Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

DEMAND DUO LITE

(DD180 and DD340)

Operation and Installation Manual

DDLT160E180L, DDLT160E180N, DDLT160E340L and DDLT160E340N

External installations only.

Not suitable or approved as a pool heater.

Appliance must be installed, commissioned and serviced by a licensed tradesperson in

accordance with these instructions and all applicable local rules and regulations.

Customer, please retain this manual for future reference.

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

RINNAI LIMITED WARRANTY

Warranty Summary Table and General Warranty Terms

Rinnai Continuous

Flow Water Heater

Demand Duo Lite Tank

Domestic Applications

Heat Exchanger and Tank Parts 10 years pro rata 5 years

Labour 3 years 3 years

All Other Parts (pump, thermostat etc) Parts 3 years 1 year

Labour 3 years 1 year

Commercial Applications

Heat Exchanger and Tank Parts 5 years pro rata 3 years

Labour 3 years 1 year

All Other Parts (pump, thermostat etc) Parts 3 years 1 year

Labour 3 years 1 year

All terms of the warranty are effective from the date of installation of the Rinnai Demand Duo

system. Rinnai New Zealand Limited (Rinnai) reserves the right to verify this date.

Domestic vs. Commercial Application

The reason for distinguishing between a domestic and commercial application is because the

expected life of a system is directly related to the hours of use.

A domestic application is dened as an installation that serves a single residential dwelling

which is not used for commercial purposes, such as a hair salon, catering kitchen, motel or

communal care facility.

All other installations are dened as a commercial application.

General Warranty Terms

Rinnai reserves the right to make modications and change specications and its parts without

notice.

For the purposes of the Consumer Guarantees Act 1993, Rinnai only guarantees the availability

of repair facilities and spare parts for the express warranty periods recorded in the Rinnai

Warranty Summary Table.

If the Rinnai Demand Duo system is being acquired for personal, domestic or household

use, this warranty does not limit any consumer rights or guarantees that may apply under

the Consumer Guarantees Act 1993. If the product is being acquired for the purposes of a

business, the provisions of the Consumer Guarantees Act 1993 do not apply and no other

warranties (either express or implied by law) apart from those stated in this warranty apply.

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

RINNAI LIMITED WARRANTY

Warranty Terms for Rinnai Continuous Flow Water Heater

Extended Warranty for Rinnai Continuous Flow Water Heater Heat Exchanger

The parts warranty on heat exchangers in a Rinnai continuous ow water heater installed for

domestic use is 10 years pro rata (i.e. in the 4th year, 70% of the value of the part is covered

by the warranty and 40% of the value of the part is covered by warranty in the 7th year).

For Rinnai continuous ow water heater units installed for commercial use the parts warranty

for the heat exchanger is 5 years pro rata (i.e. in the 4th year, 40% of the value of the part is

covered by the warranty and 20% of the value of the part is covered by the warranty in the

5th year).

This warranty is subject to Terms and Conditions below.

All other parts and labour for the Rinnai continuous ow water heater are covered for 3 years

in accordance with the Terms and Conditions below.

Rinnai Continuous Flow Water Heater Warranty - Terms and Conditions

During the warranty period and subject to clauses 2 and 3 below, Rinnai will, at its own

discretion, either replace or repair any defective product at no charge to the customer.

This warranty covers manufacturing defects only. This warranty will not apply (for example)

if the Rinnai continuous ow water heater has been improperly installed or is otherwise

installed contrary to manufacturer’s recommendations, has been damaged during or

after installation, or has been subjected to damage or abuse beyond that expected from

conditions of normal use.

Warranty claims may be invalid if not accompanied by details of the installing or

supervising gas tters registration number and the gas tting certication number.

This warranty commences from the date of installation. Proof of purchase is required at the

time of the warranty claim.

Servicing of the Rinnai continuous ow water heater is to be carried out by a Rinnai

authorised service centre.

Water Quality for Rinnai Continuous Flow Water Heater

Water quality outside the maximum recommended limits (as set down below) will void this

warranty. Water quality tests must be carried out at the customer’s own cost but Rinnai will

reimburse any reasonable test costs if the product is found to be defective.

Water chemistry and impurity limits are detailed in the table below. Most metropolitan water

supplies fall within these requirements. If you are unsure about water quality, contact your

water authority. If sludge or foreign matter is present in the water supply, a suitable lter

should be incorporated.

Water Quality Limits - Standard Rinnai Continuous Flow Water Heater

TDS (Total

Dissolved

Solids)

Total

Hardness

CaCO3

Alkalinity

(as CaCO3)

Dissolved

(free) CO2

pH Chlorides Magnesium Sodium Iron Langelier

Index

Up to 600mg/litre

or ppm

Up to 200mg/

litre or ppm

Up to

200mg/litre

or ppm

Up to 25mg/

litre or ppm

6.5 to 8.5 Up to

300mg/litre

or ppm

Up to 10mg/

litre or ppm

Up to

150mg/litre

or ppm

Up to

1mg/litre

or ppm

Between

-1.0 and 0.8

Examples of water quality issues where water may need to be treated:

Hard water (Wanganui)

Aggressive water (some areas of Christchurch)

Both hard and aggressive water (some bore water)

•

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

RINNAI LIMITED WARRANTY

Please keep these instructions in a safe place for future reference.

RECORD AND ATTACH YOUR PROOF OF PURCHASE BELOW:

Your Retailer:__________________________________________________

Name:________________________________________________________

Address:______________________________________________________

_____________________________________________________________

Telephone:( _______ ) __________________________________________

Date of Purchase: ______ / ______ / _________

Warranty Terms for Demand Duo Lite Tanks

In Relation to Storage Tanks

The following exclusions apply:

Accessibility - Where the cylinder is not easily accessible for maintenance and replacement,

this warranty will not cover any additional costs caused by access difculty.

Leaks - To the fullest extent permitted by law, this warranty does not cover any

consequential loss resulting from leaks to a cylinder. Accordingly it is important that a

suitably drained catch pan is tted where damage could be caused by discharge from the

cylinder.

•

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

Contents

WARNING

Improper installation, adjustment, alteration, service or maintenance

can cause property damage, personal injury or loss of life.

For assistance or additional information contact Rinnai on 0800

RINNAI (0800 746 624).

Customer Information

Limited Warranty 2

Introduction 6

For Your Safety 7

Maintenance 8

Servicing 9

Troubleshooting 9

Installation Information

General - Before Installation 10

General - Location 10

Specication 11

Connections 12

Filling and Draining 13

Commissioning 14

Thermostat 14

Pump 15

Customer Contacts 16

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

Customer Information - Introduction

This manual has been written to:

Help you understand how your Demand Duo Lite operates

Identify what you need to do to maintain your Demand Duo Lite system

Assist in troubleshooting in the unlikely event a problem occurs

Some facts about your Demand Duo Lite system

•

How it works The thermostat senses the temperature of the water in the tank, and when

it drops below the set point, the primary pump is activated. This ow starts

the Rinnai continuous ow water heater which returns heated water to the

tank.

Safety devices For safe operation the tank component of your system is tted with a:

Temperature Pressure and Relief (TPR) Valve that ensures the water

remains at a safe pressure and temperature

Automatic tank thermostat to maintain water temperature, do not

adjust the thermostat which is set to 65 °C

It is important that you do not tamper with or remove these devices. In the

case of the TPR valve, do not block or seal the valve or drain pipe.

•

Anode The tank is tted with a sacricial anode designed to extend the life of the

tank. It will slowly dissipate protecting the cylinder and should be changed

every 5 years (more frequently in hard/aggressive water areas).

Space should left above the cylinder to allow anode replacement.

Reset timer Your system is equipped with a reset timer to ensure the pump does not

run continuously. This may occur if for some reason the Rinnai continuous

ow water heater does not ignite.

The timer will shut off the pump every 15 minutes for a few seconds to

ensure the continuous ow water heater resets itself.

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

Customer Information - For Your Safety

Scald Hazard Hot water can cause scalds

Children, elderly and disabled are the highest at risk of being scalded

Feel the water temperature before bathing or showering

Scalds from hot water taps can result in severe injuries

Scalds can occur when children are exposed directly to hot water when

they are placed into a bath which is too hot

•

Hydrogen Gas If the hot water is not used for 2 weeks or more, a quantity of hydrogen

gas which is highly ammable, may accumulate in the storage tank.

To dissipate this safely, it is recommended a hot tap (non electrical) be

turned on for 2 minutes at a sink, basin or bath. During this procedure

there must be no smoking, open ame or any other appliance operating

nearby.

If hydrogen is discharged through the tap, it will make a sound like air

escaping.

Safety Devices

WARNING

Your system is supplied with various safety devices including temperature

sensors, overheat sensors/switches and a Temperature & Pressure Relief

(TPR) valve.

Do Not:

Tamper or remove safety devices

Block or seal the TPR and drain pipe

Operate the system unless all safety devices are tted and in working

order

•

Legionella

Protection

Your system has been preset with specic temperature settings to disinfect

water for Legionella. Do not adjust these unless instructed by an authorised

person.

Flue Outlet of

Water Heater

Do not touch or insert any objects in the ue outlet.

Keep ammable materials, spray cans, fuel containers, trees, shrubs, pool

chemicals etc clear of the ue outlet.

If ue product discharge causes annoyance, an upwards or sideways ue

diverter can be purchased as an accessory.

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

Customer Information - Maintenance

Your Rinnai Demand Duo Lite requires little maintenance, but for maximum performance the

following is recommended.

Temperature &

Pressure Relief

Valve (TPR)

Normally only occurs during installation or servicing and must be carried

out by an authorised person.

Draining and ushing the cylinder on a yearly basis is recommended if

the water supply contains excessive levels of silt.

This valve is located near the top of the tank and is essential for safe

operation. Every 6 months operate the easing gear to ush the valve. As

this will discharge hot water, ensure no one is near the drain line.

It is very important that you raise and lower the easing gear gently.

During this operation, if the valve does not discharge water when the

easing gear is lifted, or does not seal again when closed, attendance by

an authorised person must be arranged immediately.

lift until water ows

from drain line,

lower gently

During servicing the TPR valve needs to be checked and/or replaced.

This needs to be done by an authorised person at intervals not

exceeding 5 years, or more frequently in areas where the water is

classied as hard.

Draining and

ushing of the

cylinder

Inlet water lter should be cleaned regularly.

Rinnai continuous

ow water lter

Storage tanks manufactured from metal can be susceptible to corrosion.

The combined effects of water pressure, temperature and water

chemistry can create an aggressive environment for corrosion of some

materials. For this reason anodes are placed in glass lined tanks so as to

corrode rst. They should be changed every 5 years (more frequently in

hard/aggressive water areas).

Anodes in glass

lined tanks

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

Customer Information - Servicing

Rinnai has a service and spare parts network with personnel who are fully trained

and equipped to give the best advice on your Rinnai system. If your Demand Duo

Lite needs servicing, please call Rinnai (0800 746 624) from your land line and select

option 1 for a service centre in your area.

For reliable operation Rinnai recommends regular servicing of the Demand Duo system.

Regular servicing is not covered by the Rinnai warranty.

If any electrical component of the system is damaged, it must be replaced by an authorised

person. These components must be a genuine replacement part available from Rinnai.

Do not attempt to carry out any service work other than mentioned in the troubleshooting

section. If you have any other faults or problems, please refer to your installer or call Rinnai.

Customer Information - Troubleshooting

Lack of hot water or no hot water

Is there electricity

to the system?

Check isolating switches and electrical connections to ensure everything

is turned on.

Check the fuse or circuit breakers at the meter box. Repeated failure

of a fuse or tripping of a circuit breaker indicates a fault which must be

investigated by a licensed tradesperson.

Cold Water Relief

Valve discharging

continuously?

It’s normal for the Cold Water Relief Valve to discharge a small quantity

of water through the drain line. If water is discharging continuously

there may be a fault with one of the valves, contact your installer to

discuss.

High electricity/gas bills

If you think your electricity/gas bill is too high, investigate the following:

There may have been a change to your tariffs since your last bill

Cold Water Relief Valve is discharging continuously, refer above

You may be using more hot water than you think

There may be hot water pipe/tap leakages, check with your local plumber

The tank thermostat may not be set to 65 °C

•

Is the gas on? If the gas supply has been interrupted the water heater will display er-

ror code 11 or 12. Turn off the power to the system, wait 10 seconds

before turning on again.

Rinnai New Zealand Demand Duo Lite Operation/Installation: 11451-A

01-09

Installation Information - General

Before installation

Unpack the appliance and components and check for damage. DO NOT install any

damaged items.

Check all components have been supplied and that you have the correct gas type.

Read these instructions to get an overview of the steps required before starting the

installation. Failure to follow these instructions could cause a malfunction of the system.

This could result in serious injury and property damage.

The cylinder should be installed to AS/NZS3500.4, with reference to G12/AS1 where

appropriate.

Base requirements

Access to system

Catch pan

Flue clearance

Electricity

The cylinder should be installed on a at level base of sufcient

strength to support the weight of the water heater when full. It must

also be restrained against seismic activity.

The Demand Duo Lite system should not be located where it will

be difcult to remove. Where a system is not easily accessible for

maintenance and replacement, the Rinnai Warranty will not cover any

additional costs caused by access difculty.

It’s important a suitably drained catch pan is tted where damage

could be caused by discharge from the cylinder.

This is a power ued appliance and ue clearances must comply

with NZS:5261, “Table 16 - Minimum clearances required for ue

terminals”.

A single 10 amp outdoor power point is required adjacent to the

installation.

Location

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Rinnai Chauffage

Rinnai

Rinnai ES750 Manuel utilisateur

Rinnai

Rinnai 37AHA04508KA5 Manuel utilisateur

Rinnai

Rinnai Energysaver RHFE-1004FDT Mode d'emploi

Rinnai

Rinnai RHFE-556 FM Manuel utilisateur

Rinnai

Rinnai SPECTRUM 28 REH281 EB Manuel utilisateur

Rinnai

Rinnai ES38 RHFE-1004RFA Manuel utilisateur

Rinnai

Rinnai FC510 Manuel utilisateur

Rinnai

Rinnai RCE-606TRA II Guide de démarrage rapide

Rinnai

Rinnai RHFE-556FTR Manuel utilisateur

Rinnai

Rinnai rhfe-556ftp Manuel utilisateur

Rinnai

Rinnai RCE-460PTR Manuel utilisateur

Rinnai

Rinnai Energysaver 309FT Manuel utilisateur

Rinnai

Rinnai FC824 Manuel utilisateur

Rinnai

Rinnai ORH15S Manuel utilisateur

Rinnai

Rinnai ORH15SR Manuel utilisateur

Rinnai

Rinnai RCE-329A Guide de démarrage rapide

Rinnai

Rinnai RHFE-551FT Guide de démarrage rapide

Rinnai

Rinnai ENERGYSAVER RHFE-308FTR Mode d'emploi

Rinnai

Rinnai RHFE-556FTR Fiche technique

Rinnai

Rinnai RHE1S40N Manuel utilisateur

Rinnai

Rinnai FS35ETRN Guide de démarrage rapide

Rinnai

Rinnai Granada 252 Manuel utilisateur

Rinnai

Rinnai RHFE-309FT Fiche technique

Rinnai

Rinnai RHFE-559FDT / FT Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
