Ricoh SWALLOW 2 Manuel utilisateur

IMPORTANT SAFETY NOTICES

PREVENTION OF PHYSICAL INJURY

1. Before disassembling or assembling parts of the copier and peripherals,

make sure that the copier power cord is unplugged.

2. The wall outlet should be near the copier and easily accessible.

3. Note that some components of the copier and the paper tray unit are

supplied with electrical voltage even if the main switch is turned off.

4. If any adjustment or operation check has to be made with exterior

covers off or open while the main switch is turned on, keep hands away

from electrified or mechanically driven components.

5. If the start key is pressed before the copier completes the warm-up

period, keep hands away from the mechanical and the electrical

components as the copier starts making copies as soon as the warm-up

period is completed.

6. The inside and the metal parts of the fusing unit become extremely hot

while the copier is operating. Be careful to avoid touching those

components with your bare hands.

HEALTH SAFETY CONDITIONS

1. Toner and developer are non-toxic, but if you get either of them in your

eyes by accident, it may cause temporary eye discomfort. Try to remove

with eye drops or flush with water as first aid. If unsuccessful, get

medical attention.

OBSERVANCE OF ELECTRICAL SAFETY STANDARDS

1. The copier and its peripherals must be installed and maintained by a

customer service representative who has completed the training course

on those models.

2. The RAM board on the main control board has a lithium battery which

can explode if replaced incorrectly. Replace the battery only with an

identical one. The manufacturer recommends replacing the entire RAM

board. Do not recharge or burn this battery. Used batteries must be

handled in accordance with local regulations.

SAFETY AND ECOLOGICAL NOTES FOR DISPOSAL

1. Do not incinerate the toner bottle or the used toner. Toner dust may

ignite suddenly when exposed to open flame.

2. Dispose of used toner, developer, and organic photoconductor

according to local regulations. (These are non-toxic supplies.)

3. Dispose of replaced parts in accordance with local regulations.

4. When keeping used lithium batteries in order to dispose of them later,

do not put more than 100 batteries per sealed box. Storing larger

numbers or not sealing them apart may lead to chemical reactions and

heat build-up.

SWALLOW 2

(Machine Code: A212/A214)

Service Manual

–

Insert Version

–

The A212 copier is based on the A161 copier.

The A214 copier is based on the A162 copier.

Only the differences from the A161/A162 copier are described in

the following pages. Refer to the A161/A162 copier service manual

for more information.

1. SPECIFICATIONS

NOTE: Only items marked with ✽are different from A161 and A162 copiers.

Configuration: Desktop

Copy Process: Dry electrostatic transfer system

Originals: Sheet/Book

Original Size: Maximum: A3/11" x 17"

Copy Paper Size: Maximum: A3/11" x 17" (Paper trays)

Minimum: A5/81/2" x 51/2" sideways (Paper trays)

A4/11" x 81/2" sideways (LCT)

A6/51/2" x 81/2" lengthwise (By-pass)

Duplex Copying: Maximum: A3/11" x 17"

Minimum: A5/81/2" x 51/2" (sideways)

Copy Paper Weight: Paper tray: 64 ~ 90 g/m2, 17 ~ 24 lb

By-pass: 52 ~ 157 g/m2, 14 ~42 lb

LCT: 52 ~ 128 g/m2, 14 ~ 34 lb

Duplex copying: 64 ~ 90 g/m2, 17 ~ 24 lb

(feeding from the Paper tray)

64 ~ 105 g/m2, 17 ~ 24 lb

(feeding from the LCT)

Reproduction Ratios: 4 Enlargement and 6 Reduction

A4/A3 Version LT/DLT Version

Enlargement

200%

141%

122%

115%

200%

155%

129%

121%

Full size 100% 100%

Reduction

93%

82%

75%

71%

65%

50%

93%

85%

77%

74%

65%

50%

A212/A214

Copier

13 October 1997 SPECIFICATIONS

Power Source: 120 V/60 Hz:

More than 12 A (for North America)

220 V ~ 240 V/50 Hz:

More than 7 A (for Europe)

220 V/50 Hz:

More than 7 A (for Asia)

110 V/60 Hz:

More than 14 A (for Taiwan)

220 V/60 Hz:

More than 7 A (for Saudi Arabia, Philippines)

✽ Power Consumption:

NOTE: 1) Full System: Copier + ADF + Paper Tray Unit + 10 Bin S/S

2) Energy Saver: See SP1-105-002

3) Auto Off: See SP5-305

✽Noise Emission:

NOTE: The above measurements were made in accordance with ISO

7779.

* : Full System: Copier + ADF + Paper Tray Unit +10 Bin S/S.

Copier Only Full System

Maximum 1.45 kW 1.50 kW

Copying 0.64 kW 0.72 kW

Warm-up 0.95 kW 0.97 kW

Stand-by 0.15 kW 0.17 kW

Energy Saver

1 0.14 kW 0.16 kW

2 0.12 kW 0.13 kW

3 0.09 kW 0.10 kW

4 0.07 kW 0.08 kW

5 0.05 kW 0.06 kW

Auto Off 0.02 kW 0.04 kW

Copier Only Full System*

1. Sound Power Level

Copying 65 dB(A) 70 dB(A)

Stand-by 40 dB(A) 40 dB(A)

2. Sound Pressure Level at the operator position

Copying 60 dB(A) 64 dB(A)

Stand-by 40 dB(A) 40 dB(A)

SPECIFICATIONS 13 October 1997

✽Dimensions:

Width Depth Height

A212 copier 900 mm (35.5") 655 mm (25.8") 626 mm (24.7")

A214 copier 1,128 mm (44.5") 655 mm (25.8") 626 mm (24.7")

Measurement Conditions

1) With by-pass feed table closed

2) With platen cover and copy tray attached

3) With LCT cover closed

Weight:

Zoom: From 50% to 200% in 1% steps

Copying Speed

(copies/minute): 22 copies/minute (A4/11" x 81/2" sideways)

12 copies/minute (A3/11" x 17")

Warm-Up Time Less than 60 seconds (at 20°C/68°F)

First Copy Time:

NOTE: In the A214 copier, the 2nd tray in the above table is called the 1st

tray (see Installation - Paper Feed Station Definition of the base

copier service manual).

Copy Number Input: Ten-key pad, 1 to 999 (count up or count down)

Manual Image Density

Selection: 7 steps

Automatic Reset: 1 minute is the standard setting; it can be changed

to a maximum of 999 seconds or no auto reset by

SP mode.

✽Copy Paper Capacity:

Paper Tray By-pass Feed LCT

A212 copier About 500 sheets x 2 About 40 sheets —

A214 copier About 500 sheets x 1 About 40 sheets About 1,000 sheets

Weight

A212 copier About 67 kg (147.7 lb)

A214 copier About 80 kg (176.4 lb)

Paper Feed Station A4/11" x 81/2" (sideways)

1st Tray 5.9 s (except for A214)

2nd Tray 6.6 s

By-pass 5.6 s

LCT 5.9 s

A212/A214

Copier

13 October 1997 SPECIFICATIONS

Duplex Tray Capacity

[A214]: 50 sheets (30 sheets for A3/11"x17"

81 ~ 105 g/m2, 21.5 ~ 27.9 lb paper)

Toner Replenishment: Cartridge exchange (415 g/cartridge)

✽Optional Equipment

(Sales items): •Platen cover (except for A212 machines with

destination code 29)

•Document feeder

•10-bin sorter stapler

•20-bin sorter stapler

•20-bin mini sorter

•10-bin micro sorter

•Sorter adapter (required when installing a

10-bin sorter stapler or 20-bin mini sorter)

•1,500-sheet tray unit (three 500-sheet trays)

•1,000-sheet tray unit (two 500-sheet trays)

•500-sheet tray unit (two 250-sheet trays)

Optional Equipment

(Service items): •Original length sensor for 11" x 15" size paper

(only for LT/DLT version)

•Tray heater

•Optical anti-condensation heater

•ADS sensor for particular types of red original

Optional Equipment

(To be procured locally): •Key counter

SPECIFICATIONS 13 October 1997

2. MACHINE CONFIGURATION

2.1 COPIER

– A212 copier –

Two 500-sheet trays

*: Only for machines with destination code 29.

– A214 copier –

A 500-sheet tray

A duplex tray

A 1000-sheet large capacity tray

A212V500.wmf

A212V501.wmf

A212/A214

Copier

13 October 1997 MACHINE CONFIGURATION

2.2 OPTIONAL EQUIPMENT

*: Except for machines with A212 destination code 29.

A212V502.wmf

MACHINE CONFIGURATION 13 October 1997

MEMO

A212/A214

Copier

13 October 1997 MACHINE CONFIGURATION
