Ricoh M099 Manuel

PE-MF3/PE-P2 Training

Slide 1

M099/M100, M095/M096

Service Training

PE-MF3a/PE-MF3c, PE-P2a/PE-P2c

Version 1.0

This training course provides service technician training for the PE-MF3/PE-P2

series.

The differences between this series and the previous PE-MF2/PE-P1e series are

also explained.

PE-MF3/PE-P2 Training

Slide 2

Service Training

M099/M100, M095/M096

Product Overview

This section provides an overview of the machine, and the options that can be

installed.

PE-MF3/PE-P2 Training

Slide 3

What Models are there in the Series?

PE-MF3

PE-MF3a (M099)

16 ppm (color and b/w)

DDST (GDI)

Memory: 256 MB

‘4-in-1’ (Print/Copy/Fax/Scan)

PE-MF3c (M100)

20 ppm (color and b/w)

PCL/PS

Memory: 256 MB

‘4-in-1’ (Print/Copy/Fax/Scan)

No hard disk and no optional memory for either model

Difference from PE-MF2: Both models were 20 ppm in the PE-MF2 series, and

optional memory was available for the PE-MF2c.

Print speeds are for A4

PE-MF3/PE-P2 Training

Slide 4

What Models are there in the Series?

PE-P2

PE-P2a (M095)

16 ppm (color and b/w)

DDST (GDI)

Memory: 64 MB

PE-P2c (M096)

20 ppm (color and b/w)

PCL/PS

Memory: 256 MB

No hard disk and no optional memory for either model

Difference from PE-P1e: Both models were 20 ppm in the PE-P1e series, and

optional memory was available for both models.

Print speeds are for A4

¾For LT, the speeds are 16.5 and 21 cpm

PE-MF3/PE-P2 Training

Slide 5

Appearance – MFP Models

Note that the two models have different color schemes.

PE-MF3a PE-MF3c

These machines have a built-in ADF.

PE-MF3/PE-P2 Training

Slide 6

Appearance – Printer Models

Note that the two models have different color schemes.

PE-P2a PE-P2c

No additional notes

PE-MF3/PE-P2 Training

Slide 7

Standard Equipment

This equipment is built-in for all models.

35-sheet automatic document feeder (MF models only)

250-sheet paper feed unit

1-sheet bypass feed

Duplex

Ethernet: 10Base-T/100base-TX

USB 2.0

Fax

Memory

PE-MF3a: 256 MB

PE-MF3c: 256 MB

PE-P3a: 64 MB

PE-P3c: 256 MB

No optional memory

No hard disk (built-in or optional) for any model

Duplex can be used for printing and copying. In some earlier models in this

series, duplex could not be used for copying.

PE-MF3/PE-P2 Training

Slide 8

Optional Equipment

TK1010 Paper Feed Unit, G849

Available for all models

Also used in the PE-MF1/MF2/P1/P1E series

No optional memory

Some of the previous models in this series also had optional memory.

PE-MF3/PE-P2 Training

Slide 9

Product Positioning – MF Model

FY2008

FY2008 FY2009

FY2009 FY2011

FY2011

FY2007

PE-MF1a

PE-MF1c

PE-MF1b

3 in 1

GDI

Nov ‘07.

FY2010

20ppm

16ppm

PE-MF2c

Jan ‘09. 20ppm

PE-MF2b

20ppm

PE-MF3c

Jun ‘11. 20ppm

PE-MF3a

16ppm

4 in 1

GDI

4 in 1

PCL 4 in 1

PCL

4 in 1

GDI

4 in 1

GDI

4 in 1

PCL

Per/ Mid HY/SY Toner

Per SY Toner

No additional notes

PE-MF3/PE-P2 Training

Slide 10

Product Positioning – Printer Model

FY2008

FY2008 FY2009

FY2009 FY2011

FY2011

FY2007

PE-P1a

PE-P1c

PE-P1b

GDI

Jul ‘07.

FY2010

20ppm dn

20ppm n

16ppm n

PE-P1Ec

Feb ‘09.20ppm dn

PE-P1Eb

20ppm n

PE-P2c

Jun ‘11. 20ppm dn

PE-P2a

16ppm dn

MD-P1c

Dec ‘08.25ppm dn

MD-P1b

25ppm n

PCL

PCL PCL

PCL

GDI

PCL

MD-P2c

25ppm dn

Per/ Mid HY/SY Toner

Per SY Toner

Nov ‘10.

PCL (GW CTL)

PCL

GDI

Price

No additional notes
