Ricoh SC-10A Manuel utilisateur
2020/6/26 1
Example of using barcode reader
Barcode
reader
Work Assistance
Camera System
RICOH SC-10A
Setting flow
2020/6/26 2
1. Open job settings from the Job tab.
※Please refer to page 30 of Operating Instructions
2. Create a new job ID on the job settings.
※Please refer to page 38 of Operating Instructions
3. Click [Add] of [Instruction Steps] ,
the dialog for inputting Job ID is displayed.
※Please refer to page 43 of Operating Instructions
Example）JobID A-123-RICOH
(code39 barcode）
4. Scan the barcode of "A-123-RICOH" with the barcode
reader, and the text is automatically entered.
※Also you may type on the keyboard.
5. Work flow with ID "A-123-RICOH“ will be created.
A-123-RICOH
How to use
2020/6/26 3
1. Select [User Mode] and Click [Login].
※Please refer to page 29 of Operating Instructions
2. Enter [User ID] .
※Please refer to page 82 of Operating Instructions
※Reading of User ID is optional.
RICOH-JAPAN
3. Enter [Job ID] .
A-123-RICOH
4. Enter [Reference ID] .
※Please refer to 83 pages of Operating Instructions 00000000100
⇒After entering the Reference ID,
the flow automatically starts ※Reading of Reference ID is optional.
TIPS
2020/6/26 4
1. USB
※Please refer to page 97 of Operating Instructions
2. Language support
※Please refer to page 101 of Operating Instructions
Enableｄinterfaces ：TYPE-A x1 USB2.0 High Speed supported (Host)
Enabled device ：USB-HID, USB-Mass Storage
・Input of alphanumeric characters and symbols is supported.
・Japanese cannot be input.
・Folders with names containing 2-byte characters may not be accessible.
・ Use ASCII characters except ":", "/", "¥", "|", "*", "?", "", "<", and ">"
for folder names and file names.
TIPS
2020/6/26 5
3. Notes
・Number of registered characters for Job ID can be registered up to 50 digits.
※Numbers cannot be registered after the blank or ”%” at the beginning and end.
・Barcode reader is not included, so please prepare by yourself.
・This procedure is made based on a barcode reader that is automatically given
enter.
・Please contact the vendor for the settings on the barcode reader side.
