than
1.2 seconds.
Music
1
2
5
6
3 4
EN
ES
FR
4
BASIC OPERATION
Power on/o
1. Slide the power on/o button or press and hold the button to turn
the player on or o.
Note: The player standby time setting will automatically turn o your player
after a certain lapse of inactivity. You can modify this setting. While the music
player is connected to a computer, the standby function is temporarily disabled.
Low battery
1. The player display will show a low battery alert.
2. Plug in your player to recharge as soon as possible.
Note: If your digital music player has insucient power it will automatically
turn o to prevent damage to the electronics.
Expansion card
1. Gently insert a MicroSD card by lightly pressing on the rear edge of the
card.
2. To remove the MicroSD card, lightly press on the card and the card will
come out partially. Gently pinch the card and pull away from the player
to remove it completely.
EN
ES
FR
5
PLAYER FUNCTIONS
Main menu
1. Press and hold the Mbutton to access the main menu.
2. Use the & buttons to select between the following functions:
• Music
• Videos
• Recordings
• Voice recorder
• FM radio
• Photos
• Settings
• Reader
MUSIC MODE
1. Select MUSIC in the main menu.
2. Use the and buttons to browse through song les.
3. Use the Mbutton to select a folder.
4. Press the button to begin or pause music playback with the select-
ed song.
EN
ES
FR
6
Playback settings
During music playback, press the Mbutton to adjust the following playback
settings:
• Repeat modes: Choose normal playback, repeating a single track, folder
playback, repeat all songs in a folder, repeat all songs, shue, and intro
(plays the rst several seconds of every song). The chosen mode will be
indicated on the top of the screen in a red icon during play.
• Equalizer: Choose between Natural, Rock, Pop, Classic, Soft, Jazz, & DBB
(Dynamic Bass Boost) equalizer settings. You can hear the changes to
the music as you scroll through the selections.
• Variable play speed: “0” is normal. You can slow the song down (up to
“–8”) or speed it up (up to “+8”)
• Replay mode: This feature allows you to play just part of a song (from
“point A” to “point B”) in a loop. Begin by selecting the replay options,
before you select the part of the song you want to replay. Select “Replay
Times” to choose how many times you want that section of the song re-
peated (from 1 to 10). Select “Replay gap” to choose how many seconds
to pause between each replay (from 1 to 10). Select “Replay.” The letter
“A” will begin ashing in the upper-left-hand corner of the screen. When
you reach the point in the song that you want to begin from, press the
button. The letter “B” will begin ashing in the upper-left-hand corner of
EN
ES
FR
7
the screen. When you reach the point in the song that you want to end
with, press the button.
• Exit: Exit the playback setting sub-menus
Lyric les
Your music player can display lyrics during MP3 playback. Ensure that the
LRC lyric le and the MP3 le have the exact same name and are in the same
folder. Example: "My Moon My Man.mp3" and "My Moon My Man.lrc".
To display the lyrics during playback, press and hold the Mbutton.
Managing music les
While music playback is stopped, press the M button to manage your music les.
• Local folder: Displays the current music playback folder name & location.
Use the , , and Mbuttons to navigate through the directory struc-
ture on the unit. This works in a similar manner
• Delete le/delete all: Delete one or all songs from the music directory
• Repeat modes: Choose normal playback, repeating a single track, folder
playback, repeat all songs in a folder, repeat all songs, shue, and intro
(plays the rst several seconds of every song).
• Exit: Exit the le management sub-menu
EN
ES
FR
8
VIDEO MODE
1. Select VIDEOS in the main menu.
2. Use the and buttons to browse through .AMV video les.
3. Use the Mbutton to change folders.
4. Press the button to begin or pause video playback with the selected
video.
Managing video les
While video playback is stopped, press the Mbutton to manage your videos.
• Local folder: Displays the current video playback folder name & location.
• Delete le: Delete one video from the video directory
• Delete all: Delete all videos
• Repeat modes: Choose normal playback, repeating a single video, folder
playback, repeat all videos in a folder, repeat all videos, shue, and intro
(plays the rst several seconds of every video). The chosen mode will be
indicated on the top of the screen in a red icon during play.
• Exit: Exit the le management sub-menu
EN
ES
FR
9
VOICE RECORDER
1. Select recorder in the main menu.
2. Press to begin recording.
3. To stop recording & save the recording le, press & hold the Mbutton.
Recording options
Before recording, press the M button to enter the voice recorder congura-
tion sub-menu.
• Local folder: Choose the folder where your recording will be stored.
• REC type: Choose the quality of the recording; higher bitrate numbers
are better for music recordings while lower numbers are acceptable for
voice recordings.
• Exit: Exit the voice recorder conguration sub-menu.
RECORDINGS
1. Select recordings in the main menu to listen to your saved voice recordings.
2. Use the & buttons to browse through the saved voice recordings.
3. Press the button to begin or pause audio playback of the selected re-
cording.
EN
ES
FR
10
Managing recording les
While recording playback is stopped, press the Mbutton to manage your
recordings.
• Local folder: Displays the current recording playback folder name and
location.
• Delete le: Delete one recording from the directory of les
• Delete all: Delete all voice recordings
• Exit: Exit the le management sub-menu
FM RADIO
1. Start the FM tuner by selecting FM RADIO in the main menu.
2. Tune between stations either manually or automatically:
• Manual tuning: use the or button to scan frequencies one by one.
• Automatic tuning: press and hold the or button; the tuner will
automatically scan frequencies, decreasing or increasing based on the
button used. Once a station is detected, the tuner stops scanning.
