Revolve Electronics ?eMilo Manuel utilisateur

Owner’s Manual

χeMilo

Quick Start

IMPORTANT: Conrm compatibility of χeMilo power inputs

and outputs with external device(s) before making any

external connection(s) (see specications).

Install and fully charge the xeSuperPack battery

prior to use.

To connect the χeMilo to a power source:

Having Trouble? See How to Use the χeMilo or refer the

Troubleshooting Guide in this manual for more information.

* Extreme heat may damage the χeMilo, which is not covered by the limited

warranty. Avoid exposing χeMilo to temperatures above 104°F (40°C).

To charge external devices, use cable to connect to

USB power output(s).

Specications

POWER

AC INPUT: 100-240V AC 50/60Hz 130mA

USB INPUT: 5V DC 2A

USB OUTPUT: 5V DC 2.8A max (total)

BATTERY

2 X 2200 mAh Lithium Ion (4400 mAh total)

PV PANEL

5V 1.2 Watts

This package includes:

- χeMilo

- χeSuperPack Battery

- USB A to USB Micro B Cable

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

CAUTION: Changes or modications not expressly approved by Revolve Electronics, Inc. for

compliance with FCC rules and regulations could void authority to operate this equipment.

CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used

batteries according to instructions. χePowerPack battery is designed exclusively for use with

Revolve Electronics’products. DO NOT USE WITH ANY OTHER PRODUCTS.

Revolve Electronics, Inc.

2151 Alessandro Dr, Ste. 250

Ventura, CA 93001

Phone (800) 693-0068 Fax (805) 435-2063

Place in sunlight* Connect to USB source Plug into AC outlet

CHARGE/SYNC CHARGE

How to Use the χeMilo

The χeMilo has been designed to help simplify your life. The

χeMilo will charge any small electronic device that accepts

5V DC (USB standard) – even iPad and other tablet devices!

You no longer need to carry multiple power supplies for your

devices. Plus, the χeMilo has a built in battery to provide

power to compatible devices on the go.

Connecting to Power

IMPORTANT: Conrm compatibility of χeMilo power inputs

and outputs with external device(s) before making any

external connection(s) (see specications).

To connect the χeMilo to a power source:

Place it in direct sunlight.

Plug it into an AC outlet.

Connect the χeMilo power

input to an external power

source such as a computer or

car charger with a USB cable.

Or, connect to any combination of A, B, or C !

Special Note: If you connect the χeMilo to a car charger that

is not iPod/iPhone‑compatible, the CHARGE/SYNC output on

the χeMilo will not be iPod/iPhone‑compatible. We recom‑

mend Revolve’s χePico charger to maximize compatibility.

Charging External Devices

IMPORTANT: Install and fully charge the xeSuperPack

battery prior to use.

To charge external device(s), connect up to two compatible

devices to the χeMilo’s USB power output(s) using USB

cable(s).

Note: Some devices require a proprietary connector to connect

to a power source. Since USB adapters are widely available to

accommodate such connectors, we have not included adapters with

the χeMilo to eliminate the potential waste that could result from

including adapters that you may not use or need.

Note: Approximately 15 hours of

direct sunlight are needed to fully

recharge the χeMilo. Exposing the

χeMilo to temperatures above 104°F

(49°C) may cause damage that is not

covered by the limited warranty.

POWER OUTPUTS

Example: Connecting to iPhone

Device Compatibility

Both χeMilo outputs have been designed to be compatible

with a wide variety of devices that accept 5V DC power (USB

standard), with the following limitations:

Checking Charging Status

When the χeMilo is generating Light

Assisted Power®, the green LED on the

face of the χeMilo will illuminate. When

the χeSuperPacks is storing energy from

any sources, the charge status LED will

illuminate red. When the χeSuperPack is

completely charged, the charge status

LED will illuminate green.

Checking Backup Battery Status

To determine the amount of energy stored in the χeSuperPack,

press the Battery Status Button.

This output is compatible with iPad and most smart devices, but is

only compatible with certain iPod models when the χeMilo is also

connected to a computer or external iPod charger, like the χePico.

Charge Status

Light Assisted Power™

Replacing the Battery

The χeSuperPack is an advanced lithium-ion battery designed

for years of service. To obtain a replacement battery and

participate in our hassle-free battery recycling program,

contact Revolve Electronics Support at www.revolveUSA.com

or by calling us toll-free at (800) 693-0068.

CAUTION: The χeMilo is designed to work exclusively with Revolve’s

χeSuperPack, which is included in this package. Risk of explosion if

battery is replaced by an incorrect type. Dispose of used batteries

according to instructions.

Installing/Replacing the Battery

To install battery:

Place your χeMilo on a flat surface.

Align the contacts inside xeMilo

with the contactson the battery.

Insert the battery as shown

until it lays flat inside the battery

compartment.

Tilt the battery door and insert the

two tabsintothematchingnotches.

Gently push the slotted latch of the

battery door together and down at

the same time until the door is fully

seated and latched.

Red = Recharge Now Yellow = Medium Green = Recharged

Battery Status Button

This output is compatible with iPod and iPhone,

but is not compatible with certain smart devices

like Flip.

PUSH

HERE

You Are Making a Dierence

Reducing Your Carbon Footprint

When using a traditional AC charger to recharge your

electronic devices, you connect to an AC outlet and draw

power from the power grid. Grid power is typically generated

using carbon emitting fossil fuels, like coal, oil, and natural gas.

As a result, when you use regular AC chargers to recharge your

devices, you are contributing to environmental pollution.

The χeMilo’s exclusive Light Assisted Power® generates and

stores clean, green power to recharge your compatible

electronic devices. By making the choice to place your χeMilo

in the sunlight and recharge with Light Assisted Power®,

you reduce your need for grid power by using energy from

the sun to trickle charge your batteries. With Light Assisted

Power®, the χeMilo empowers you to make a positive change.

Eliminating Waste

The χeMilo’s packaging has been made from 100% post

consumer recycled material. We encourage you to keep these

materials out of the landll by separating and recycling them,

so that they may be used again.

Unlike proprietary AC chargers that become obsolete

and battery backups that wear out, the χeMilo has been

designed to be compatible with a wide range of devices

and deliver many years of use. The χeMilo uses USB standard

power specications that have been widely adopted by the

electronics industry. Organizations like the International

Telecommunications Union are implementing initiatives

designed to expand the

adoption of these power

standards to make them

truly universal. As a result,

your χeMilo will provide

power to a wide range of

products both now and in

the future.

After hundreds of charge

cycles, dead batteries

won’t turn your χeMilo into

waste – the χeSuperPack

is easily replaced. The χeSuperPack battery uses advanced

lithium ion technology to provide maximum service life.

However, no battery will last forever. When you are ready

for a new batteries, contact Revolve Electronics Support

either at www.revolveUSA.com or by calling (800) 693-0068

to purchase replacements and participate in our hassle-free

battery recycling program.

Exercising Your Voice

By purchasing the χeMilo, you have made a powerful choice.

You have chosen to support a company that believes in a

healthy planet, a sustainable lifestyle, a rich life experience,

and the idea that these goals are not mutually exclusive.

Revolve Electronics has made very conscious choices in the

design and manufacturing of this product to include “green”

features and use sustainable materials and processes. Your

purchase has helped to validate the eorts of our team and

makes it possible for us to continue to oer products that

make a positive impact.

The team that has made this product possible is composed

of hundreds of people around the globe. From the χeMilo’s

designers to the engineers, from the sourcing agents to

assembly workers, our entire team appreciates you for

enabling us to pursue our passions, dreams, and aspirations.

In a very real and tangible way, we are now connected. To

learn more about the story behind the people you have just

made a connection with, visit us at www.revolveUSA.com.

A Helping Hand

Every year, Revolve Electronics contributes 10% of our prots

towards assisting“green”entrepreneurs.The best part is that

you get to help us decide who receives this assistance.

Simply visit us online at www.revolveUSA.com, register

your product, and you can cast your vote for the organization

that you’d like to receive our money.

Recycling Guide

Packaging – To recycle the χeMilo packaging material

properly, please separate the recycled plastic panel from the

recycled cardboard box before depositing into a recycling

bin.

Battery – To obtain a replacement batteries and participate

in our hassle-free battery recycling program, contact Revolve

Electronics Support at www.revolveUSA.com or by calling

(800) 693-0068.

Electronics – While Revolve Electronics has designed the

χeMilo to provide you with many years of service, you may

eventually need to dispose of it. To do so without causing

harm to the environment, we suggest that you contact a local

electronics recycler near you. To locate one, please visit:

NCER US Directory: www.electronicsrecycling.org or

IAER World Directory: www.iaer.org/search/

Troubleshooting Guide

Step 1: Verify Compatibility – Before connecting any device

to the χeMilo, check the power requirements for the device.

The device must match the input or output requirements of

the χeMilo. For example, the χeMilo’s output is 5V DC and

the external device(s)’ current demand must not exceed 2.1A

(peak). If the voltage does not match (i.e. 6V, 9V, etc.), or the

current draw exceeds 2.1A (i.e. 2200mA, 2.2A, etc.), do not

connect it to the χeMilo.

Step 2: Check the Cable – Unplug, then reconnect the cable.

Revolve cables are high-quality and designed to meet the

χeMilo’s requirements. Some cables do not connect all lead

points and cables can easily get damaged or short out. If

problem persists, replace cable with a new cable and retest.

Step 3: Check Battery Status Indicator – If your compatible

device is not charging from the χeMilo and you have replaced

the cable, check the χeMilo’s battery status by pressing the

battery status indicator button next to the USB outputs on

your χeMilo. If the green light does not illuminate, connect the

χeMilo to a power source and allow the χeMilo to recharge.

Note: Your χeMilo has built in battery protection circuitry that

will automatically turn o your battery when the charge level

is too low. To recover, simply connect your χeMilo to a power

source and allow 4‑6 hours for it to fully recharge.

Service

To obtain service of your χeMilo, contact Revolve Electronics

Support department online at www.revolveUSA.com or by

calling (800) 693-0068.

LIMITED WARRANTY

Revolve Electronics, Inc. (“the Company”) warrants to the original purchaser that this

equipment will be free from defects in materials and workmanship for a period of 1 (one)

year from the original date of purchase. If a defect exists that is covered by this Limited

Warranty, the Company will, at its sole option, (i) repair the product at no charge, using

new or refurbished replacement parts, (ii) exchange the product with a product that is

new or which has been manufactured from new or serviceable used parts and is at least

functionally equivalent to the original product, or (iii) refund the purchase price of the

product. A replacement product/part assumes the remaining warranty of the original

product or ninety (90) days from the date of replacement or repair, whichever provides

longer coverage for you. When a product or part is exchanged, any replacement item

becomes your property and the replaced item becomes the Company’s property. When

a refund is given, your product becomes the Company’s property. All warranty returns

must be sent postage and insurance prepaid.

LIMITATIONS

This Limited Warranty applies only to hardware products manufactured by or for the

Company.This LimitedWarranty does not apply to any non-Company hardware products

or any equipment, even if packaged or sold with Company hardware. This warranty

does not apply: (a) to damage caused by accident, abuse, misuse, misapplication, or

non-Company products; (b) to damage caused by service (including upgrades and

expansions) performed by anyone other than the Company; (c) to a product or a part

that has been modied without the written permission of the Company; or (d) if any

Company serial number has been removed or defaced.

Responsibility is limited to the actual cost of the item. Revolve Electronics, Inc. will not

be responsible for expenses or inconveniences, or consequential damages occasioned

by equipment, or by breach of any expressed or implied warranty with respect thereto.

Implied warranties on this item shall be in eect only for duration of the expressed

warranty set forth above and after the expiration of such expresses warranty there shall

be no warranties, expressed or implied (including merchantability) on the product.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Revolve Electronics Bloc de piles

Revolve Electronics

Revolve Electronics Rescue2200 Manuel utilisateur

Manuels Bloc de piles populaires d'autres marques

Acumentrics

Acumentrics PACK-POWER SYSTEM Manuel utilisateur

ACDC Dynamics

ACDC Dynamics SPF12-50 Manuel utilisateur

Aegis

Aegis ABL-72020P Manuel utilisateur

Dyness

Dyness TowerESS Manuel utilisateur

Growatt

Growatt APX 5.0P-S0-US Manuel utilisateur

EGO

EGO BAX1300 Manuel utilisateur

CyberPower

CyberPower BCA Series Manuel utilisateur

Intermec

Intermec 700 Series Manuel utilisateur

Dometic

Dometic PLB40 Manuel utilisateur

V-TAC

V-TAC VT-48280-W2 Manuel utilisateur

Valence

Valence RT Manuel utilisateur

Nikon

Nikon MB-D14 Manuel utilisateur

IOGear

IOGear GBP24V Series Manuel utilisateur

Inventus Power

Inventus Power PROTRXion S-12V100-TRX-HD Manuel utilisateur

Clas Ohlson

Clas Ohlson PW-290A Manuel utilisateur

EINHELL

EINHELL MULTI-Ah Power X-Change Plus Manuel utilisateur

Samsung

Samsung EB-U3300 Manuel utilisateur

ECTIVE

ECTIVE LC Series Manuel utilisateur
