FOR YOUR SAFETY

WHAT TO DO IF YOU SMELL GAS

* Do not try to light any appliance.

* Do not touch any electrical switch; do not use any phone in your building.

* Immediately call your gas supplier from a neighbor's phone. Follow the gas

supplier's instructions.

* If you cannot reach your gas supplier, call the fire department.

WARNING

Improper installation, adjustment, alteration, service or maintenance can cause property

damage, personal injury or loss of life. Refer to the user's information manual provided

with this heater. Installation and service must be performed by a qualified installer,

service agency or the gas supplier.

IMPORTANT WARNING

THE HEATER MUST BE INSTALLED IN ACCORDANCE WITH THE INSTRUCTIONS IN THIS MANUAL. WAR-

RANTY WILL NOT APPLY TO UNITS NOT INSTALLED, OPERATED OR MAINTAINED ACCORDING TO THESE

INSTRUCTIONS. THE INSTALLATION MUST CONFORM TO THE AUTHORITIES HAVING JURISDICTION AND/

OR WITH THE LATEST EDITIONS OF THE NATIONAL FUEL GAS CODE ANSI Z223.1, THE NATIONAL

ELECTRIC CODE ANSI/NFPA 70.

Rheem Commercial Water Heater Products

Ruud Commercial Water Heater Products

One Bell Road • Montgomery, AL 36117

(205) 260-1500

Part No. 240454

CATALOG NO.: RM-001

Effective : 01-15-02

Replaces: 03-15-01

FOR YOUR SAFETY

Do not store or use gasoline or other flammable vapors or liquids or other combustible

materials in the vicinity of this or any other appliance. To do so may result in an explosion

or fire.

OPERATING AND

INSTALLATION

INSTRUCTIONS

Models 136-1826

MODEL

SERIAL NUMBER

INSTALLATION DATE

START UP DATE

INDEX

3 COPPER SANIMASTER AND TYPHOON HOT WATER HEATERS

4 Specification Data

7 INTRODUCTION

INSTALLATION GUIDELINES

8 Base Requirements

9 Combustible Construction Clearances

10 Combustion Air Supply

Outdoor Venting

12 Indoor Venting

16 Power Venting

Outdoor Heaters

Vent Damper Installation

18 Piping (Gas and Water)

20 Cold Water Supply

21 Hot Water Supply Heater

22 Piping Diagram - 1 Heater 1 Tank Thermostat Supplied

23 Piping Diagram - 1 Heater 2 Tank

24 Piping Diagram - 1 Heater 3 Tank

25 Piping Diagram - 1 Heater 4 Tank

26 Piping Diagram - 2 Heater 1 Tank Uses Special Thermostat & Well

27 Description of Controls in General

Operating Controls

28 Tankstat Temperature Control

29 Electrical

29 Start-Up

30 General Safety Precautions

31 Lighting Instructions

33 Inspection and Maintenance Procedures

Burner Inspection

34 Venting System Inspection

Circulator (Water Pump) Inspection

Service Assistance

35 Trouble Shooting

39 Wiring Diagram

44 Replacement Parts List

COPPER SANIMASTER AND TYPHOON

HOT WATER HEATERS

Series GB

for circulating tank systems

136 through 1826 MBTUH

Model Applications

Hot water Supply Heaters are designed to provide hot water service to a variety of applications when used in

conjunction with an appropriately sized storage tank. Models are available for indoor or outdoor installations, and

controls and pump are factory tested and mounted.*

Construction Features

1. All copper high efficiency heat exchanger.

2. Factory mounted pump suited for a wide variety of water conditions.*

3. Flow Switch included on all models.

4. All models feature an energy saving pump control.

5. Glass-lined cast iron headers to handle the most aggressive water conditions.+

6. All units are tested and certified to ANSI Z21.10.3 and carry National Board Stamps HLW.

7. Factory installed pressure relief valve.

8. Temperature pressure gauge and tankstat are included.

9. All inputs over a 400,000 BTU feature intermittent pilot ignition.

10. Models available for Natural or LP Gas.

* Pump shipped separate in carton on Models 136 through 399.

+ Model 136 features Bronze Headers.

MBH Natural Gas

Sanimaster Typhoon

(Indoor) (Outdoor)

Input Output Input Output

136.0 112.0 136.0 112.0

181.0 148.0 181.0 148.0

264.0 216.0 264.0 216.0

334.0 274.0 334.0 274.0

399.0 327.0 399.0 327.0

511.5 419.4 511.5 419.4

627.0 514.0 627.0 514.0

726.0 595.0 726.0 595.0

825.0 676.5 825.0 676.5

926.0 759.0

961.7 788.6

1083.0 888.0

1124.7 922.0

1178.0 966.0

1222.5 1002.4

1287.0 1055.0

1336.6 1096.0

1413.0 1158.5

1467.0 1203.0

1570.0 1287.0

1630.0 1336.6

1758.0 1441.5

1825.6 1497.0

ELECTRICALRATINGS

Model

Size With Pump

136-264 3.4 amps @ 120V(1/8 hp pump)

331-399 3.6 amps @ 120V(1/6 hp pump)

512-1826 7.9 amps @ 120V (1/2 hp

pump)

MBTUHPROPANE GAS†

Model

Size Multiplier

136-399 Same as natural gas

512-825 .94

926-1826 .92 Indoor

.955 Outdoor (Input)

.92 Outdoor (Output)

† Multiplier x Nat. MBTUH =

Pro. MBTUH

MODEL

136

181

264

331

399

512

627

726

825

926

962

1083

1125

1178

1223

1287

1337

1413

1467

1570

1630

1758

1826

STYLE

In- Out-

Door Door

• •

•

Rated inputs are suitable for up to 2000 feet elevation. For elevations above 2000 feet, reduce input 4% for each

1000 feet above sea level. These heaters are tested and certified to ANSI Standard Z 21.10.3

SPECIFICATION DATA

Jacket

Height

30-1/8

33-1/2

36-1/2

Gas

Conn.

1/2

3/4

1-1/4

Water

Connection

1-1/4

1-1/2

2-1/2

12-1/16

11-1/8

10-3/4

12-1/2

23-5/8

Reference

Drawing

9-1/4

25-3/8

29-1/2

34-1/4

38-1/2

Width

24-1/8

18-1/4

22-3/8

25-3/4

29-1/4

32-3/4

37-1/2

41-5/8

45-3/4

52-3/8

59-1/4

63-5/8

68-5/8

74-7/8

81-1/8

89-3/8

Height

Overall

62-5/8

62-7/8

63-3/4

65-3/8

76-1/8

78-1/8

80-1/8

83-1/8

85-1/8

Flue

Dia.

SHIPPING

WEIGHT

LBS (APPROX)

Less Pump

160

182

205

225

244

475

485

635

645

785

705

865

745

925

805

980

875

1080

945

1130

985

1160

1035

W/Pump

210

232

255

275

294

530

540

690

700

840

760

920

800

980

860

1035

930

1130

1000

1190

1040

1220

1090

MODEL

SIZE

136

181

264

331

399

512

627

726

825

926

962

1083

1125

1178

1223

1287

1337

1413

1467

1570

1630

1758

1826

Indoor Outdoor

••

•

A. INTRODUCTION

WE RECOMMEND THAT THIS MANUAL BE REVIEWED THOROUGHLY BEFORE INSTALLING THE

WATER HEATER. SHOULD ANY QUESTIONS ARISE, NOT COVERED BY THIS DATA, CONTACT YOUR

LOCAL DISTRIBUTOR OR THE SERVICE DEPARTMENT AT THE FACTORY.

MODEL IDENTIFICATION

The model number of the water heater is found on the rating plate. Each model number identifies the application,

the construction and the function of the water heater , and provides a positive means of identification for application,

installation, operation, service and parts of the unit in a minimum amount of time.

RECEIVING EQUIPMENT

On receiving equipment it is suggested that you

• Review packing slip for the number of packages.

• Inspect for concealed damage immediately.

• Advise carrier, in writing, of shortages or damage.

• Claims are filed by the receiver against the carrier. The carrier, not the shipper, is responsible for any

shortage or damage whether visible or concealed.

B. INSTALLATION GUIDELINES

INSTALLATION REGULATIONS

THE INSTALLATION MUST CONFORM WITH THESE INSTRUCTIONS, REQUIREMENTS OR CODES OF

AUTHORITIES HAVING JURISDICTION, THE LATEST EDITION OF THE NATIONAL FUEL GAS CODE, ANSI

Z223.1 AND THE NATIONAL ELECTRICAL CODE.

ANY ALTERATION OR MODIFICATION TO THE WATER HEATER, ITS COMPONENTS OR ITS INTENDED

APPLICATION MAY VOID THE WARRANTY EXTENDED WITH THE PRODUCT BY THE MANUFACTURER.

WARNING: Improper installation, adjustment, alteration, service or maintenance can damage the

water heater, or create a hazard resulting in asphyxiation, explosion or fire.

WATER FLOW

Low water content heat exchangers require continuous flow for proper operation.

WATER CONDITIONS:

Domestic Hot water heaters are designed for operation with various water conditions. Corrosive water that has

high chlorine content or other chemicals require that the tubes in the heat exchanger be cupro-nickel. Provide us

with an analysis of water where this potential exists.

BASE REQUIREMENTS

Indoor water heaters must be installed on a level noncombustible surface, except as noted below. Do not install

on carpeting. Heater sizes 926 to 1758 Typhoon (Outdoor) are supplied with a combustible flooring base as

standard. The following chart lists the part number required for a combustible base, for water heaters supplied

without a combustible base.

COMBUSTIBLE FLOOR BASE

BOILER PART BOILER PART BOILER PART BOILER PART

136 001749 399 058316 825 056202 1337 059236

181 058313 512 056199 962 059233 1467 059237

264 058314 627 056200 1125 059234 1630 059238

331 058315 726 056201 1223 059235 1826 059239

Fig. #8276

Hollow concrete cinder block; align holes and leave ends open.

Alternative method for providing a non-combustible base.

HEATER INSTALLATION

ON CONCRETE BLOCKS OR TILE

HEATER WITH COMBUSTIBLE

FLOOR SHIELD

Fig. #8148.1

COMBUSTIBLE CONSTRUCTION CLEARANCES

The water heater should be positioned to provide the minimum clearances from combustible surfaces and to

provide sufficient space for servicing the unit as follows.

MINIMUM CLEARANCES: PROTECTED SURFACES

Clearances to surfaces installed

in rooms which are large (2) in

comparison with size of heater.

Rear 12" 9 6 4 6 4 4 4 4

Left Side 12" 9 6 4 6 4 4 4 4

136 Right Side 6" 5 3 3 6 2 3 3 3

Indoor Top 42" 42 42 42 42 42 42 42 42

Rear 12" 9 6 4 6 4 4 4 4

Left Side 12" 9 6 4 6 4 4 4 4

181-399 Right Side 12" 9 6 4 6 4 4 4 4

Indoor Top 39" 39 39 39 39 39 39 39 39

Outdoor Top(1)

Rear 12 9 6 4 6 4 4 4 4

Left Side 18 12 9 6 6 6 6 6 6

512-825 Right Side 6 5 3 3 6 2 3 3 3

Indoor Top 36 36 36 36 36 36 36 36 36

Outdoor Top (1)

Rear 24 16 12 8 8 8 8 8 8

Left Side 24 16 12 8 8 8 8 8 8

926-1826 Right Side 24 16 12 8 8 8 8 8 8

Indoor Top 24 24 24 24 24 24 24 24 24

Outdoor Top (1)

(1) Unobstructed.

(2) Large rooms are defined as having a volume at least 16 times the total volume of the heater.

(3) Installation clearances for heaters in rooms not large in comparison with the heater size shall be as listed

under combustible surfaces and shall not be reduced by the protection methods.

SERVICING CLEARANCES: 24" in front of heater for removal of burner tray.

18" on side opposite water connection for deliming of Heat Exchanger on

Models 181-1826 only.

Combustible Surfaces

(a) 3 1/2-in. thick masonry wall with-

out ventilated air space

(b) 1/2-in. insulation board over 1-in.

glass fiber or mineral wool batts

or mineral wool batts reinforced with wire

on rear face with ventilated air space

(d) 3 1/2-in. thick masonry wall with venti-

lated air space

(e) 0.024 sheet metal with ventilated air

space

(f) 1/2-in. thick insulation board with

ventilated air space

(g) 0.024 sheet metal with ventilated

air space over 0.024 metal with

ventilated air space

(h) 1-in. glass fiber or mineral wool

batts sandwiched between two sheets

0.024 sheet metal with ventilated air

space

COMBUSTION AND VENTILATION AIR SUPPLY

CAUTION: Combustion air must not be contaminated by corrosive chemical fumes which can damage the heater

and void the warranty.

IMPORTANT: Adequate air must be provided for proper combustion and ventilation of the surrounding area. An

inadequate supply of combustion air will result in incomplete combustion and eventual sooting of the heater.

Insufficient ventilation will cause excessive heat and rapid deterioration of electronic and electrical components.

Equipment rooms should be provided with TWO permanent air supply openings directly connected to outside air.

Each opening must have a minimum FREE area of one square inch per 4000 BTU per hour input of the total input

rating of all equipment in the room. Local codes or authorities having jurisdiction should be consulted for the following

table.

RECOMMENDED MINIMUM AIR OPENINGS

NET NET NET

BOILER FREE BOILER FREE BOILER FREE

SIZE AREA SIZE AREA SIZE AREA

136 34 512 128 1125 282

181 47 627 157 1223 306

264 66 726 182 1337 335

331 84 825 207 1467 367

399 100 962 241 1630 408

All area shown in square inches 1826 457

For other conditions refer to the latest edition of the National Fuel Gas Code ANSI Z 223.1. Net free area, sq. in.

requires data from louver manufacturer based on resistance of screening, if provided.

OUTDOORINSTALLATIONS

MODEL 136

Step 1: Remove the front (4) screws

Step 2: Line up outdoor top vent opening over heater

vent opening.

Step 3: Lower outdoor top onto unit lining up slots in the

outdoor top with screws holes in jacket top.

Step 4: Reinstall (5) screw to secure jacket top and

outdoor top to unit.

Fig. # 8114

MODEL 181-399

VENT TERMINAL (Outdoor) Stackless Top Installation

1. Insert tabs into keyhole (4 places).

Pagoda Top

(Shipped

Loose with

Heater)

Table des matières

Autres manuels Rheem Chauffe-eau

Rheem

Rheem TRITON GHE80SU-130A Manuel utilisateur

Rheem

Rheem RUUD AdvantagePlus Mode d'emploi

Rheem

Rheem 265 series Manuel utilisateur

Rheem

Rheem 82VP30 Manuel utilisateur

Rheem

Rheem Richmond RMTGH-95DVLP Manuel utilisateur

Rheem

Rheem RSID50 Manuel utilisateur

Rheem

Rheem STID30 Manuel utilisateur

Rheem

Rheem 511161 Document technique

Rheem

Rheem GE Series Manuel utilisateur

Rheem

Rheem PROE20 1 RH POU Manuel utilisateur

Rheem

Rheem 884 Series Document technique

Rheem

Rheem RTG-66DV Manuel utilisateur

Rheem

Rheem Residential Solar Water Heater with Heat... Manuel utilisateur

Rheem

Rheem AdvantagePlus HE119-130LP Manuel utilisateur

Rheem

Rheem RS120-64BP Manuel utilisateur

Rheem

Rheem PVR50-80 (NAT) Manuel utilisateur

Rheem

Rheem Stellar 8A0 330 Document technique

Rheem

Rheem Power Direct Vent Series Manuel utilisateur

Rheem

Rheem 22DV40S-36N Manuel utilisateur

Rheem

Rheem Raypak 408A Manuel utilisateur

Rheem

Rheem PVS 40-33(NAT) HA Manuel utilisateur

Rheem

Rheem Multipak MPE02 Document technique

Rheem

Rheem PRO40-40FY1 Manuel utilisateur

Rheem

Rheem RTE 3 Manuel utilisateur

Manuels Chauffe-eau populaires d'autres marques

Kenmore

Kenmore 153.582400 Manuel utilisateur

Applimo

Applimo Edel AIR Manuel utilisateur

STIEBEL ELTRON

STIEBEL ELTRON Eltronom SHU 5 S Manuel utilisateur

clage

clage E-Mini Series Manuel utilisateur

Toyotomi

Toyotomi Oil Miser OM-180 Manuel utilisateur

Bradford White

Bradford White EF Series Manuel utilisateur

Eccotemp

Eccotemp 40-H Manuel utilisateur

Dimplex

Dimplex ECSd125-580 Mode d’emploi

Dux

Dux 32FCR6N Manuel utilisateur

Toyotomi

Toyotomi Oil Miser OM-148 (Type D) Guide de dépannage

Noritz

Noritz N-132M Manuel d'instructions

TESY

TESY GCV7/4S 10047 Fiche technique

A.O. Smith

A.O. Smith Gphe 50 Manuel utilisateur

Koryo

Koryo KWHZF15Y Manuel utilisateur

Pentair

Pentair PSC-14-4-02 Manuel utilisateur

GE 40M06AAG Instructions de montage

Thermor

Thermor AEROMAX SPLIT 2 Manuel utilisateur

American Hometec

American Hometec AHQ-B03X Manuel utilisateur
