DOCUMENT READER
REGULA 7027F
RGVI.195.00.00–01 UG
User’s Guide
Certied Quality
Management System
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
FCC ID: 2AOFE-7027F
FCC Compliance Statement:
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation
EU Declaration of Conformity CE:
Hereby, Regula Baltija Ltd. declares that
Document Reader 7027F is in compliance with
the essential requirements and other relevant
provisions of Directive 2014/53/EU with reference
to Directives 2014/30/EU, 2014/35/EU.
This symbol means the product
must not be as household waste, and
should be delivered to an appreciate
collection facility for recycling. For
more information on disposal and
recycling of this product, contact
your local municipality service, or
the shop where you bought this
product.
OPERATING RESTRICTIONS
1. ATTENTION! CONSULT THIS USER’S GUIDE
AT ALL STAGES OF DEVICE OPERATION.
2. When operating the device, do not remove
any seals set by the manufacturer during the whole
warranty period.
3. DO NOT SWITCH ON THE DEVICE IN CASE OF
ITS MALFUNCTION!
4. DO NOT PLACE ANY FOREIGN OBJECTS ON
THE OBJECT GLASS OF THE DEVICE!
5. DO NOT USE THE DEVICE WHEN THE USB
CABLE IS DAMAGED!
6. DO NOT DISMANTLE THE DEVICE AND ELIMINATE
ANY MALFUNCTIONS OCCURRED DURING DEVICE
OPERATION WITHOUT QUALIFIED ASSISTANCE.
7. Do not operate the reader if the object glass is
dirty (see paragraph 3.3 of this User’s Guide).
8. DO NOT OPERATE THE DEVICE AT A DISTANCE
CLOSER THAN 20 CM TO OTHER RADIO-TAIL
DEVICES INCLUDING SIMILAR DEVICES.
UV
Warning!
UV radition
365 nm
min 20 сm
CONTENTS
ABBREVIATIONS ...................... 6
1 DESCRIPTION AND OPERATION .......... 8
1.1 Reader function ................. 8
1.2 Technical specications ............10
1.3 Delivery set ....................12
1.4 Conguration and operation ........13
1.5 Marking and sealing ..............16
1.6 Packaging .....................17
2 INTENDED USE .....................18
2.1 Operating restrictions .............18
2.2 Preparation for use ...............20
2.3 Reader use.....................22
3 DEVICE MAINTENANCE ................25
4 TRANSPORTATION, STORAGE
AND RECYCLING ....................29
4.1 Transportation ..................29
4.2 Storage .......................29
4.3 Recycling ......................30
5 MANUFACTURER’S WARRANTY ...........31
6 ACCEPTANCE CERTIFICATE .............35
7 SALE CERTIFICATE ...................36
APPENDIX А. CALIBRATION OF THE READER ..37
APPENDIX B. SIMPLIFIED EU DECLARATION
OF CONFORMITY......................39
6
ABBREVIATIONS
SDK —software development kit
DR SDK —Document Reader SDK
USB —Universal Serial Bus
OCR —optical character
recognition
MRZ —Machine Readable Zone
VIZ —Visual Inspection Zone
ISO —International Organization
for Standardization
PPI —pixels per inch —
parameter which
characterizes the resolution
of an image
ОS —operating system of the PC
(Windows)
7
The User’s Guide (hereinafter referred to as
«the Guide») applies to all models of the document
reader Regula 7027F (hereinafter referred to as
«the reader» or «the device»). The Guide contains
the description of the device design, principles of
operation and operating rules.
Only PC users familiar with this Guide are allowed
to use the reader provided that safety measures
and reader operating rules are observed.
Operations with PC software components
(installing, deleting, changing the settings, etc.) are
carried out by the user with administrator rights.
The safety measures given in the Guide must be
strictly observed during reader operation.
The device operates together with the software
and is controlled by the User’s application and
performs the functions described in «Programmer’s
Guide. Document Reader. RGVI.01.01.00 MZ».
A PC which meets minimum requirements given in
paragraph 1.2.7 is required for proper functioning of
the reader. The PC is not included in the delivery set.
The User’s application intended for controlling
the reader is to be based on the libraries of Software
Development Kit (SDK) RGVI.01.15.00 and SDK
RGVI.54.10.00 in accordance with the mentioned
Programmer’s Guide.
The test application Readerdemo.exe
(see the document «Test application (Readerdemo.
exe). User’s Guide RGVI.17.01.00 D») is an
example of the User’s application intended for
8
testing the above mentioned functions. The test
application is supplied as a part of SDK.
The customer is responsible for developing
the User’s application and organizing its interaction
with SDK components and reader hardware. These
procedures are not described in the Guide.
1 DESCRIPTION AND OPERATION
1.1 Reader function
The reader is a multipurpose product which is
intended for capturing document images of ID, ID2 or
ID3 formats produced in accordance with ISO 7810
standard. The device allows reading text and graphic
data from documents, transmitting the obtained data
into the PC for recognizing, processing, verifying,
archiving and comparing the obtained data with the
help of special software algorithms.
1.1.1 The device together with the supplied software
allows the following:
а) capturing colorful images of a document with
up to 470 ppi resolution;
Supported image formats: BMP, JPEG, JPEG 2000,
PNG, TIFF.
b) reading text data from the machine readable
zone (hereinafter referred to as «the MRZ») of
a document in compliance with Doc 9303 ICAO
and ISO 7501 standards: 2 lines with 44 symbols
each, 2 lines with 36 symbols each, 3 lines with
30 symbols each;
9
c) analyzing MRZ checksums and MRZ completion
accuracy in compliance with «ePassport Conformity
Testing (v 1.0 04.04.2008)»;
d) dening the issuing state and the document type;
e) correct cropping of the holder’s portrait and
signature from the document for all document types
recognized by the system;
f) reading data from an RFID chip (contactless
smart card) in accordance with the ICAO specication
«Machine readable travel documents. Technical
report. Logical data structure (LDS)».
Supported data access modes: direct, ВАС, ЕАС.
Identication: passive and active.
RFID-chip types: ISO 14443 А and В types.
Data exchange rate: 106, 212, 424 or 848 Kbaud
(support of asymmetric rates).
1.1.2 The device together with the supplied
software may perform the following functions
(optionally):
a) reading text data (OCR) from the visual
inspection zone (VIZ) including non-ICAO standard
documents;
b) automatic authenticity verication of
a document according to the following IR features
(for Regula 7027F.100 and 7027F.110):
1) MRZ printing contrast (IR B900 ink);
2) photo embedding type;
3) IR visibility or invisibility of:
10
– image elements,
– text data,
– holder’s portrait;
c) automatic authenticity verication of
a document by crosschecking of text data obtained
from the MRZ, VIZ, RFID chip, a barcode, as well as
data read from a visa;
d) verifying authenticity and quality of MRZ
printing in accordance with Doc 9303 ICAO,
ISO 7501, ISO 1831 and ISO 1073–2;
e) reading 1D and 2D barcodes from the
document image;
Barcode types available for decoding: PDF-417,
Codabar, Code 128, Code 39, Code 39 extended,
Code 93, EAN-13, EAN-8, Interleaved 2 of 5 (ITF),
Standard 2 of 5 (Industrial), Matrix 2 of 5, IATA 2
of 5 (Airline), UPC-A, UPC-E, etc.
To purchase the device or enable its optional
functions, contact the manufacturer’s marketing
and sales department (for more information visit
the website www.regulaforensics.com).
1.2 Technical specications
1.2.1 The device corresponds to Class III by
IEC 60950–1 regarding protection against electric
shock.
1.2.2 According to EMC, the device complies with
EN 55022 (class B) and CISPR 24 standards.
1.2.3 The device is designed for indoor use in
heated rooms in the following climatic conditions:
