Retractable Awnings KONYA Manuel utilisateur
SUNTECH -QUATTRO
Technical Details
All information contained in this document was provided by the
manufacturer of the components for this particular model. As a
fabricator/distributor, Retractableawnings.com Inc. claims no
liability with respect to these documents as we are not engineers
and did not complete any of the information, engineering or
calculations in this document.
All measurements in this document are metric. To convert from
metric (meters, centimeters and millimeters) to imperial (feet
and inches) visit this website:
http://www.onlineconversion.com/length_common.htm
KONYA
INSTALLATION
INSTRUCTIONS
Tel: (305) 628-2424 or
(866) 438-2964
All information contained in this document was provided by the
manufacturer of the components for this particular model. As a
fabricator/distributor, Retractableawnings.com Inc. claims no
liability with respect to these documents as we are not engineers
and did not complete any of the information, engineering or
calculations in this document.
All measurements in this document are metric. To convert from
metric (meters, centimeters and millimeters) to imperial (feet
and inches) visit this website:
http://www.onlineconversion.com/length_common.htm
Page 1
DIN 933
M8 x 25
STEP I
MOTOR SIDE
Quattro
Installation
GUTTER
160
160
10
DIN 933
M8 x 25
160
17
6
90
POST
GUTTER
Page 2
STEP II
FRONT SIDE
Quattro
Installation
GUTTER
160
17
6
90
160
160
10
DIN 933
M8 x 25
DIN 933
M8 x 25
Page 3
Quattro
Installation
RAFTER SIDE GUTTER
STEP III
RAFTER SIDE GUTTER
SLICONE
DIN 7504-P
4,2x19
RAFTER SLICONE
SLICONE
DIN 7504-P
4,2x19
RAFTER
RAFTER SIDE GUTTER
Page 4
STEP IV
Quattro
Installation
RAFTER
ISO 7380-A2
M8 x 16
90,6 mm
ISO 7380-A2
M8 x 16
Page 5
ISO 7380-A2
M8 x 20
ISO 7380-A2
M8 x 20
MOTOR BOX
Quattro
Installation
MOTOR BOX
STEP V
M8x12
M8x12
SQUARE MIL ISO 7380-A2
M8 x 20
M8x12
MOTORBOX SUPPORT
PLATE
Page 6
Quattro
Installation
TOP COVER
STEP VI
TOP COVER
ISO 7380-A2
M8 x 20
ISO 7380-A2
M8 x 20
ISO 7380-A2
M8 x 20
M8x12
M8x12
M8x12
MOTORBOX SUPPORT
PLATE
Page 7
LIGHTING CHANNEL
LIGHTING CHANNEL
DIN 7504-P
4,2x19
DIN 7504-P
4,2x19
Quattro
Installation
TOP COVER
STEP VII
Page 7
Page 8
STEP VIII
Installation of fabric
FABRIC
DIN 7040
M8 PREVAILING
TORQUE NUT
DIN 7040
M8 WASHER
Quattro
Installation
PULLER BAR
(BACK)
MIDDLE SUPPORT BAR
PULLER BAR
(FRONT)
Page 8
Page 9
RAFTER TOP CAP
DIN 7504-P
4,2x19
Quattro
Installation
RAFTER TOP CAP
STEP IX
Page 10
