Rigol DS1102E Manuel utilisateur

Quick Guide RIGOL

Publication Number QGA07116-1110

Jun 2013

DS1000E, DS1000D Series

Digital Oscilloscope

DS1102E, DS1052E, DS1102D, DS1052D

RIGOL

Quick Guide for DS1000E, DS1000D Series I

RIGOL products are protected by patent laws in and outside of

the P.R. China.

Information in this publication replaces all previous

corresponding material.

RIGOL reserves the right to modify or change part of or all the

specifications and pricing policies at company’s sole decision.

NOTE:

RIGOL is registered trademark of RIGOL Technologies, Inc.

RIGOL

Quick Guide for DS1000E, DS1000D Series

Safety Notice

Review the following safety precautions carefully to avoid any

personal injuries or damages to the instrument and any products

connected to it. To avoid potential hazards, please use the

instrument as specified by this manual only.

The instrument should be serviced by Authorized personnel

only.

To Avoid Fire or Personal Injury.

Use Proper Power Cord. Use the power cord designed for the

instrument and authorized in your country only.

Connect and Disconnect Logic Analyzer. Do not connect or

disconnect logic Analyzer while the instrument is powered on.

Ground The Instrument. The oscilloscope is grounded through

the grounding conductor of the power cord. To avoid electric shock

the instrument, grounding conductor(s) must be grounded properly,

before making connections to the input or output terminals of the

instrument.

Connect The Probe. The probes’ ground terminals are at the

same voltage level of the instrument ground. Do not connect the

ground terminals to a high voltage.

Observe All Terminal Ratings. To avoid fire or shock hazard,

observe all ratings and marks on the instrument. Follow the user’s

guide for further ratings information before making connections to

the instrument.

Do Not Operate Without Covers. Do not operate the instrument

with covers or panels removed.

Avoid Circuit or Wire Exposure. Do not touch exposed

connections and components when power is on.

Do Not Operate With Suspected Failures. If suspected damage

occurs with the instrument, have it inspected by qualified service

RIGOL

Quick Guide for DS1000E, DS1000D Series III

personnel before further operations.

Provide Proper Ventilation. Refer to the installation instructions

for proper ventilation of the instrument.

Do Not Operate in Wet/Damp Conditions.

Do Not Operate in an Explosive Atmosphere.

Keep Product Surfaces Clean and Dry.

The disturbance test of all the models meet the limit values

of A in the standard of EN 61326: 1997+A1+A2+A3, but

can’t meet the limit values of B.

Measurement Category

The DS1000E, DS1000D series Digital Oscilloscope is intended to be

used for measurements in Measurement Category I.

Measurement Category Definitions

Measurement Category I is for measurements performed on circuits

not directly connected to MAINS. Examples are measurements on

circuits not derived from MAINS, and specially protected (internal)

MAINS derived circuits. In the latter case, transient stresses are

variable; for that reason, the transient withstand capability of the

equipment is made known to the user.

WARNING

IEC Measurement Category I. The input terminals may be

connected to circuit terminal in IEC Category I installations for

voltages up to 300Vrms. To avoid the danger of electric shock, do

not connect the inputs to circuit’s voltages above 300Vrms.

Transient overvoltage is also present on circuits that are isolated

from mains. The DS1000E, DS1000D series Digital Oscilloscopes is

designed to safely withstand occasional transient overvoltage up to

1000Vpk. Do not use this equipment to measure circuits where

transient overvoltage could exceed this level.

RIGOL

Quick Guide for DS1000E, DS1000D Series

Safety Terms and Symbols

Terms in This Guide. These terms may appear in this manual:

WARNING: Warning statements indicate the conditions

or practices that could result in injury or loss of life.

CAUTION: Caution statements indicate the conditions or

practices that could result in damage to this product or

other property.

Terms on the Product. These terms may appear on the product:

DANGER indicates an injury or hazard that may be immediately

happen.

WARNING indicates an injury or hazard that may be not

immediately happen.

CAUTION indicates that a potential damage to the instrument or

other property might occur.

Symbols on the Product. These symbols may appear on the

product:

Hazardous

Voltage

Refer to

Instructions

Protective

Earth

Terminal

Earth

Ground

Chassis

Ground

RIGOL

Quick Guide for DS1000E, DS1000D Series V

Contents

Contents.................................................................................. V

Necessary Inspection................................................................ 1

How to Connect Power Cord...................................................... 2

How to Connect Probe or BNC................................................... 3

How to Connect Logic Analyzer ................................................. 5

How to Connect USB and RS232 Devices.................................... 6

Troubleshooting........................................................................ 7

RIGOL

Quick Guide for DS1000E, DS1000D Series 1

Necessary Inspection

1．Inspect the shipping container for damage.

Keep the damaged shipping container or cushioning material

until the contents of the shipment have been checked for

completeness and the instrument has been checked

mechanically and electrically.

2．Inspect the instrument.

In case there is any mechanical damage or defect, notify the

RIGOL Sales Representative. If the shipping container is

damaged, or the cushioning materials show signs of stress,

notify the carrier as well as the RIGOL sales office. Keep the

shipping materials for the carrier’s inspection.

3．Check the accessories.

Please check the accessories according to packing list. If the

contents are incomplete or damaged notify the RIGOL Sales

Representative.

RIGOL

Quick Guide for DS1000E, DS1000D Series

How to Connect Power Cord

After inspecting the instrument and the accessories, connect the

power cord as shown in the following figure.

Press the power key on the top of the oscilloscope. if the

oscilloscope can not be powered on, check the power cord

connection. If the oscilloscope still can not start up after the

inspections, please contact RIGOL for help.
