SCOOP SCOOP ASSEMBLY INSTRUCTIONS
GENERAL RECOMMENDATIONS:
Spotlight suitable for indoor and outdoor mounting, as well as on normally
flammable surfaces .
Protection class IP65.
Installation height: universal.
oHIGH VOLTAGE (above 1000 AC and 1000V √2 DC).
The symbol indicates that the object must be placed at a minimum safety
distance.
Such distance is measured along the optical axis of the lighting fixture from the
lamp side to the nearest object illuminated.
It is essential to replace safety shield (safety glass or UV filters) when demaged
or broken before switching the fixture on.
Photosensitive objects, if exposed to the action of sunbeams or artificial light
sources can bleach.
In the case of damage or breakage to the safety shields in the luminaire
(protective glass or UV filters), they must be replaced (with original
shields to be ordered from Reggiani Spa Illuminazione) before proceeding to
switch on the luminaire again.
Attention: The effectiveness of the anti-UV-filter depends on the illuminance
level (lux), the distance from the light source, the exposure duration and light
sensitivity of the individual objects.
Reggiani Spa Illuminazione does not accept any responsibility for possible
deterioration of exposed objects.
INSTALLATION AND CONNECTION OF THE FIXTURE TO THE MAINS:
Fasten bracket to the wall or ceiling with suitable wall plugs dia. 8 mm. Use
a cable rated no lower than type H05 RN-F (min cross section 1 mm2). Insert the
cable in the central hole of bracket and connect it to the socket supplied with
the lighting fixture.
Standard connection for plug : ground (yellow/green lead) pole; phase (brown
lead) pole 1; neutral (blue lead) pole 3.
After connecting the socket/plug, position the fixture on the bracket as shown in
the drawing.
Then lock it in the required position with set screw . If necessary, secure the
optical compartment on the base, by securely tightening nut and relative
screw as shown in dwg. .
TO REPLACE/INSTALL THE LAMP
- Disconnect from mains.
- Back-off and remove safety screw release handle to gain access to the
optical compartment.
N.B. for double ended lamp (halogen and metal halide types) proceed as
shown in fig. .
- For correct operation of double ended metal halide vapour lamps, it is
essential that the operation position be included within 45° on the flat-lying.
REFLECTOR ADJUSTMENT:
- Disconnect from mains.
- Gain access to the optical compartment as described above.
- Loosen (without removing completely) screws and turn the entire
reflector/gearbox assembly as shown in drawing.
- After adjustment, retighten the screws securely.
- Before switching on, check wheter the lamp is in its correct operating position
(see lamp manufacturer's instructions).
ASSEMBLY SCOOP LIGHTING FIXTURE ON POST
- Switch off from mains.
- Remove bracket from the fixture (not used in this specific application).
- Make the ground (earth) connection between the fixture and top of the post
by connecting to the tapped hole identified by symbol , the ground
lead disconnected from bracke .
- Connect the plug and socket, then fasten the fixture to the post with set screw
.
