Revere Aero Compact 2 Manuel utilisateur

REVISION RECORD

Feb 25/11

9105 RR - 1

DOCUMENTING A REVISION

Record the Revision No. and Revision Date. Remove the old sheet and replace it with the revised copy.

Record the Insert Date and then initial in the Inserted By column.

Revisions made ONLY by Revere Supply, Inc.

REV. No.

REV.

DATE

INSERTED

REV. No.

REV.

DATE

INSERTED

DATE

Original

Feb 25/11

RR - 2 9105

THIS PAGE INTENTIONALLY LEFT BLANK

SERVICE BULLETIN

Feb 25/11

9105SB - 1

All service bulletins which are incorporated into this manual are required to be recorded in this list.

All updates to this list will be made by the owner of the manual.

SERVICE

BULLETIN No.

DATE

TITLE/DESCRIPTION

REV. No.

DATE OF

INCORPORATION

Feb 25/11

SB - 2 9105

THIS PAGE INTENTIONALLY LEFT BLANK

SERVICE BULLETIN NO. 09/16A

Sept 20/2016

9105SB - 1

5323 Highway Avenue

Jacksonville, FL 32254

(T) 904.503.9733

(F) 904.503.9719

1. INTRODUCTION

This service bulletin is to advise service stations of the change in valves, firing heads and cylinders

for the Aero Compact liferafts.

Starting from July, 2014 all Aero Compact rafts produced by Revere will now be equipped with the

following valves

Pressure Relief Valve: Thanner OTS-45 (Revere P/N 95-324-004)

Topping Off Valve: Mirada A-52030 (Revere P/N 95-326-009)

Inlet Check Valve: Mirada B-51994 (Revere P/N 95-325-005) 3/8-18NPSM

Universal Flange (PU): Mirada B-51073 (Revere P/N 95-326-001)

As a result of the inlet check valve replacement, new firing heads are required for all rafts starting

in July 2014.

Raft Number

Firing Head

Cylinder

Aero Compact 2 (45-AC2V)

95-41115-103

(Circor M70 w/ 3/8-18 NPSM)

95-327-061 (61in3) Re-fillable

Aero Compact 4 (45-AC4V)

95-41115-103

(Circor M70 w/ 3/8-18 NPSM)

95-327-061 (61in3) Re-fillable

The purpose of the technical update is to show the new items and procedures to follow for the

servicing of the inflation system with the new firing heads.

2. EMBODIMENT DATE

Mandatory at next service.

SERVICE BULLETIN NO. 09/16A

Sept 20/2016

9105SB - 2

5323 Highway Avenue

Jacksonville, FL 32254

(T) 904.503.9733

(F) 904.503.9719

3. VALVE IDENTIFICATION

Thanner OTS-45 Mirada A-52030 Mirada B-51994

4. FIRING HEAD 95-41115-103 (M70) OPERATING INSTRUCTIONS

See Chapter 8 –Assembly and Packing, Inflation Valve Disassembly & Rebuilding Process for

instructions on servicing the 41115 inflation valve. All service instructions remain the same, but

note the outlet fitting is now 3/8-18 NPSM rather than the previous fitting of 1/2-20 UNF.

3/8-18 NPSM

SERVICE BULLETIN NO. 09/16A

Sept 20/2016

9105SB - 3

5323 Highway Avenue

Jacksonville, FL 32254

(T) 904.503.9733

(F) 904.503.9719

5. PRV OTS-45 INSTALLATION

The OTS 45 relief valve consists of 4 main elements:

1. Valve body section.

2. Nut.

3. Washer / washer with closing cap.

4. O-ring.

The valve parts are produced from Acetal Copolymer (1+2+3)

The seal/o-ring (4) is made of silicone rubber.

INSTALLATION:

When the nut (2) is in position inside the tube, the washer (3) is placed over the hole with the

o-ring (4) in the center.

Cutting hole in the fabric: 22 mm

IMPORTANT

The grip rings of the washer (3) must be placed towards the fabric.

The valve body (1) is screwed into the nut through the fabric by hand, before any tools are used. The

valve is tightened to the raft and finally by torque tool. Depending of the fabric –reinforcement can be

necessary. Check the color code of the valve for the right pressure.

TIGHTENING:

To tighten the valve use a 32 mm top spanner/torque tool.

Tightening torque: 6 –8 Nm

SERVICE BULLETIN NO. 09/16A

Sept 20/2016

9105SB - 4

5323 Highway Avenue

Jacksonville, FL 32254

(T) 904.503.9733

(F) 904.503.9719

NOTE:

The valve must not be re-tightened after installation. If a leakage appears between the fabric and the

relief valve, the valve must be taken apart and reinstalled until tight.

IMPORTANT:

If using the closing cap, be careful the cap is not fitted to the valve during packing. The locked valve

may damage the raft during inflation.

CAUTION:

Do not separate the spring, washer and valve piston.
