Reliable 5100CD Manuel utilisateur

www.reliablecorporation.com

DENTAL LAB STEAM CLEANER

NETTOYEUR DENTAIRE À LA VAPEUR

INSTRUCTION MANUAL

GUIDE D’UTILISATION

MANUAL DE INSTRUCCIONES

5100CD

LIMPIADOR DENTAL A VAPOR

ENGLISH

FRANÇAIS

ESPAÑOL

5100CD DENTAL LAB STEAM CLEANER

INSTRUCTION MANUAL

ENGLISH

For immediate help with your purchase, please

We can be reached toll-free at 1-800-268-1649 or

via email at [email protected]

RELIABLE.

RIGHT THERE WITH YOU.

At Reliable, we do what we love, and take pride in doing it right. You want

what’s best for the people, places and things that matter in your life – from

where you live to what you wear. So do we. From the start, we approach every

product with a craftsman’s attention to detail and passion for making it right.

Quality, functionality, design and customer service play an equally important

part in delivering what’s right for you.

With its stainless steel construction, the 5100CD will allow you to obtain the

benefits of professional steam cleaning in a compact and convenient format.

For your safety and to fully enjoy the advantages of this product, please take a

few minutes to read all the important safeguards and care instructions. Keep

this manual handy and review the product warranty for your reference.

IMPORTANT SAFETY INSTRUCTIONS

Read all instructions before use. Save these instructions for

your future reference.

1. To avoid risk of electric shock, do not immerse the boiler in water or other

liquids.

2. Do not allow the cord to come in contact with hot surfaces.

3. Always allow the appliance to cool down before storing.

4. Always put the appliance in a secure location (e.g., table or countertop) when

in use.

5. Do not move the appliance without unplugging it first.

6. Always disconnect the appliance from the outlet before filling it with water, or

emptying the water. Be careful to avoid spilling water onto the appliance while

filling it up.

7. Use either tap water or distilled water in the appliance. Do not use perfumed

liquid or products containing alcohol.

8. Always disconnect the appliance when not in use.

9. Do not use the appliance if the cord is damaged. If the cord looks damaged,

return the appliance to have the cord repaired by the manufacturer or their

service agent.

10. Do not operate the appliance if it has been dropped or damaged. Do not

disassemble the appliance. Incorrect reassembly can cause a risk of electric

shock. Send it to an authorized service center for repair.

11. Do not operate another high wattage appliance on the same circuit.

12. This appliance must be grounded. Do not alter the plug or attempt to remove

this feature.

13. Be careful when operating the unit. Burns can occur from touching any hot

metal surfaces or the steam.

14. This appliance is not intended for use by young children.

15. While using the appliance, never unscrew or remove the Safety Cap (1) while

the boiler is under pressure.

•Low water light indicator

•Auto shut-off thermostat protection

•Regular tap water or distilled water

•50 PSI operating pressure

•Up to 4 hours of continuous steam

•Eco mode

FOR HOUSEHOLD AND LIGHT

COMMERCIAL USE ONLY

FEATURES

IMPORTANT: When you want to dispose of the appliance, never throw it into

the garbage. Instead, go to your closest recycling station or waste collection

center for subsequent treatment. In this way, you will be contributing to

preservation of the environment.

•Boiler power - 1000W

•Working pressure 3.5 BAR

•Tank nominal capacity of model - 2.2 L, Fill to 1.9 L

TECHNICAL DATA

16. Before removing the cap, make sure there is no more steam in the steam

chamber. Do this by turning the Boiler Button (4) to the off position and

pressing the Steam Power Button (2) to release all remaining steam.

17. To ensure your safety, the Safety Cap (1) and all other components must

be replaced with original parts only.

1. 5100CD Dental Steam Cleaner

2. 3000DA Steam Gun

3. Steam Cord Holder

4. Safety Cap

5. Funnel

6. Water Level Measuring Stick

WHAT'S IN THE BOX

Please ensure that you have unpacked all of the following items:

DESCRIPTION OF THE 5100CD BOILER

1. Safety Cap

2. Steam Power Button

3. Steam Ready Light

4. Boiler Button

BOILER WITH STEAM GUN ATTACHMENT

FRONT VIEW SIDE VIEW

5. Eco Mode Button

6. Low Water Indicator Light

7. Pressure Gauge

8. Steam Cord Holder

9. Lock Mechanism

10. Ilme Plug

11. Steam Volume Dial

12. Steam Quick Connect

4/5

SteamSteam

BOILER ASSEMBLY

STEAM GUN ASSEMBLY

1. Remove steam gun from packaging and ensure all protective bags/outer

packaging has been taken off.

2. Insert the two piece Steam Cord Holder (8) into the flange on top of the

boiler and attach the spring on the steam hose to the coil end of the wand.

3. Connect the steam gun to the Ilme Plug (10) and the Steam Quick Connect

(12) on the boiler. Turn the Lock Mechanism (9) until it clicks to ensure full

connection.

1. Remove the Boiler from its packing and make sure all packaging has been

removed (including the protective bags). Put the station on a flat and solid

surface.

2. Unscrew the Safety Cap (1). Fill the boiler with a maximum of 8 cups (1.9

litres) of water for the 5100CD. Use the funnel supplied, making sure you do

not overfill the tank (you can also use the water stick to determine the water

level in the steam tank).

Note: To preserve the life of your boiler,we recommend distilled water. Tap

water is okay, but more cleaning is required. See maintenance section for

more cleaning information.

How to use the water stick: Fully insert the water stick into the tank. Place

your finger on the end of the water stick. While holding the end, remove the

water stick from the boiler tank. The water level capacity will then appear on

the stick measurement to indicate the level.
