Renogy ONE M1 Manuel utilisateur

VERSION A0

Renogy ONE

User Manual

Applicability

The user manual applies to the following product:

zRenogy ONE M1

Disclaimer

zRenogy makes no warranty as to the accuracy, suﬃciency, or suitability of information in the

user manual because continuous product improvements are going to be made.

zRenogy assumes no responsibility or liability for losses or damages, whether direct, indirect,

consequential, or incidental, which might arise out of the use of information in the user

manual.

zRenogy is not responsible or liable for the failures, damages, or injuries resulting from repair

attempted by unqualiﬁed personnel or improper installation and operation.

zThe illustrations in the user manual are for demonstration purposes only. Details may appear

slightly diﬀerent depending on product revision and market region.

zRenogy reserves the right to change the information in the user manual without notice.

zRenogy ONE collects and uses your data in accordance with the Privacy Policy.

manual is subject to copyright and other intellectual property rights of Renogy and its licensors.

The user manual may not be modiﬁed, reproduced, or copied, in whole or in part, without the

prior written permissions of Renogy and its licensors.

Trademarks

The following are trademarks or registered trademarks of Renogy in the United States and other

countries and regions:

RENOGY

All other trademarks in the user manual are the property of their respective owners and their

use herein does not imply sponsorship or endorsement of their products or services. The

unauthorized use of any trademark displayed in the user manual or on the product is strictly

prohibited.

Date and Revision

March 2022, Revision A0

Table of Contents

Important Safety Information .......................................................................................................05

Symbols Used .........................................................................................................................05

General Safety Information .....................................................................................................05

Introduction ..................................................................................................................................07

General Information ................................................................................................................07

Key Features ...........................................................................................................................07

Package Contents .......................................................................................................................08

Product Overview ........................................................................................................................09

Wiring Diagram ............................................................................................................................11

Communication Diagram .............................................................................................................12

Renogy ONE Communication Architecture .............................................................................12

Energy Device Communication Connections ..........................................................................12

Preparation ..................................................................................................................................14

Required Tools ........................................................................................................................14

Inspection ................................................................................................................................14

Mounting Location ...................................................................................................................15

Power Wiring ...............................................................................................................................18

Communication Wiring (Optional)................................................................................................20

RS485 Communication ...........................................................................................................20

RV-C Communication ..............................................................................................................23

Load Wiring (Optional).................................................................................................................27

Mounting ......................................................................................................................................31

Activation .....................................................................................................................................32

Operation .....................................................................................................................................33

WLAN ......................................................................................................................................33

Pairing with App ......................................................................................................................33

Add Devices/Smart Accesories ...............................................................................................33

Power On/Oﬀ ...............................................................................................................................35

Control External Loads ................................................................................................................36

Technical Speciﬁcations ..............................................................................................................37

Troubleshooting ...........................................................................................................................38

FAQ .............................................................................................................................................40

Maintenance ................................................................................................................................42

Inspection ................................................................................................................................42

Cleaning ..................................................................................................................................42

Storage ....................................................................................................................................42

Emergency Responses ...............................................................................................................43

Fire ..........................................................................................................................................43

Flooding ..................................................................................................................................43

Smell .......................................................................................................................................43

Noise .......................................................................................................................................43

Technical Support ........................................................................................................................44

Dimensions ..................................................................................................................................45

Important Safety Information

The user manual provides important installation, operation, and maintenance instructions for

Renogy ONE M1. Read the user manual carefully before installation and operation and save it

for future reference. Failure to observe the instructions or precautions in the user manual can

result in electrical shock, serious injury, or death, or can damage Renogy ONE M1, potentially

rendering it inoperable.

Symbols Used

The following symbols are used throughout the user manual to highlight important information:

WARNIN

Indicates a potentially dangerous condition which could result in

injury or death.

CAUTIO

Indicates a critical procedure for safe and proper installation and

operation.

NOT

Indicates an important step or tip for optimal performance.

INFO

Indicates that more information is available in other documents

relating to the subject.

General Safety Information

WARNIN

zInspect Renogy ONE for any visible damage including cracks, dents, deformation, and other

visible abnormalities before installation.

zDo not puncture, drop, crush, penetrate, shake, strike, or step on Renogy ONE.

zDo not open, dismantle, repair, tamper with, or modify the components of Renogy ONE.

zInstall Renogy ONE on a vertical surface indoors protected from direct sunlight, high

temperature, and water. Make sure there is good ventilation.

zKeep Renogy ONE away from heating equipment.

zDo not insert foreign objects into Renogy ONE.

zKeep Renogy ONE out of the reach of children.

zIn order to prevent electric shock and protect personal safety, the installation shall be carried

out under the condition of power failure, and live operation is not allowed.

zWear proper protective equipment and use insulated tools during the installation or

disassembly of Renogy ONE.

zDo not touch the connector contacts while Renogy ONE is in operation.

zDisconnect all connectors from Renogy ONE before maintenance or cleaning.

zDo not dispose of Renogy ONE as household waste. Comply with local, state, and federal

laws and regulations and use recycling channels as required.

Important Safety Information

Symbols Used General Safety Information

Important Safety Information

zIn the event of ﬁre, use ﬁre extinguishers suitable for electrical equipment.

zIf Renogy ONE is installed improperly on a boat, it may cause damage to the corrosive

agents of the boat. Please have Renogy ONE installed by a qualiﬁed electrician.

CAUTIO

zDo not expose Renogy ONE to ﬂammable or harsh chemicals or vapors.

zEnsure that there is no water source including downspouts, sprinklers, or faucets above or

near Renogy ONE.

zRenogy ONE is only suitable for safe use in areas below 2,000 meters above sea level.

Symbols Used General Safety Information

Introduction

General Information

Renogy ONE M1 (hereinafter referred to as Renogy ONE) is your all-in-one energy monitoring

and oﬀ-grid smart living center that revolutionizes comfort when you live in your oﬀ-grid home or

RV.

It is the heart of your oﬀ-grid system with a sleek, ﬂush-mount touchscreen that looks great

anywhere. The 4’’ HD display lets you monitor every Renogy device in your home from one

screen. When Renogy ONE works in association with the DC Home app, you will have the same

system monitoring wherever you go on your smartphone.

Renogy ONE makes it possible to live oﬀ-grid without compromising comfort. It allows control of

up to three devices at a time through the direct connection with panel relays. In addition, Renogy

ONE delivers peace of mind with enhanced security feature for your oﬀ-grid home or RV. It is

compatible with our Smart Relay, Smart Plug, Door & Window Sensor, and Motion Sensor to

send instant alerts right to your DC Home app if there is a security breach.

Key Features

zAll-in-one Smart Panel

Renogy ONE gets rid of cumbersome cables and multiple monitors by connecting to Renogy

devices and smart accessories via Bluetooth, Zigbee, RV-C, and RS485. Its 4-inch HD

touchscreen lets you monitor and control all compatible Renogy devices in your home from one

screen with intuitive visuals and real-time data.

z24/7 Energy Monitoring Anywhere

Renogy ONE delivers all the performance data from connected devices directly to your smart

panel through Bluetooth or RS485 and RV-C communication cables. The Wi-Fi connectivity

uploads energy data while you are oﬀ grid, so you can monitor your system in real time,

wherever you are, with the DC Home app.

zConnected Living

Renogy ONE integrates with three panel switches that allow you to turn on or oﬀ up to three DC

appliances. When pairing Renogy ONE with the DC Home app, you can set up smart scenes to

control devices together depending on how you live. For instance, you can create an “Evening”

scene that automatically turns on lights or a “Sleep” scene that turns oﬀ your home appliances.

General Information Key Features

Package Contents

Renogy ONE M1 ×1 Quick Guide ×1

12V Power Cable (5m) ×1 M2 Screws ×4

ST2 x 1.2 x 6.5 mm

M4 Mounting Screws ×4

ST4 x 2 x 13 mm

Product Overview

21 3 4 5

No. Part No. Part

1Power Button 4 Panel Switch 2

2 Touch Screen 5 Panel Switch 3

3 Panel Switch 1

Product Overview

IN 1

+ -

IN 2

CAN/RS485 TYPE-C

OUT 1 OUT 2 IN 3 OUT 3

81 19 10

1 2 3 4 5 6 7 1

No. Part No. Part

1 Mounting Holes 6 IN 3 (External Load Input Terminal)

2 IN 1 (External Load Input Terminal) 7 OUT 3 (External Load Output Terminal)

3OUT 1 (External Load Output Terminal) 8Power Port (12V, 3.5W)

4 IN 2 (External Load Input Terminal) 9 RJ45 Port

5OUT 2 (External Load Output Terminal) 10 Alternate Power Input Port (Type-C,

5V, 3.5W)
