Rigol DP1308A Manuel utilisateur

RIGOL

User’s Guide

DP1308A Programmable

Linear DC Power Supply

Aug. 2009

RIGOL Technologies, Inc.

RIGOL

User’s Guide for DP1308A

Guaranty and Declaration

Trademark Information

RIGOL is registered trademark of RIGOL Technologies, Inc.

Notices

RIGOL products are protected by patent law in and outside of P.R.C..

RIGOL Technologies, Inc. reserves the right to modify or change parts of or all

the specifications and pricing policies at company’s sole decision.

Information in this publication replaces all previously corresponding material.

RIGOL shall not be liable for losses caused by either incidental or consequential

in connection with the furnishing, use or performance of this manual as well as

any information contained.

Any part of this document is forbidden to copy or photocopy or rearrange without

prior written approval of RIGOL.

Product Certification

RIGOL guarantees this product conforms to the standards of national and industrial.

Meanwhile, the related standards conform to other ISO will get further. At present,

DP1308A has passed CE, cTUVus and LXI certification.

If you have any problem or requirement when using our products, please contact

RIGOL Technologies, Inc. or your local distributors, or visit: www.rigol.com

RIGOL

User’s Guide for DP1308A

Safety Notices

Review the following safety precautions

carefully before operating the

instrument to avoid any personal injuries

or damages to the instrument and any

product connected to it. To prevent

potential hazards, do use the instrument

specified by this user’s guide only.

Use Proper Power Cord.

Only the power cord designed for the

instrument and authorized by local

country could be used.

Ground the Instrument.

The instrument is grounded through the

grounding conductor of the power cord.

To avoid electric shock, the instrument

grounding conductor(s) must be

grounded properly before connecting

the input or output terminals.

Connect Output Wire Correctly.

Please connect the output wire in strict

accordance with operation methods in

this guide.

Observe all Terminal Ratings.

To avoid fire or shock hazard, observe all

ratings and marks on the instrument.

Consult your manual for more

information about ratings before

connecting.

Do Not Operate Without Covers.

Do not operate the instrument with

covers or panels removed.

Use Proper Fuse.

Please use the fuse with specified

voltage and current rating.

Avoid Circuit or Wire Exposure.

Do not touch exposed connections and

components when power-on.

Do not Operate with Suspected

Failures.

If suspected damage occurs to the

instrument, have it inspected by

qualified service personnel before

further operations.

Keep Well Ventilation.

Inadequately ventilated will cause the

temperature rises or damages to the

device. Please keep well ventilation and

inspect the intake and fan regularly.

Do not Operate in Wet/Damp

Conditions.

In order to avoid short circuit to the

interior of the device or electric shock,

please do not operate in a humid

environment.

Do not Operate in an Explosive

atmosphere.

In order to avoid damages to the device

or personal injury, please operate far

away from an explosive atmosphere.

RIGOL

User’s Guide for DP1308A

III

Keep Product Surfaces Clean and

Dry.

In order to prevent the performance of

the device from influencing by dust or

water in air, please keep the surface of

device clean and dry.

Handling Safety

Please handle with care during

transporting to avoid damages to

buttons, and knobs or interfaces as well

as other parts on the panel resulting

from the falling from your hand.

RIGOL

User’s Guide for DP1308A

Safety Terms and Symbols

Terms in this Guide. These terms may appear in this manual:

WARNING

Warning statements indicate the conditions or practices that could result in

injury or loss of life.

CAUTION

Caution statements indicate the conditions or practices that could result in

damage to this product or other property.

Terms on the Product. These terms may appear on the product:

DANGER indicates an injury or hazard that may immediately happen.

WARNING indicates a potential injury or hazard that may happen.

CAUTION indicates that a potential damage to the instrument or other property

might occur.

Symbols on the Product. These symbols may appear on the product:

Protective

Earth

Terminal

Hazardous

Voltage

Refer to

Instructions

Test

Ground

Chassis

Ground

RIGOL

User’s Guide for DP1308A

DP1308A Overview

DP1308A programmable linear DC power supply is designed with high performance

and 80W triple-output. It has clear user interface, excellent specifications and multiple

standard interfaces, which can meet diversified testing demands.

Main Features:

4.3 inch, 16M true color TFT LCD;

Individual and controllable triple-channel enables to output power up to 80W in

total;

Low ripples noise, the output noise and ripples<350μVrms/2mVpp;

Excellent load regulation rate and linear regulation rate: <0.01%+2mV (voltage),

<0.01%+250μA (current);

To implement effective protection for loads through setting up the corresponding

parameters based on overvoltage/overcurrent protection function;

Two-level over-temperature protection;

Store and recall system parameters;

Timing output;

Waveform display: enable to display voltage/current waveform in real time and

make the state of instrument understand fully at one glance coordinating with

digital voltage, current and power value;

Standard interfaces: USB Device, USB Host, LAN and GPIB;

Support U disk store;

Support remote control via Web;

Support remote control via commands;

Conform to LXI-C class instrument standard;

One button help function;

Support Chinese & English interface, input method.

RIGOL

User’s Guide for DP1308A

Structure of This Document

Chapter 1 Quick Start

This chapter introduces you the panels and display interface of DP1308A as well as

some considerations when first use.

Chapter 2 Front Panel Operations

This chapter gives detailed information on function and operating methods about each

button of the front panel.

Chapter 3 Remote Control

This chapter shows more details about remote control of DP1308A.

Chapter 4 Troubleshooting

This chapter offers some methods to help you solve the problems during operations.

Chapter 5 Specifications

This chapter lists the specifications of DP1308A power supply.

Chapter 6 Appendix

Information about accessories, warranties, services and supports and the like.

Hint:

For the newest edition of this manual please go to http://www.rigol.com to

download.

Conventions about how to denote the buttons and menu softkeys from

front panel in this document:

Buttons: button characters + textbox, for example: +6V denotes the selection

button of + 6V channel.

Menu softkeys: Menu character+ character shading, for example: Volt denotes the

voltage option in Channel settings.

RIGOL

User’s Guide for DP1308A

VII

Contents

Guaranty and Declaration.............................................................................. I

Safety Notices ............................................................................................. II

DP1308A Overview.......................................................................................V

Chapter 1 Quick Start ............................................................................ 1-1

General Inspection ....................................................................................1-2

Front/Rear Panels and User Interface..........................................................1-3

Front Panel.........................................................................................1-3

Rear Panel..........................................................................................1-5

User Interface ....................................................................................1-6

First Use DP1308A.....................................................................................1-7

Power Requirement.............................................................................1-7

Power-On Inspection...........................................................................1-7

Output Inspection...............................................................................1-8

Display Modes......................................................................................... 1-11

Chapter 2 Front Panel Operations ......................................................... 2-1

Parameter Input........................................................................................2-2

Constant Voltage Output............................................................................2-4

Constant Current Output............................................................................2-8

Timing Output......................................................................................... 2-12

Multiplexed Output .................................................................................. 2-14

Tracking Output ...................................................................................... 2-16

Save and Recall....................................................................................... 2-18

Set up the Utility ..................................................................................... 2-21

I/O Setting ....................................................................................... 2-22

System Setting ................................................................................. 2-24

Calibrate .......................................................................................... 2-27

Timer Setting ................................................................................... 2-28

Online Help System ................................................................................. 2-29

Key Lock................................................................................................. 2-30

Chapter 3 Remote Control.....................................................................3-1

Chapter 4 Troubleshooting....................................................................4-1

Chapter 5 Specifications........................................................................5-1

RIGOL

User’s Guide for DP1308A

VIII

Chapter 6 Appendix............................................................................... 6-1

Appendix A: DP1308A Accessories ..............................................................6-1

Appendix B: Warranty................................................................................6-2

Appendix C: General Care and Cleaning ......................................................6-3

Index ...........................................................................................................1
