QUICK-START

GUIDE

RELOOP NEON

Installation and Setup

The Reloop NEON is a class compliant USB plug and play device and

requires no further driver installation.

NOTE: The Reloop NEON is an additional controller that will only work

in addition to supported Serato DJ hardware. Click here to see a list of

supported Serato DJ hardware.

1. Download and install the latest version of Serato DJ from http://serato.

com/dj/downloads

2. Connect your supported Serato DJ hardware to a USB port.

3. Connect your Reloop NEON to an available USB Port.

4. Open Serato DJ.

Controller

123 4 5 6 7

16 17

NOTE: The SHIFT button is used with other buttons that have shift modier functions.

# Reloop NEON Control Function Shift

1 LEFT DECK/BROWSER

KNOB

Turn for Library scroll. Press to load track. Turn to adjust Sampler volume. Press to toggle Back

through areas.

2 SAMPLER Press once for SAMPLER mode. Press twice for PAD FX Enable velocity sensitivty (Pads will illuminate green)

3 SLICER Press once for SLICER mode, press twice for LOOPED SLICER

4 PERFORMANCE PADS SEE PERFORMANCE PADS SECTION FOR MORE INFO

5 HOT CUE Press once for HOT CUE mode. Press twice for FLIP* mode

6 HOT LOOP Press once for HOT LOOP mode, press twice for MANUAL LOOP

mode

7 RIGHT BROWSER

KNOB

Press to enable Auto Loop. Turn to adjust loop length Turn to shift loop left or right. Press to enable loop roll.

8 MODE/CENSOR Censor Enables REL mode (if hardware available)

9 SLIP Enables Slip mode Enables INT mode

10 SYNC Enables SYNC Turns SYNC off. Press twice to reset to absolute pitch.

11 SHIFT Used with other functions with Shift modier controls

12 BANK/DECK D Switches to SP-6 Bank D Arms a Flip* for recording

13 BANK/DECK C Switches to SP-6 Bank C Turns current Flip* On/Off

14 BANK/DECK B Switches to SP-6 Bank B Turns Flip* loop On/Off

15 BANK/DECK A Switches to SP-6 Bank A Retriggers current Flip*

16 USB Connect the Reloop NEON to your computer with a USB Mini cable

17 LINK Link multiple Reloop NEONs together to use in series

* Flip Expansion Pack is required to be purchased and activated before Flip controls are accessable. See http://serato.com/dj/expansion-packs/ip

Performance Pads

The performance pads have eight different modes you can select. The

rst four modes; Sampler, Slicer, Hot Cue and Hot Loop are activated by

pressing the performnace mode button once. The last four modes; Pad FX,

Looped Slice, Flip* and Manual loop modes are activated by pressing the

performance mode buttons a second time.

• SAMPLER Mode: Pads 1-6 Trigger Samples loaded in your Sample

Banks. Holding MODE and pressing a pad will change the trigger type.

Holding SLIP and pressing a pad will toggle Loop on and off for that

SP-6 slot. Holding SYNC and pressing a pad will enable SYNC for that

SP-6 slot. Press SAMPLER twice to enable PAD FX mode. Hold SHIFT

and press the SAMPLER button to enable velocity sensitivity.

• SLICER Mode: A specied range (or domain) is divided into eight equal

sections, and these eight sliced sections are assigned to the respective

performance pads. Pressing SLICER once for the rst mode, is a shifting

Slicer Domain. Pressing SLICER twice, for the second mode is a xed

Slicer Domain or LOOPED SLICER. Hold SHIFT + Press a pad to set the

domain length. The domain can be set to one of six settings: 2 beats, 4

beats, 8 beats, 16 beats, 32 beats or 64 beats.

• HOT CUE Mode: When pressing buttons 1-8 you can add up to 8 Cue

Points. Holding SHIFT and pressing buttons 1-8 will delete the Cue

Points. Press HOT CUE again to enable saved FLIP* mode. Use this

mode to save or trigger saved Flips* you have created. Pressing a pad

while the current Flip* is active will save the Flip* to that slot.

• HOT LOOP mode: When pressing pads 1-8 you can activate saved

Loops. You can also use the AUTO LOOP knob to set auto loops.

SEE LOOPING FOR MORE INFORMATION. Pressing LOOP twice will

enter MANUAL LOOP mode: Pressing buttons 1-8 can set, save and

launch previously made Manual Loops. SEE LOOPING FOR MORE

INFORMATION.

*Flip Expansion Pack is required to be purchased and activated before Flip

controls are accessable. See http://serato.com/dj/expansion-packs/ip.

Looping

You have up to 8 loops per track in Serato DJ, and the choice between

either manual or auto loops. When using your Reloop NEON the four different

looping modes ROLL, HOT LOOP, AUTO LOOP and MANUAL LOOP modes can

all be activated and controlled via the eight performance pads.

Hot Loop mode with Auto Loops and Loop Rolls

Hot Loop mode is one of the performance pad modes. When pressing pads

1-8 you can save active loops to empty slots or trigger previously saved

loops. Use the Loop Size/Loop Set knob to set Auto Loops, Loop Rolls and

change loop size.

SEE PERFORMANCE PADS FOR MORE INFORMATION.

NEON Control Serato DJ Function Shift

LOOP SET

(press knob)

Set Auto Loop (turn on) Enable Loop Roll

LOOP SIZE

(turn knob)

Adjust Loop size Shift Auto

Loop left/right

Pads 1-8 Save active Loop to slot Re-trigger Loop

NEON

Control

Manual Loop Mode Shift

Pad 1 Turn current Loop On/Off.

Pad 2 Not mapped. Jump to and turn

on Loop (Reloop)

Pad 3 Save loop to next available slot

Pad 4 Scrolls up through available loop slots

Pad 5 Set Loop In point/Edit start of loop point

(if Loop already active).

Pad 6 Set Loop Out point/Edit end of loop point

(if Loop already active).

Pad 7 First press turns selected loop ON

and moves playhead to loops start

point. Second press turns loop OFF.

Pad 8 Scrolls down through available loop slots

LOOP SIZE Halve/Double Loop length. Shift Loop

to the Left/Right

Manual Loop Mode

Press HOT LOOP twice to enable MANUAL LOOP mode. It enables you to

manually set the length of your loops, save your loops as well as launch

previously saved loops.

SEE PERFORMANCE PADS FOR MORE INFORMATION.

NOTE: You can also save a loop to the next available free loop slot in the

software. To do this, either click the button in the manual/auto loop tab

or click on an available loop slot. Your loops are saved to the le and

recalled the next time it is loaded. They are not lost if the le is moved or

renamed.

DJ-FX

The DJ-FX in Serato DJ are powered by iZotope™. Click the FX tab

to open the FX panel. Select either 1, 2, 3, 4 or M to assign the selected effect bank

to a deck or Master Output.

There are two available modes in the DJ-FX. Single FX Mode allows you to

select one effect per FX bank, and has multiple parameters that can be adjusted.

Multi FX Mode allows you to select up to three effects per FX bank, and adjust

only one parameter, the FX Depth. The same effects available in Single FX mode

are available in Multi FX mode, as well some additional presets.

You can select between the two FX modes by clicking either the Single FX mode

button or Multi FX mode button in the software.

On the Reloop NEON, press SAMPLER mode twice to enable PAD FX mode.

Pads are velocity sensive when controlling FX or adjusting FX parameters.

NEON Control Multi FX Mode Single FX Mode Shift

Pads 1-3 FX Unit 1 Effect

On/Off. Velocity

Sensitive.

FX Unit 1 Effect

On/Off/Parameter

Adjust.

Effect Select

FX Unit 1

Pad 4 Adjust Beats value

left

Adjust Beats value

left

N/A

Pads 5-7 FX Unit 2 Effect

On/Off. Velocity

Sensitive.

FX Unit 1 Effect

On/Off/Parameter

Adjust.

Effect Select

FX Unit 2

Pad 8 Adjust Beats value

right

Adjust Slot 1

FX Parameter

N/A

Serato Flip

Flip is an Expansion Pack for Serato DJ. Flip controls are only available

once the Flip expansion pack has been purchased and activated. The

expansion pack can be purchased in-app through the Serato DJ Online

window, or online at http://serato.com/accessories

In HOT CUE performance pad mode SHIFT + BANK/DECK buttons are used

to record, trigger and loop Flips.

Press Hot Cue mode twice to enter Flip performance pad mode. Pressing

pads 1-6 in will trigger saved Flips, pressing SHIFT + pads 1-6 will turn

saved Flips on/off. Pressing an empty Flip slot will save any active Flip to

that slot.

NEON Control Flip function

SHIFT + 1 (REC) Starts the recording of a new Flip

SHIFT + 2 (ON) Starts the current Flip / re-trigger Flip

SHIFT + 3 (LOOP) Turns Flip Loop on/off

SHIFT + 4 (START) Turns current Flip On/Off

Using the Tool Tips

Click on the icon to enable Tool Tips. This is located in between the MIDI

and setup button in the top right hand corner of the screen. Tool Tips provide

a handy way to learn the various features of Serato DJ.

Move the mouse over a section of the screen to bring up a context sensitive

tool tip. Holding the mouse over the button with Tool Tips turned on will

show you a list of all keyboard shortcuts.

For more information about how to use Serato DJ, please go to our website

www.serato.com or refer to the Serato DJ Software Manual. For more

information on your controller, please refer to the hardware manual.

For further help, please contact [email protected] or go to

www.serato.com/dj/support
