Models DD56-6, DD56-27, DD80-6, DD80-27, DS56, & GP56 Attic Sprinklers

Specific Application Sprinklers cULus Listed

for Sloped Combustible and Noncombustible Light Hazard Concealed Spaces

Product Features

DD80 Series sprinklers provide coverage for spans up

to 70 ft (21 m) with one row of sprinklers

DD56 Series sprinklers provide coverage for spans up

to 40 ft (12 m) with one row of sprinklers.

Model DS56 sprinkler provides coverage up to

6 ft x 40 ft (1.8 m x 12 m)

Model GP56 sprinkler provides coverage up to

10 ft x 15 ft (3.0 m x 4.6 m)

All models use a 212°F (100°C) temperature rated

fusible-link operating element

Product Description

Reliable Attic Sprinklers are cULus Listed Specific Appli-

cation sprinklers. The sprinklers are available for protection

of combustible and non-combustible light hazard con-

cealed spaces with roof/ceiling slopes of 4:12 to 8:12. Re-

liable Attic Sprinklers are upright sprinklers listed for use

on wet-pipe or dry-pipe sprinkler systems. All Reliable

Attic sprinklers use a 212°F (100°C) temperature rated

fusible-link operating element that is Listed for installation

where the maximum ceiling temperature is up to 150°F

(66°C). Table A provides a summary of available Reliable

Attic sprinklers.

Attic Sprinklers

Model DD56

Model DD80

Model DS56

Model GP56

Attic Sprinkler Summary Table A

Sprinkler

Model

Nominal

K-Factor

gpm/psi

1/2

(L/min/bar

1/2

)

Thread Size

NPT or

ISO7-1

Max. Coverage Area

(Measured on Floor)

ft x ft

(m x m)

Roof Slope Design Criteria

Sprinkler

Identification

Number (SIN)

DD56-6 5.6

(80) ½ 6 x 40

(1.8 x 12) 4:12 to <6:12 Table B RA5624

DD56-27 5.6

(80) ½ 6 x 40

(1.8 x 12) 6:12 to 8:12 Table C RA5694

DD80-6 8.0

(115) ¾ 6 x 66 or 5 x 70

(1.8 x 20 or 1.5 x 21) 4:12 to <6:12 Table D RA5622

DD80-27 8.0

(115) ¾ 6 x 66 or 5 x 70

(1.8 x 20 or 1.5 x 21) 6:12 to 8:12 Table E RA5692

DS56 5.6

(80) ½ 6 x 40

(1.8 x 12) 4:12 to 8:12 Table F RA5625

GP56 5.6

(80) ½ 10 x 15

(3.0 x 4.6) 4:12 to 8:12 Table G RA5695

Bulletin 056 December 2016

Bulletin 056 Page 2 of 24

December 2016 www.reliablesprinkler.com

Model DD56-6 Specific Application Sprinkler SIN RA5624

Technical Specifications

Style: Upright

Orientation: Deflector horizontal

Threads: 1/2” NPT or ISO 7-1R1/2

Nominal K-Factor: 5.6 (80 metric)

Max. Working Pressure: 175 psi (12 bar)

Sprinkler Temperature Rating: 212°F (100°C)

Sensitivity: Quick-response

Hydraulic Design Criteria

(See Table H)

Finish

Brass

Sprinkler Wrench

Model R2 or W2

Listings and Approvals

cULus Listed

Hazard Classification

Light Hazard

System Types

Wet-pipe with steel or Listed CPVC pipe

Dry-pipe with steel pipe

Installation Criteria

Sprinkler Spacing

Max: 6 ft (1.8 m) across roof slope

Min: 4 ft (1.2 m) across roof slope

Min: 26 ft (7.9 m) down the roof slope

measured parallel to the roof deck

Horizontal Distance from Face of Truss

Min: 6 inches (150 mm)

Vertical Distance of Deflector Above Scis-

sor Truss

Min: 18 inches (450 mm)

Horizontal Distance from Centerline of

Ridge

Max: 6 inches (150 mm)

Vertical Distance of Top of Deflector Below

Peak, Ridge, or Deck

Min: 17 inches (430 mm)

Max: 21 inches (530 mm)

Material Specifications

Thermal Sensor: Nickel Alloy Solder Link

Levers: Stainless Steel

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Button Clip: Stainless Steel

Sealing Assembly: Nickel Alloy with

PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Model DD56-6 Sprinkler Components and Dimensions Figure 1

Model DD56-6 Minimum Required Flow and Residual Pressure Table B

Ceiling Slope

Max. Coverage

Area

ft x ft

(m x m)

Flow

gpm

(l/min)

Pressure

psi

(bar)

4:12 to less than 6:12 6 x 40*

(1.8 x 12)

(95)

19.9

(1.37)

* Coverage is 20 ft (6.1 m) down slope in two directions measured along the floor.

Bulletin 056 Page 3 of 24

December 2016 www.reliablesprinkler.com

Model DD56-27 Specific Application Sprinkler SIN RA5694

Technical Specifications

Style: Upright

Orientation: Deflector horizontal

Threads: 1/2” NPT or ISO 7-1R1/2

Nominal K-Factor: 5.6 (80 metric)

Max. Working Pressure: 175 psi (12 bar)

Sprinkler Temperature Rating: 212°F (100°C)

Sensitivity: Quick-response

Hydraulic Design Criteria

(See Table H)

Finish

Brass

Sprinkler Wrench

Model R2 or W2

Listings and Approvals

cULus Listed

Hazard Classification

Light Hazard

System Types

Wet-pipe with steel or Listed CPVC pipe

Dry-pipe with steel pipe

Installation Criteria

Sprinkler Spacing

Max: 6 ft (1.8 m) across roof slope

Min: 4 ft (1.2 m) across roof slope

Min: 26 ft (7.9 m) down the roof slope

measured parallel to the roof deck

Horizontal Distance from Face of Truss

Min: 6 inches (150 mm)

Vertical Distance of Deflector Above Scis-

sor Truss

Min: 18 inches (450 mm)

Horizontal Distance from Centerline of

Ridge

Max: 6 inches (150 mm)

Vertical Distance of Deflector Below Peak,

Ridge, or Deck

Min: 17 inches (430 mm)

Max: 21 inches (530 mm)

Material Specifications

Thermal Sensor: Nickel Alloy Solder Link

Levers: Stainless Steel

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Button Clip: Stainless Steel

Sealing Assembly: Nickel Alloy with

PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Model DD56-27 Sprinkler Components and Dimensions Figure 2

Model DD56-27 Minimum Required Flow and Residual Pressure Table C

Ceiling Slope

Max. Coverage

Area

ft x ft

(m x m)

Flow

gpm

(l/min)

Pressure

psi

(bar)

6:12 to 8:12 6 x 40*

(1.8 x 12)

(95)

19.9

(1.37)

* Coverage is 20 ft (6.1 m) down slope in two directions measured along the floor.

Bulletin 056 Page 4 of 24

December 2016 www.reliablesprinkler.com

Model DD80-6 Specific Application Sprinkler SIN RA5622

Technical Specifications

Style: Upright

Orientation: Deflector horizontal

Threads: 3/4” NPT or ISO 7-1R3/4

Nominal K-Factor: 8.0 (115 metric)

Max. Working Pressure: 175 psi (12 bar)

Sprinkler Temperature Rating: 212°F (100°C)

Sensitivity: Quick-response

Hydraulic Design Criteria

(See Table H)

Finish

Brass

Sprinkler Wrench

Model R2 or W2

Listings and Approvals

cULus Listed

Hazard Classification

Light Hazard

System Types

Wet-pipe with steel or Listed CPVC pipe

Dry-pipe with steel pipe

Installation Criteria

Sprinkler Spacing

Max: 6 ft (1.8 m) across roof slope

Min: 4 ft (1.2 m) across roof slope

Min: 26 ft (7.9 m) down the roof slope

measured parallel to the roof deck

Horizontal Distance from Face of Truss

Min: 6 inches (150 mm)

Vertical Distance of Deflector Above Scis-

sor Truss

Min: 18 inches (450 mm)

Horizontal Distance from Centerline of

Ridge

Max: 6 inches (150 mm)

Vertical Distance of Deflector Below Peak,

Ridge, or Deck

Min: 17 inches (430 mm)

Max: 21 inches (530 mm)

Material Specifications

Thermal Sensor: Nickel Alloy Solder Link

Levers: Stainless Steel

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Button Clip: Stainless Steel

Sealing Assembly: Nickel Alloy with

PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Model DD80-6 Sprinkler Components and Dimensions Figure 3

Model DD80-6 Minimum Required Flow and Residual Pressure Table D

Ceiling Slope

Max. Coverage

Area

ft x ft (m x m)

Flow

gpm (l/min)

Pressure

psi (bar)

4:12 to less than 6:12

6 x 40

(1.8 x 12)

(95)

9.8

(0.68)

6 x 63

(1.8 x 19)

(144)

22.6

(1.56)

6 x 66

(1.8 x 20)

(151)

(1.72)

5 x 70

(1.5 x 21)

(144)

22.6

(1.56)

Coverage is 20 ft (6.1 m) down slope in two directions measured along the floor.

Coverage is 31.5 ft (9.6 m) down slope in two directions measured along the floor.

Coverage is 33 ft (10.0 m) down slope in two directions measured along the floor.

Coverage is 35 ft (10.7 m) down slope in two directions measured along the floor.

Bulletin 056 Page 5 of 24

December 2016 www.reliablesprinkler.com

Model DD80-27 Specific Application Sprinkler SIN RA5692

Technical Specifications

Style: Upright

Orientation: Deflector horizontal

Threads: 3/4” NPT or ISO 7-1R3/4

Nominal K-Factor: 8.0 (115 metric)

Max. Working Pressure: 175 psi (12 bar)

Sprinkler Temperature Rating: 212°F (100°C)

Sensitivity: Quick-response

Hydraulic Design Criteria

(See Tables E and H)

Finish

Brass

Sprinkler Wrench

Model R2 or W2

Listings and Approvals

cULus Listed

Hazard Classification

Light Hazard

System Types

Wet-pipe with steel or Listed CPVC pipe

Dry-pipe with steel pipe

Installation Criteria

Sprinkler Spacing

Max: 6 ft (1.8 m) across roof slope

Min: 4 ft (1.2 m) across roof slope

Min: 26 ft (7.9 m) down the roof slope

measured parallel to the roof deck

Horizontal Distance from Face of Truss

Min: 6 inches (150 mm)

Vertical Distance of Deflector Above Scis-

sor Truss

Min: 18 inches (450 mm)

Horizontal Distance from Centerline of

Ridge

Max: 6 inches (150 mm)

Vertical Distance of Deflector Below Peak,

Ridge, or Deck

Min: 17 inches (430 mm)

Max: 21 inches (530 mm)

Material Specifications

Thermal Sensor: Nickel Alloy Solder Link

Levers: Stainless Steel

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Button Clip: Stainless Steel

Sealing Assembly: Nickel Alloy with

PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Model DD80-27 Sprinkler Components and Dimensions Figure 4

Model DD80-27 Minimum Required Flow and Residual Pressure Table E

Ceiling Slope

Max. Coverage

Area

ft x ft (m x m)

Flow

gpm (l/min)

Pressure

psi (bar)

6:12 to 8:12

6 x 40

(1.8 x 12)

(106)

12.3

(0.85)

6 x 63

(1.8 x 19)

(144)

22.6

(1.56)

6 x 66

(1.8 x 20)

(151)

(1.72)

5 x 70

(1.5 x 21)

(144)

22.6

(1.56)

Coverage is 20 ft (6.1 m) down slope in two directions measured along the floor.

Coverage is 31.5 ft (9.6 m) down slope in two directions measured along the floor.

Coverage is 33 ft (10.0 m) down slope in two directions measured along the floor.

Coverage is 35 ft (10.7 m) down slope in two directions measured along the floor.

Bulletin 056 Page 6 of 24

December 2016 www.reliablesprinkler.com

Model DS56 Specific Application Sprinkler SIN RA5625

Technical Specifications

Style: Upright

Orientation: Frame arms perpendicular to roof

deck

Threads: 1/2” NPT or ISO 7-1R1/2

Nominal K-Factor: 5.6 (80 metric)

Max. Working Pressure: 175 psi (12 bar)

Sprinkler Temperature Rating: 212°F (100°C)

Sensitivity: Quick-response

Hydraulic Design Criteria

(See Tables F and H)

Finish

Brass

Sprinkler Wrench

Model DS56

Listings and Approvals

cULus Listed

Hazard Classification

Light Hazard

System Types

Wet-pipe with steel or Listed CPVC pipe

Dry-pipe with steel pipe

Installation Criteria

Sprinkler Spacing

Max: 6 ft (1.8 m) across roof slope

Min: 4 ft (1.2 m) across roof slope

Min: 26 ft (7.9 m) down the roof slope

measured parallel to the roof deck

Horizontal Distance from Face of Truss

Min: 6 inches (150 mm)

Horizontal Distance from Draft Curtain or

Wall

Min: 34 inches (860 mm)

Max: 38 inches (970 mm)

Vertical Distance of Top of Deflector Above

Bottom of Draft Curtain

Min: 8 inches (200 mm)

Model DS56 sprinklers may be installed

back-to-back on opposite sides of a

ridge where a draft curtain is installed to

separate the back-to-back rows of

sprinklers.

Vertical Distance of Top of Deflector Above

Scissor Truss

Min: 18 inches (450 mm)

Distance from Top of Deflector to Roof

Deck

(measured perpendicular to roof deck)

Min: 9 inches (230 mm)

Max: 13 inches (330 mm)

Material Specifications

Thermal Sensor: Nickel Alloy Solder Link

Levers: Brass Alloy

Frame Body: Brass Alloy

Frame Arms: Brass Alloy

Yoke: Copper Alloy

Sealing Assembly: Nickel Alloy with

PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Model DS56 Sprinkler Components and Dimensions Figure 5

Model DS56 Minimum Required Flow and Residual Pressure Table F

Ceiling Slope

Max. Coverage

Area

ft x ft

(m x m)

Flow

gpm

(l/min)

Pressure

psi

(bar)

4:12 to 8:12

6 x 30

(1.8 x 9.1)

(87)

16.9

(1.17)

6 x 40

(1.8 x 12)

(132)

39.1

(2.70)

Coverage is 30 ft (9.1 m) down slope measured along the floor.

Coverage is 40 ft (12 m) down slope measured along the floor.

Bulletin 056 Page 7 of 24

December 2016 www.reliablesprinkler.com

Model GP56 Specific Application Sprinkler SIN RA5695

Technical Specifications

Style: Upright

Orientation: Top of deflector parallel to roof deck

Threads: 1/2” NPT or ISO 7-1R1/2

Nominal K-Factor: 5.6 (80 metric)

Max. Working Pressure: 175 psi (12 bar)

Sprinkler Temperature Rating: 212°F (100°C)

Sensitivity: Quick-response

Hydraulic Design Criteria

(See Tables G and H)

Finish

Brass

Sprinkler Wrench

Model R2 or W2

Listings and Approvals

cULus Listed

Hazard Classification

Light Hazard

System Types

Wet-pipe with steel or Listed CPVC pipe

Dry-pipe with steel pipe

Installation Criteria

Sprinkler Spacing

Max: 10 ft (3.0 m) across roof slope

measured along the floor

Max: 15 ft (4.6 m) up and down roof

slope measured along the floor

Min: 6 ft (1.8 m) measured parallel to the

roof deck

Distance from Top of Deflector to Roof

Deck

(measured perpendicular to roof deck)

Min: 9 inches (230 mm)

Max: 13 inches (330 mm)

Material Specifications

Thermal Sensor: Nickel Alloy Solder Link

Levers: Stainless Steel

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Button Clip: Stainless Steel

Sealing Assembly: Nickel Alloy with

PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Model GP56 Sprinkler Components and Dimensions Figure 6

Model GP56 Minimum Required Flow and Residual Pressure Table G

Ceiling Slope

Max. Coverage

Area

ft x ft

(m x m)

Flow

gpm

(l/min)

Pressure

psi

(bar)

4:12 to 8:12 10 x 15*

(3.0 x 4.6)

(64)

9.2

(0.63)

* Coverage is 3 ft (0.9 m) up slope and 12 ft (3.7 m) down slope measured along the floor.

Bulletin 056 Page 8 of 24

December 2016 www.reliablesprinkler.com

Application

Reliable Attic Sprinklers are cULus Specific Application

sprinklers intended for installation in accordance with this

Bulletin and NFPA 13. The sprinklers are classified as

Special Sprinklers by NFPA 13.

The sprinklers are intended for installation within combus-

tible or noncombustible roof structures, including those

with wood joists or trusses.

Coverage area and spacing requirements for each sprin-

kler are provided on the individual sprinkler data sheets in

this Bulletin. Example sprinkler layouts are illustrated in

Figures 7 through 21. Design criteria for Reliable Attic

Sprinklers must be in accordance with Table H based on

the minimum flows and pressures for each sprinkler in Ta-

bles B through G. Provide additional sprinklers beyond

obstructions where required by Figure 22.

For example, hydraulic calculations for a sprinkler system

using DD Series sprinklers at the ridge with Model GP56

sprinklers at the eave must include the hydraulically most

remote 5 DD Series sprinklers plus 2 Model GP56 sprin-

klers for a wet pipe sprinkler system or 7 DD Series sprin-

klers plus 2 Model GP56 sprinklers for a dry pipe sprinkler

system.

Bulletin 056 Page 9 of 24

December 2016 www.reliablesprinkler.com

Reliable Attic Sprinkler Hydraulic Design Criteria Table H

Sprinklers in Attic

Number or (Area) of Sprinklers Included in Hydraulic Design

(Select Hydraulically Most Remote Sprinklers of Each Type)

Wet Pipe Sprinkler System Dry Pipe Sprinkler System

aa=

pÉêáÉë= apRS= dmRS= pí~åÇ~êÇ=

péê~ó=

aa=

pÉêáÉë= apRS= dmRS= pí~åÇ~êÇ=

péê~ó=

DD Series at ridge only (Fig. 7) 5 N/A N/A N/A 7 N/A N/A N/A

DS56 at ridge only (Fig. 8) N/A 5 N/A N/A N/A 9 N/A N/A

DD Series at ridge with DS56 beyond

obstruction (Fig. 9) 5 2 N/A N/A 7 2 N/A N/A

DS56 at ridge with DS56 beyond ob-

struction (Fig. 10) N/A 5 N/A N/A N/A 9 N/A N/A

DD Series at ridge with GP56 beyond

obstruction (Fig. 11) 5 N/A 2 N/A 7 N/A 2 N/A

DS56 at ridge with GP56 beyond ob-

struction (Fig. 12) N/A 5 2 N/A N/A 9 2 N/A

DD Series at ridge with GP56 in dormer

or cross (Fig. 13)

(Calculate upper row if 4 or less GP56

sprinklers are used in each dormer or

cross;

Separately calculate upper row and

lower row if more than 4 GP56 sprin-

klers are used in any dormer or cross

and use the greater demand)

5 N/A 2 N/A 7 N/A 2 N/A

0 N/A

(1,500 ft2)

(139 m2) N/A 0 N/A

(1,950 ft2)

(181 m2) N/A

DD Series at ridge with Standard Spray

sprinklers in dormer or cross (Fig. 14)

(Calculate upper row if 4 or less

Standard Spray sprinklers are used in

each dormer or cross;

Separately calculate upper row and

lower row if more than 4 Standard

Spray sprinklers are used in any dor-

mer or cross and use the greater de-

mand

)

5 N/A N/A 2 7 N/A N/A 2

Calculate design area per NFPA 13 and include

all sprinkler types that are in the design area

Calculate design area per NFPA 13 and include all

sprinkler types that are in the design area

DD Series at ridge with DD Series in

dormer (Fig.15)

5 at ridge

and up to

2 in dormer

N/A N/A N/A

7 at ridge

and up to

2 in dormer

N/A N/A N/A

DD Series sprinklers at ridge with

GP56 sprinklers at eave (Fig. 16) 5 N/A 2 N/A 7 N/A 2 N/A

DS56 sprinklers at ridge with GP56

sprinklers at eave (Fig. 17) N/A 5 2 N/A N/A 9 2 N/A

DD Series sprinklers at ridge with DS56

sprinklers at hip or ell (Fig. 18) 5 total N/A N/A

9 total

(Include a max. of 7 DD

Series sprinklers in

hydraulic design)

N/A N/A

DS56 sprinklers at ridge with DS56

sprinklers at hip or ell (Fig. 19) N/A 5 N/A N/A N/A 9 N/A N/A

DD Series sprinklers at ridge with

Standard Spray sprinklers at hip or ell

(Fig. 20)

(Calculate upper row if 4 or less

Standard Spray sprinklers are used in

each hip or ell; Separately calculate

upper row and lower row if more than 4

Standard Spray sprinklers are used in

any hip or ell and use the greater de-

mand

)

5 N/A N/A 2 7 N/A N/A 2

Calculate design area per NFPA 13 and include

all sprinkler types that are in the design area

Calculate design area per NFPA 13 and include all

sprinkler types that are in the design area

DS56 sprinklers at ridge with Standard

Spray sprinklers at hip or ell (Fig. 21)

(Calculate upper row if 4 or less

Standard Spray sprinklers are used in

each hip or ell; Separately calculate

upper row and lower row if more than 4

Standard Spray sprinklers are used in

any hip or ell and use the greater de-

mand)

N/A 5 N/A 2 N/A 9 N/A 2

Calculate design area per NFPA 13 and include

all sprinkler types that are in the design area

Calculate design area per NFPA 13 and include all

sprinkler types that are in the design area

Bulletin 056 Page 10 of 24

December 2016 www.reliablesprinkler.com

Model DD Series Sprinkler – Example Layout (Not to Scale) Figure 7

Model DS56 Sprinkler – Example Layout (Not to Scale) Figure 8

Autres manuels pour DD56-6

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Reliable Système d'irrigation

Reliable

Reliable F1FR Series Manuel

Reliable

Reliable F3-80 Dry Pendent Manuel utilisateur

Reliable

Reliable F156 Series Manuel

Reliable

Reliable F1FR56 Manuel

Reliable

Reliable N252 EC Pendent Manuel utilisateur

Reliable

Reliable N252 EC Manuel utilisateur

Reliable

Reliable SWC Manuel

Reliable

Reliable F1FR-FS Series Manuel utilisateur

Reliable

Reliable Reliable Manuel utilisateur

Reliable

Reliable F1 LO Manuel utilisateur

Reliable

Reliable N252 EC Manuel utilisateur

Reliable

Reliable F1-SS Series Manuel utilisateur

Reliable

Reliable XL Commercial Manuel utilisateur

Reliable

Reliable F1FR LO Series Manuel

Reliable

Reliable F1-28 Series Manuel utilisateur

Reliable

Reliable DDX Type D Manuel d'entretien

Reliable

Reliable F4FR Manuel utilisateur

Reliable

Reliable F156-300 Series Manuel

Reliable

Reliable F3QR56 Dry Manuel

Reliable

Reliable F1FR56 Manuel utilisateur

Reliable

Reliable GFR Manuel utilisateur

Reliable

Reliable RFC30 LL Manuel utilisateur

Reliable

Reliable G6-80 Manuel

Reliable

Reliable H PrePak Manuel d'entretien

Manuels Système d'irrigation populaires d'autres marques

Hunter

Hunter Institutional Series Manuel utilisateur

Cellfast

Cellfast 52-305 Manuel utilisateur

Tyco Fire Product

Tyco Fire Product Star Galaxy SGQR Manuel utilisateur

Tyco Fire Product

Tyco Fire Product CENTRAL A Manuel utilisateur

Oral Care Technologies

Oral Care Technologies Hydro Floss Manuel utilisateur

Tyco Fire Product

Tyco Fire Product Gem F892 Manuel utilisateur

Netafim

Netafim NETBEAT Manuel utilisateur

Irrigation-Mart

Irrigation-Mart KIT-GK100-RV-B Manuel utilisateur

Tyco

Tyco CC3 Manuel utilisateur

OpenSprinkler

OpenSprinkler OSPi Manuel utilisateur

EINHELL

EINHELL GE-WW 5537 E Manuel utilisateur

Valley

Valley Bender160 Manuel utilisateur

Toro

Toro 730 Series Guide rapide

Eden

Eden 97063-EDAMZ Manuel utilisateur

Tyco

Tyco TY-L Series Manuel utilisateur

Tyco Fire Product

Tyco Fire Product CENTRAL ELO-231 Manuel utilisateur

Johnson Controls

Johnson Controls tyco ESFR-17 Manuel utilisateur

Victaulic

Victaulic VicFlex I-VICFLEX.AQC-U Manuel utilisateur
