Riello 40 FS20 Guide de démarrage rapide

20013742 (2) - 09/2009

Installation, use and maintenance instructions

安装 , 使用以及维护说明书

Forced draught gas burner

强制通风燃气燃烧器

CODE - 编码 MODEL - 型号 TYPE - 类型

20013621 FS20 569T30

One stage operation

一段火运行

20013742

INFORMATION ABOUT THE INSTRUCTION MANUAL

INTRODUCTION

The instruction manual supplied with the burner:

- is an integral and essential part of the product and must not be sepa-

rated from it; it must therefore be kept carefully for any necessary

consultation and must accompany the burner even if it is transferred

to another owner or user, or to another system. If the manual is lost

or damaged, another copy must be requested from the Technical

Assistance Service of the area;

- is designed for use by qualified personnel;

- offers important indications and instructions relating to the installation

safety, start-up, use and maintenance of the burner.

DELIVERY OF THE SYSTEM AND THE INSTRUCTION MAN-

UAL

When the system is delivered, it is important that:

- The instruction manual is supplied to the user by the system manu-

facturer, with the recommendation to keep it in the room where the

heat generator is to be installed.

- The instruction manual shows:

- the serial number of the burner;

- the address and telephone number of the nearest Assistance

Centre;

- The system supplier carefully informs the user about:

- the use of the system,

- any further tests that may be necessary before the system is

started up,

- maintenance and the need to have the system checked at least

once a year by the manufacturer or another specialised techni-

cian.

To ensure a periodic check, recommends the drawing up

of a Maintenance Contract.

..................................................................................

1 20013742

INDEX

1. BURNER DESCRIPTION

Gas burner with one stage working.

1.1 BURNER EQUIPMENT

Insulating gasket . . . . . . . . . . No. 1 Screws and nuts for flange to be fixed to boiler . . . . No. 4

Cable grommet. . . . . . . . . . . . .No. 1 Screws for fixing the cover. . . . . . . . . . . . . . . . . . . . No. 3

Hinge . . . . . . . . . . . . . . . . . . . . No. 1 7 pin plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1

1. BURNER DESCRIPTION . . . . . . . . . . . 1

1.1 Burner equipment . . . . . . . . . . . . . . . . . 1

2. TECHNICAL DATA . . . . . . . . . . . . . . . . 2

2.1 Technical data. . . . . . . . . . . . . . . . . . . . 2

2.2 Overall dimensions . . . . . . . . . . . . . . . . 2

2.3 Working field. . . . . . . . . . . . . . . . . . . . . 2

3. INSTALLATION . . . . . . . . . . . . . . . . . . 3

3.1 Boiler fixing . . . . . . . . . . . . . . . . . . . . . . 3

3.2 Probe-electrode positioning. . . . . . . . . . 4

3.3 Gas feeding line . . . . . . . . . . . . . . . . . . 4

3.4 Electrical wiring. . . . . . . . . . . . . . . . . . . 5

3.4.1 Standard electrical wiring . . . . . . . . . . . 5

3.4.2 Electrical wiring with gas leak control

device . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4. WORKING . . . . . . . . . . . . . . . . . . . . . . . 6

4.1 Combustion adjustment. . . . . . . . . . . . . . 6

4.2 Combustion head setting. . . . . . . . . . . . . 6

4.3 Air damper setting. . . . . . . . . . . . . . . . . . 7

4.4 Combustion check. . . . . . . . . . . . . . . . . . 7

4.5 Air pressure switch . . . . . . . . . . . . . . . . . 7

4.6 Burner start-up cycle. . . . . . . . . . . . . . . . 8

4.7 Start-up cycle diagnostics . . . . . . . . . . . . 8

4.8 Resetting the control box and using

diagnostics . . . . . . . . . . . . . . . . . . . . . . . 9

5. WARNINGS

to avoid burnout or bad combustion

of the burner . . . . . . . . . . . . . . . . . . . . . . 10

6. MAINTENANCE . . . . . . . . . . . . . . . . . . . 10

7. FAULTS / SOLUTIONS. . . . . . . . . . . . . . 11

1– Air damper

2– Screws for fixing the air-damper

3– 7 pole socket for electrical supply

and control

4– 6 pole socket for gas train

5– Cable grommet

6– Screw for fixing the cover

7– Air pressure switch

8– Control box

9– Reset button with lock-out lamp

According to Directives: EMC 89/336/EEC - 2004/108/EC, Low Voltage 73/23/EEC - 2006/95/EC and Efficiency

92/42/EEC.

The burner is approved for intermittent operation as per Directive EN 676.

The burner meets protection level of IP X0D (IP 40), EN 60529.

Gas train according to EN 676.

NOTES:

– The cable grommet (5) supplied with the burner, must be fitted to the same side of the gas train.

– After having installed the burner verify the access to the fixing screws of the cover.

If necessary replace them with the fixing screws (6, fig. 1) supplied as equipment.

Fig. 1

D4183

6 5 3

20013742 2

2. TECHNICAL DATA

2.1 TECHNICAL DATA

For gas family 3 (LPG) ask for separate kit.

2.2 OVERALL DIMENSIONS

2.3 WORKING FIELD (as EN 676)

Thermal power (1) 81 – 220 kW - 70,000 – 189,000 kcal/h

Natural gas (Family 2) Net heat value: 8 – 12 kWh/Nm3-7,000 – 10,340 kcal/Nm3

Pressure: min. 20 mbar - max. 100 mbar

Electrical supply Single phase, 230V ±10% ~50Hz

Motor 230V / 1.4A

Capacitor 5 μF

Ignition transformer Primary 230V / 1.8A - Secondary 8 kV / 30 mA

Absorbed electrical power 0.25 kW

(1) Reference conditions: Temp. 20°C - Barometric pressure 1013 mbar – Altitude 0 m above sea level.

COUNTRY DE AT - GR FR ES - GB-IE LU NL

GAS CATEGORY II2ELL3B/P II2H3B/P II2Er3P II2H3P II2E3B/P II2L3B/P

FlangeBurner

350 120 389 170

155

33 67

45°

125

298

170

Rp 3/4

230

152



280

Length available using a separate kit.

D4257

200



379



Combustion head extension, supplied separately.

D5212

Thermal power

0.8

1.6

2.4

3.2

4.0

4.8

70,000 90,000 110,000 130,000 kcal/h

80 120100 140 160 kW180

170,000

200 220

150,000 190,000

Pressure in the combustion

chamber – mbar

3 20013742

TEST BOILER

The working field has been defined according to EN 676 standard.

COMMERCIAL BOILERS

The burner-boiler matching is assured if the boiler conforms to EN 303 and the combustion chamber dimensions

are similar to those shown in the diagram EN 676. For applications where the boiler does not conform to EN 303,

or where the combustion chamber is much smaller than the dimensions given in EN 676, please consult the

manufacturers.

CORRELATION BETWEEN GAS PRESSURE AND BURNER OUTPUT

To obtain the maximum output, a gas head pressure of 6.9 mbar is measured (M2, see chapter 3.3, page 4) with

the combustion chamber at 0 mbar using gas G20 with a net heat value of 10 kWh/Nm3(8,570 kcal/Nm3).

3. INSTALLATION

THE BURNER MUST BE INSTALLED IN CONFORMITY WITH LEGISLATION AND LOCAL STANDARDS.

3.1 BOILER FIXING

D5213

Thermal power

70,000 90,000 110,000 130,000 kcal/h

80 120100 140 160 kW180

170,000

200 220

150,000 190,000

Gas pressure in the

combustion head – mbar

Boiler door must have a max. thickness of 100 mm,

refractory lining included.

If thickness is greater (max. 260 mm), a combustion

head extension must be fitted, which is supplied

separately.

IMPORTANT

Separate the combustion-head assembly

from the burner body by removing nut (1) and

removing group (A).

Fix the head assembly group (B) to the boiler

(2) insert the supplied insulating gasket (3).

HINGE

S7393

ASSEMBLY

132

D5097

20013742 4

3.2 PROBE - ELECTRODE POSITIONING

3.3 GAS FEEDING LINE

GAS TRAIN ACCORDING TO EN 676

The gas train is supplied separately, for its adjustment see the enclosed instructions.

GAS TRAIN CONNECTIONS USE

TYPE CODE INLET OUTLET

MBDLE 407 B01 3970531 Rp3/4 Rp3/4 Natural gas ≤180 kW and LPG

MBDLE 410 B01 3970532 Rp 1 Rp 3/4 Natural gas and LPG

D5104

Ignition electrode

WARNING

–

Ionization probe

Probe

Electrode

3.7

Diffuser

1– Gas supply pipe

2– Manual cock (supplied by the installer)

3– Gas pressure gauge (supplied by the installer)

4– Filter

5– Gas pressure switch

6– Safety valve

7– Pressure governor

8– Adjustment valve

M1 – Gas-supply pressure test point

M2 – Pressure coupling test point

D5099

2 3 M1 4 5 6 7 8

5 20013742

3.4 ELECTRICAL WIRING

Ionization probe

Electrode

Motor

Capacitor

Burner earth

Air pressure switch

Blue

White

Black

Control box

RMG 88.620A2

Suppressor

Connector

Ignition transformer

3.4.1 STANDARD ELECTRICAL WIRING

KEY TO LAY-OUT

XP6– 6 pole socket

XP7– 7 pole socket

X6 – 6 pin plug

X7 – 7 pin plug

B4 – Working signal

h1 – Hour counter

PG – Minimum gas pressure

switch

S3 – Remote lock-out signal

(230V - 0.5 A max.)

T6A– Fuse

TL – Limit thermostat

TS – Safety thermostat

V10 – Safety valve

V11 – Adjustment valve

In the case of phase-phase

feed, a bridge must be fit-

ted on the control box ter-

minal board between

terminal 6 and the earth

terminal.

ATTENTION

230V

50Hz

D4275

TO BE DONE BY

THE INSTALLER

CARRIED-OUT

IN THE FACTORY

ATTENTION:

Do not swap neutral and phase over, follow the diagram shown carefully and carry out a good earth connection.

The section of the conductors must be at least 1mm. (Unless requested otherwise by local standards and legislation).

The electrical wiring carried out by the installer must be in compliance with the rules in force in the country.

Verify that the burner stops by operating the boiler control thermostats and that the burner locks out by separating

the red ionisation probe lead connector.

NOTES

The burners have been type-approved for intermittent operation. This means they must stop at least once every 24 hours in

order to allow the electrical control box to check its efficiency on start-up. The boiler limit thermostat (TL) normally ensures

the burner halts. If this does not happen a time switch halting the burner at least once every 24 hours must be applied in se-

ries to limit thermostat (TL).

20013742 6

3.4.2 ELECTRICAL WIRING WITH GAS LEAK CONTROL DEVICE (DUNGS VPS 504)

4. WORKING

4.1 COMBUSTION ADJUSTMENT

In conformity with Efficiency Directive 92/42/EEC the application

of the burner on the boiler, adjustment and testing must be car-

ried out observing the instruction manual of the boiler, including

verification of the CO and CO2concentration in the flue gases,

their temperatures and the average temperature of the water in

the boiler.

To suit the required appliance output, choose the proper set-

ting of the combustion head, and the air damper opening.

4.2 COMBUSTION HEAD SETTING

Loose the screw (A), move the elbow (B) so that the rear plate

of the coupling (C) coincides with the set point.

Tighten the screw (A).

Example:

The burner is installed on a 155 kW boiler

with an efficiency of 90%, the burner

input is about 172 kW using the diagram,

the combustion set point is 3.

The diagram is to be used only for initial

settings, to improve air pressure switch

operation or improve combustion, it may

be necessary to reduce this setting (set

point toward position 0).

KEY TO LAY-OUT

X6 – 6 pin plug

X7 – 7 pin plug

B4 – Working signal

h1 – Hour counter

PG – Minimum gas pressure

switch

S3 – Remote lock-out signal

(230V - 0.5 A max.)

T6A– Fuse

TL – Limit thermostat

TS – Safety thermostat

V10 – Safety valve

V11 – Adjustment valve

230V

50Hz

D4199

TO BE DONE BY

THE INSTALLER

S7015

kcal/h kW

Set point

02134

240

140

120

100

160

200,000

140,000

120,000

100,000

70,000

D5109

180

200

220

80,000

160,000

180,000

172

7 20013742

4.3 AIR DAMPER SETTING

The regulation of the air-rate is made by adjusting the air damper (1), after

loosing the screws (2).

When the optimal regulation is reached, screw tight the screws (2).

4.4 COMBUSTION CHECK

It is advisable to set the burner according to the type of gas used and following the indications of the table:

IONIZATION CURRENT

The minimum current necessary for the control box operation is 3 μA.

The burner normally supplies a higher current value, so that no check is needed. However, if you want to measure

the ionization current, you must open the connector fitted to the red wire and insert a microammeter.

4.5 AIR PRESSURE SWITCH

The air pressure switch is set after all other adjustments have been made. Begin with the switch at the lowest

setting. With the burner working at the minimum output, adjust the dial clockwise, increasing its value until

the burner shuts down. Now reduce the value by one set point, turning the dial anti-clockwise.

Check for reliable burner operation, if the burner shuts down, reduce the value by a half set point.

Attention:

To comply with the EN 676 standard, the air pressure switch must operate when the CO value exceeds 1%

(10,000 ppm). To check this, insert a combustion analyser in the flue, slowly reduce the burner air setting and ver-

ify that the burner shuts down by the action of the air pressure switch before the CO value exceeds 1%.

EN 676 AIR EXCESS:

max. output λ≤1.2 – min. output λ≤1.3

GAS Theoretical max. CO2

0 % O2

Setting CO2% CO

mg/kWh NOx

mg/kWh

λ= 1.2 λ= 1.3

G 20 11.7 9.7 9.0 ≤100 ≤170

G 25 11.5 9.5 8.8 ≤100 ≤170

G 30 14.0 11.6 10.7 ≤100 ≤230

G 31 13.7 11.4 10.5 ≤100 ≤230

D5231

Probe

Connector

Terminal board

of control-box

D5006

20013742 8

4.6 BURNER START-UP CYCLE

When flame-failure occurs during working, shut down takes place within one second.

4.7 START-UP CYCLE DIAGNOSTICS

During start-up, indication is according to the followin table:

COLOUR CODE TABLE

Sequences Colour code

Pre-purging 

Ignition phase 

Operation, flame ok 

Operating with weak flame signal. 

Electrical supply lower than ~170V 

Lock-out 

Extraneous light 

Index: Off Yellow Green Red

3s40s40smax. 2s max. 2s D4172

Lock-out, due to ignition failureNormal

Thermostat

Motor

Ignition transformer

Valves

Flame

Lock-out

Autres manuels pour 40 FS20

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Riello Cheminée intérieure

Riello

Riello 836 T1 Guide de démarrage rapide

Riello

Riello Two stage operation forced draught natural gas/propane... Instructions d'installation

Riello

Riello RS 44/1 MZ Guide de démarrage rapide

Riello

Riello GAS 6 P/M Guide de démarrage rapide

Riello

Riello G20D Guide de démarrage rapide

Riello

Riello RS310/EVO2 BLU Guide de démarrage rapide

Riello

Riello RLS 28/M Guide de démarrage rapide

Riello

Riello 40 GS10 Guide de démarrage rapide

Riello

Riello DB 16 LSE FGR Guide de démarrage rapide

Riello

Riello DB 3 LSE FGR Guide de démarrage rapide

Riello

Riello LPG kit Guide de démarrage rapide

Riello

Riello 40 Series Guide de démarrage rapide

Riello

Riello RX25 S/PV H Guide de démarrage rapide

Riello

Riello RS 34 MZ Guide de démarrage rapide

Riello

Riello RS 70/M Guide de démarrage rapide

Riello

Riello RX 90 S/PV Guide de démarrage rapide

Riello

Riello RX 180 S/PV Manuel utilisateur

Riello

Riello 437T1 Guide de démarrage rapide

Riello

Riello RS 34/M MZ Guide de démarrage rapide

Riello

Riello RS 1000/M C01 Guide de démarrage rapide

Riello

Riello RS 200/E LN Guide de démarrage rapide

Riello

Riello 40 GS3 Guide de démarrage rapide

Riello

Riello 40 Series Guide de démarrage rapide

Riello

Riello RS 28 Guide de démarrage rapide

Manuels Cheminée intérieure populaires d'autres marques

Brigantia

Brigantia 35-DVRS31N-2 Manuel du propriétaire

Nordpeis

Nordpeis Bergen Manuel utilisateur

Superior

Superior BCT2536TMN Manuel utilisateur

Quadra-Fire

Quadra-Fire 5100I-GD-B Manuel utilisateur

Renaissance

Renaissance RUMFORD 1000 Manuel utilisateur

Lacunza

Lacunza IV-800 Manuel utilisateur

Baxi

Baxi 940 Instructions d'utilisation

Dru

Dru Maestro 60/2 Tall RCH Manuel utilisateur

Diamond Fireglass

Diamond Fireglass SS-O22 Manuel utilisateur

HearthStone

HearthStone Windsor Bay 8830 Manuel de programmation

Napoleon

Napoleon ASCENT B42 Manuel utilisateur

Enviro

Enviro E33GI Manuel utilisateur

Smeg

Smeg L30 FABE Instructions de montage

KEDDY

KEDDY K700 Manuel utilisateur

Godin

Godin 3451 Manuel utilisateur

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manuel utilisateur

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manuel utilisateur

Desa

Desa CCFPDFT Manuel d'utilisation
