Returnstar Interactive Tech IQBoard IRQ Manuel utilisateur

Returnstar Interactive Technology Group Co., Ltd.

IQBoard IRQ

User Manual

Web: www.iqboard.net; www.recoverystar.com

Tel: 0086-591-87274373

Fax: 0086-591-87274383

E-mail: master@iqboard.net

Returnstar Interactive Technology Group Co., Ltd.

Statement

This manual is for IQBoard IRQ.

Both Whiteboard and Interactive Whiteboard in this manual refer to IQBoard IRQ.

Colorless Writing Pen (Finger) is used for IQBoard IRQ.

Use this product strictly according to detailed operation instruction in this manual so

as to ensure proper use. Please read this manual carefully before you install this

product.

Opening the package means you have agreed to purchase this product, Returnstar

will not accept returns of opened packages.

The product specification may be subject to change without prior notice. The sample

pictures in this User Manual may differ from the real product.

Returnstar reserves all rights to charge the fee at anytime for product replacement,

revision and update. The information in this manual is subject to regular change

without prior notice. Returnstar will make no warranties with respect to this product

and disclaims any warranties, whether express or implied, of merchantability and

fitness for a particular purpose.

Trademark Notice

Returnstar, IQ and IQBoard are registered trademarks of Returnstar Interactive

Technology Group Co., Ltd.. Windows is a registered trademark of Microsoft

Corporation.

Recycling

Always return your used electronic products, batteries, and packaging materials to

separate collection. This way you help prevent uncontrolled waste disposal and

promote the recycling of materials.

Temperature and Humidity Requirements

Storage

Temperature: -40°C ~ 60 °C Humidity: 0% ~ 95%

Operation

Temperature: -20°C ~ 50 °C Humidity: 15% ~ 85%

Returnstar Interactive Technology Group Co., Ltd.

CONTENT

CHAPTER 1 PRODUCT INTRODUCTION ...............................................................................................3

CHAPTER 2 SPECIFICATIONS...............................................................................................................5

2.1 PERFORMANCE ................................................................................................................................... 5

2.2 FLEXIBLE FIXING AND RELOCATING METHODS .......................................................................................... 5

2.3 DURABLE SURFACE,SOLID BODY ........................................................................................................... 5

2.4 PC CONNECTION................................................................................................................................. 5

2.5 SYSTEM REQUIREMENTS....................................................................................................................... 5

CHAPTER 3 HOW TO INSTALL IQBOARD..............................................................................................6

3.1 MOUNT WHITEBOARD （WALL MOUNTING BRACKET）......................................................................... 6

3.2 WALL MOUNTING（L-TYPE BRACKET）................................................................................................ 8

3.3 STAND MOUNTING............................................................................................................................ 10

CHAPTER 4 HOWTOCONNECTTOCOMPUTERANDPROJECTOR...................................................................... 16

CHAPTER 5 HOW TO INSTALL AND UNINSTALL DRIVER..................................................................... 17

5.1 HOW TO INSTALL DRIVER.................................................................................................................... 17

5.2 HOW TO UNINSTALL DRIVER ............................................................................................................... 17

CHAPTER 6 HOW TO SETUP IQBOARD ..............................................................................................18

6.1 ORIENTATION ................................................................................................................................... 18

6.2 HOTKEY SETTINGS ............................................................................................................................. 19

CHAPTER 7 HOW TO USE IQBOARD .................................................................................................. 21

7.1 BASIC OPERATIONS ........................................................................................................................... 21

7.2 HOW TO USE HOTKEYS ON WHITEBOARD.............................................................................................. 22

7.3 HOW TO USE SMART PEN TRAY ........................................................................................................... 23

7.4 MULTI-USER WRITING ....................................................................................................................... 24

CHAPTER 8 FAQ ................................................................................................................................ 26

CHAPTER 9 CAUTIONS AND MAINTENANCE ..................................................................................... 28

9.1 WHITEBOARD................................................................................................................................... 28

9.2 USB CABLE...................................................................................................................................... 29

9.3 PROJECTION ..................................................................................................................................... 29

9.4 TRANSPORT ..................................................................................................................................... 29

9.5 PART REPLACEMENT .......................................................................................................................... 29

Chapter 1 Product Introduction

IQBoard IRQ is the latest interactive presentation boards. Connect the whiteboard

with your computer and projector, then simply touch the projection area with your pen

Returnstar Interactive Technology Group Co., Ltd.

or your finger, you can transform the pen or your finger to Mouse and directly operate

the computer on the projection area. With IQBoard Software, Multi users can operate

simultaneously on the board.

With IQBoard IRQ and IQBoard Software, marvelous interactive communicating

effects can be achieved in live demonstration, teaching, product exhibition, business

conference, video communication, news broadcast, securities evaluation, military

command, entertainment, medical consultation, engineering design, competition

tactics analysis, weather analysis, etc.

IQBoard IRQ is provided with powerful IQBoard Software, which makes your

operation on interactive whiteboard more convenient. Through IQBoard Software,

various interactive teaching and demonstrating functions can be achieved, such as

write, erase, label (in character, line, dimension and angle), drag, zoom, reveal screen,

spotlight, screen capture and save, screen record and playback, handwriting

recognition, on-screen keyboard, text input, text to speech, hyperlink to video, sound

and webpage, and remote conference by NetMeeting. IQBoard Software also has

colorful object animation effects, page switching effects and interactive questions.

Therefore, with IQBoard Software, users can make more interactive courseware by

designing unique object animation, adding sound or hyper linking.

IQBoard Software also includes 500M IQBoard Resource Library covering more than

30 subjects, such as math, physics, chemistry, biology, gymnasium, etc. User can

customize the installation by selecting subjects. The software also provide common

line, shape, character, symbol, decoration graph, background template, Flash

courseware, and other resources. Moreover, the software supports importing various

picture files and DOC(X), PPT(X), XLS(X), PDF files. The page and file created by

IQBoard Software can be saved as and freely converted to various picture files as well

as DOC(X), PPT(X), XLS(X), PDF, html files, etc.

We provide continuous upgrading service for IQBoard Software. For more information

and detailed operation about IQBoard Software, please refer to IQBoard Software

User Manual in the installation CD.

Returnstar Interactive Technology Group Co., Ltd.

Chapter 2 Specifications

2.1 Performance

Resolution: 9600×9600

Signal tracking rate: 8m/s;

Signal processing rate: 480 dots/s;

Orientation: 4, 9 or 20 points

2.2 Flexible Fixing and Relocating Methods

Fixing methods include wall hanging, cabinets, and mobile stand. Provide optional

height adjustable mobile stand for 50-120 inch whiteboards, the height can be

adjusted from 1.88M to 2.12M.

2.3 Durable Surface, Solid Body

The surface adopts dedicated writing film made of DuPont anti-abrasive coating. It

features with anti-scratch, high luminance, high definition, easy cleaning (can be

cleaned by whiteboard detergent or wet cloth), and can completely eliminate bright

spots. The backboard, which is resistant to distortion, expansion and shrinkage,

adopts PS board with high density. Model supporting normal pen writing is also

provided.

2.4 PC Connection

Standard: 10m USB cable for connecting IQBoard with PC, external power is not

required.

Optional: USB signal amplifier to extend the USB cable to 20m.

2.5 System Requirements

Windows XP/2003/Vista/7/8

Intel C2.1 or higher

256 MB RAM or higher

1G free hard disk space (for full installation)

1 free USB port

1 projector (short throw or ultra-short throw projector recommended)

Returnstar Interactive Technology Group Co., Ltd.

Chapter 3 How to Install IQBoard

Choose a mounting way from below according to your board model.

3.1 Mount Whiteboard （Wall Mounting Bracket）

Parts list


Name

Quantity

Screw

Wall Anchor

Safety Bracket

Anchor Bolt

Wall Mounting Bracket

(already mounted on the

backboard)

Installation steps

Step 1. Determine the installation height of the Anchor Bolt (190cm above floor), then

measure the horizontal distance L (70cm recommended) of the two holes on the wall

mounting bracket according to the location of the whiteboard. Drill a hole at both ends,

then screw the 2 Anchor Bolts into the holes and leave 4mm clearance between bolt

head and nut (as shown in the figure below).

Step 2. According to the distance of the two Anchor Bolts, fix the Wall Mounting

Returnstar Interactive Technology Group Co., Ltd.

Bracket on each screw on the top frame of backboard. Please make sure to fix the

Wall Mounting Brackets symmetrically on the backboard to keep the balance (as

shown in the figure).

Step 3. Align the Wall Mounting Brackets on the backboard with the Anchor Bolts,

and hang the whiteboard on the wall.

Step 4. Fasten the 2 Safety Brackets on each side of whiteboard lower frame using 2

Screws. According to the location of the Safety Brackets, drill 2 mounting holes on

the wall. Finally, use Wall Anchors and Screws to fix the Safety Brackets on the wall.

Returnstar Interactive Technology Group Co., Ltd.

3.2 Wall Mounting（L-type Bracket）

Parts list

No.


Item

Qty

Flat Cross-tapping Screw

Wall Anchor

L-type Bracket

Installation steps

Step 1. Determine the fixed position and height of the IQBoard according to the actual

use of the site.

Step 2. Determine the installation height of the bottom L-type Brackets according to

the location of IQBoard on the wall. Then determine the installation height of the upper

L-type Brackets according to the size of your IQBoard. Make sure when you pull up

the upper brackets, IQBoard can be taken out; and when you pull them down,

IQBoard frame can be clasped. Two upper/bottom brackets should be on the same

height level. You will need 2 screws for each of bottom Brackets, and 1 screw for each

of the upper ones. To determine the position of brackets, take an 82”IQBoard for e.g.

as below:

IQBoard

L(mm)

H1(mm)

H2(mm)

82”

700

1175

Returnstar Interactive Technology Group Co., Ltd.

H1 H2

Note:

L: Horizontal distance between 2 upper/bottom brackets.

H1: Distance between the 2 screws on the same bottom bracket.

H2: Distance between the screw on the upper bracket and the upper screw on the

bottom bracket.

Note: Please measure L, H1 and H2 according to your own IQBoard size.

Returnstar Interactive Technology Group Co., Ltd.

Step 3. Drill 6 holes(70mm in depth) by a 6mm electric drill on the positions of the 6

screws you determined as per above. (2 holes for each of bottom bracket; 1 hole for

each of upper bracket)

Step 4. Put a Wall Anchor into each hole, and screw the brackets with M4*70 flat

cross-tapping screw.

Step 5. Put IQBoard on the fixed 4 L-type Brackets, and let it centered horizontally.

Fasten the upside screws and lock the downside screws.

3.3 Stand Mounting

Parts list


Name

Quantity

Leg Bar

Column

Supporting Bar

Caster

Moveable Crossbeam

(each includes 2 Beams and a

U-shaped Groove; for 100″, 112″

and 120″ whiteboards, Beams and

U-shaped Grooves are especially

lengthened)

Hexagon Bolt A

Table des matières

Autres manuels Returnstar Interactive Tech Tableau blanc

Returnstar Interactive Tech

Returnstar Interactive Tech IQBoard Manuel utilisateur

Manuels Tableau blanc populaires d'autres marques

Copernicus

Copernicus RC105 Manuel utilisateur

IKEA

IKEA MALA 104.889.67 Manuel utilisateur

SMART

SMART SBX800 Manuel utilisateur

SMART

SMART Board MX V3 Series Manuel utilisateur

funtronic

funtronic EasyBoard Manuel utilisateur

Best-Rite

Best-Rite Baby Folding Wheasel 784-T Manuel utilisateur

Best-Rite

Best-Rite Modular Room Divider Manuel utilisateur

IKEA

IKEA MALA 504.565.92 Manuel utilisateur

Panasonic

Panasonic TX-47P800HQ TX-47P800HZ Manuel utilisateur

SMART

SMART ST442i Manuel utilisateur

Quartet

Quartet QRT-72981 Manuel utilisateur

SMART

SMART Smart Board 480 Manuel utilisateur

EGAN

EGAN GlassWrite TableScreen TSG Manuel utilisateur

Claridge

Claridge Edify Mobile Manuel utilisateur

Legamaster

Legamaster e-Board Touch 2 Manuel utilisateur

Nureva

Nureva WALL Manuel utilisateur

Best-Rite

Best-Rite Black Splash Manuel utilisateur

Da-Lite

Da-Lite Cosmopolitan Electrol Manuel utilisateur
