12V Pure Sine Wave Inverter Manual

BATTERY

POWER INVERTERS

700w 1000w 2000w 3000w

Important Safety Instructions

Please save these instructions.

This manual contains important safety, installation, and operating instructions for the

inverter. The following symbols are used throughout the manual:

Inverter Safety

The inverters are suitable for 12V Battery Banks ONLY.

ALWAYS make sure inverter is in OFF position and disconnect all AC and DC

connecting when working on any circuit associated with the inverter.

NEVER connect the AC output of the unit directly to an Electrical Breaker Panel/ Load

Centre which is also fed from the utility power / generator.

When connecting battery terminals, ensure the polarity of the battery connections is

correct. Incorrect polarity may cause permanent damage to the unit.

Be careful when touching bare terminals of capacitors as they may retain high lethal

voltages even after power is removed.

Installation and wiring must comply with the Local and National Electric Codes (NEC)

and must be done by a certified technician.

Read all of the instructions and cautions in the manual before beginning the installation.

There are no serviceable parts for this inverter. Do NOT disassemble or attempt to repair

the inverter.

Make sure all connections going into and from the inverter are tight. There may be

sparks when making connections, therefore, make sure there are not flammable

materials or gases near installation.

Indicates a potentially dangerous condition. Use extreme caution

when performing this task.

Indicates a critical procedure for safe and proper operation of the

inverter.

Indicates a procedure or function that is important to the safe and

proper operation of the inverter.

NOTE

CAUTION

WARNING

General Safety Information

Do NOT let the positive (+) and negative (-) terminals of the battery touch each other.

Use only sealed lead-acid, flooded, or gel batteries which must be deep cycle.

Explosive battery gases may be present while charging. Be certain there is enough

ventilation to release the gases.

Be careful when working with large lead acid batteries. Wear eye protection and have

fresh water available in case there is contact with the battery acid.

Over-charging and excessive gas precipitation may damage the battery plates and

activate material shedding on them. Too high of an equalizing charge or too long of one

may cause damage. Please carefully review the specific requirements of the battery

used in the system.

Battery Safety

The unit should be installed in a well-ventilated, cool, and dry environment. Make

sure the fans of the unit and the ventilation holes are not blocked.

Do not expose the unit to rain, moisture, snow, or liquids of any type.

Installation Safety

General Information

Included Components

Table of Contents

Identification of Parts (AC Side)

Identification of Parts (DC Side)

Installation

Location Recommendations

Sizing a Battery Bank

Grounding

DC Side Connection

AC Side Operation 13

Inverter Troubleshooting

External Fusing

Specifications

Dimensions

1000W

700W

2000W 18

3000W 18

General Information

Pure Sine Wave

Key Features

The Renogy Pure Sine Wave Power Inverter delivers superior performance for remote

off-grid applications, capable of producing cleaner, smoother, and more reliable electricity

for a user’s electronic needs.

The Renogy Power Inverters output a pure sine wave similar to the waveform of the grid

power. In a pure sine wave, the voltage rises and falls in a smooth fashion with very low

harmonic distortion and cleaner utility-like power.

Robust and sleek design

Optimized for 12 VDC system voltage

Clean power for safe operation of sensitive electronics

Easy-to-read LED indicator display

Multiple protection features (LVD, HVD, AC Overload and Over Temperature)

Excellent Surge Rating : 2x the Power Rating

Ground-fault circuit interrupter(GFCI) protection

Build-in 5V/2.1A USB port

Time(Seconds)

Amplitude(Volts)

Pure(Sine Wavefom)

This gives users stable enough power to operate tools, fans, lights, computers, and other

electronics without any interference. Pure sine wave inverters are in many cases more

efficient, allowing users to use less energy and allow for more device capability. The main

advantage to pure sine wave inverters is that they are used to operate sensitive electronic

devices that require a high quality waveform with little harmonic distortion. Almost any

electronic device could be powered using a pure sine wave inverter.

Included Components

The Renogy Pure Sine Wave Battery Inverters will be shipped with inverter cables and a

remotecontrol for powering the inverter on or off.

Wired remote control

Inverter Model Gauge

700W

1000W

2000W

3000W

6 AWG 3ft

4 AWG 3ft

4 AWG*2 3ft

Does not include

List dimensions

Thickness

Wire length

2.875 x 2.3125 x 0.9375in, 73 x 58.7 x 23.8mm

0625in , 1.5mm

Approx 19.8ft

Identification of Parts (AC Side)

Key Parts

High Output AC Terminals

— These terminals are for connecting 115V AC devices

that require more than 15 amps to operate or for connection to distributed wiring that

has multiple AC outlets. Remove the two screws on protective cover to access the

terminals. Any AC output wiring that is directly connected must comply with US National

Electric Code (NEC) wiring gauge recommendations.

NEUTRAL and GROUND are bonded inside the inverter to comply with theNational

Electric Code (NEC) requirement that any AC source must have a neutral to ground

connection.

Figure 2: 1000W Inverter

1 2 3 4 5

678

LEFT

Neutral (N) Ground(G)

Middle Right

Live(L)

2. Power LED (Green)

— When this green LED is lit, the inverter is operating.

3. GFCI LED (Yellow)

— When the yellow LED is lit, the ground fault circuit has been interrupted.

Shut down the inverter and restart.

Facing the front panel, the terminals are:

Alarm

—If there is a buzzing sound, the battery is low. The user should reduce the

AC load, charge the battery, and check the DC cable for excessive losses.

Fault LED (Red)

— The red indicator turns on as the inverter shuts down due to overheating,

overload, under voltage, or over voltage.

Immediately turn off all AC appliances if the Fault LED is lit. Allow the inverter to cool

before continuing. Make sure that the ventilation vents are not blocked.

If an inverter shutdown was preceded by a buzzing sound, there may be an excessive

load in combination with low voltage or a cable problem.

ON/OFF Switch

— Controls AC output.

AC Outlets

—

USB Power Port

—5 volts / 2.1A for charging tablets, smartphones, and other small

Remote Switch Connection

— Insert wired remote switch to the connection port. Set

electronic devices.

NOTE

115V AC 60Hz, up to 15amps for 2000W and 3000W models, up to 6.1

amps for 700W,up to 8.7 amps for 1000W.

ON/OFF switch to "remote" position.

KEY PARTS

1.Positive Terminal

— Positive (+) DC Input (Red)

2.Cooling Fans

— Thermally controlled

3.Negative Terminal

— Negative (−) DC Input (Black)

4.Ground Terminal

— For insulated safety ground wire.

Figure 3: 1000W Inverter

Identification of Parts (DC Side)

2 3

Never install the inverter in a sealed enclosure with flooded batteries. Gas can

accumulate and there is a risk of explosion.

The inverter should never be mounted vertically on a vertical surface since

it would present a hazardfor the fan opening which is crucial for cooling

the inverter.

Cool, dry, well-ventilated area —

Heat is the worst enemy for electronic equipment.

Inverters must be in an area where the fans are not blocked or where they are not hit

directly by the sun. They should be in an area free of any kind of moisture and allow for

clearance of at least 10” around the unit to provide for adequate ventilation.

Protection against fire hazard —

the unit should be away from any flammable

material, liquids, or any other combustible material. The unit can spark and the

consequences could be severe.

Close proximity to battery bank—

prevent excessive voltage drop by keeping the unit

close to the battery bank and having a properly sized wire going from the battery bank

to the inverter.

Limiting electromagnetic interference (EMI)

— ensure the inverter is firmly grounded

to a building, vehicle, or earth grounded. Keep the inverter away from EMI receptors

such as TVs, radios, and other audio/visual electronics to prevent damage/interference

to the equipment.

Secure inverter

—the inverter could be stand alone or mounted using the outlying

terminals on the inverter.

Installation

Location Recommendations

Ensure installation follows the following guidelines:

CAUTION

WARNING

Make sure inverter is in the off position before connecting anything.

Do not over-torque or over tighten the terminals. This could

potentially damage the unit.

Refer to the technical specifications for max wire sizes on the

controller and for the maximum amperage going through wires.

Do not install the inverter in the same compartment as the battery bank

because it could serve as a potential fire hazard.
