Rega Ear Headphone Manuel utilisateur

Amplifier

Ear Headphone

ear english manual:ear.qxd 22/11/2007 10:47 Page 6

Ear Specification

Maximum output level into 32 ohm load ...................................................... 525 mW

Input sensitivity for maximum output into 32 ohm ........................................ 331 mV

Input level for 250 mW into 32 ohm load ...................................................... 230 mV

Maximum output level into 600 ohm load ...................................................... 55 mW

Input sensitivity for maximum output input 600 ohm ......................................465mV

Input impedance......................................................................................... 24K ohm

Gain ............................................................................................................... 21.7dB

Power requirements ................................................................... 24V AC @ 240mA

Frequency response .................................................... 20Hz to 35KHz - 1dB points

Recommended minimum load (normal operating conditions).........32Ωper channel

Power Supply Specifications

PS1 UK

Input.............................................................................................230V ~ 50Hz 0.05A

Output..............................................................................................24V ~ 300MA AC

PS1 EU (Euro 2 pin)

Input.............................................................................................230V ~ 50Hz 0.05A

Output..............................................................................................24V ~ 300MA AC

PS1 UL (American)

Input..........................................................................................................115V~60Hz

Output..............................................................................................24V ~ 300MA AC

ear english manual:ear.qxd 22/11/2007 10:47 Page 5

Method 4

Finally, you may use the Ear in between a pre-amplifier and power

amplifier input. The Ear will amplify any signal fed to the Cursa pre-

amplifier output and the link will feed the Maia/Exon power amplifiers.

The volume control on the pre-amplifier will control the headphone level

and the main speakers can be muted via the Ear.

How?

Connect the two sockets on the back marked INPUT (Red = Right, Black

= Left) to the pre-amplifier output sockets on the back of the Cursa pre-

amplifier. The two sockets on the back marked LINK (Red = Right, Black

= Left) are connected to the input sockets on the back of the power

amplifier. The mute on the front panel of the ear will mute the signal to

the speakers connected to the power amplifier. The volume control on

the pre-amplifier and the volume control on the Ear will affect the volume

level of the headphones. The best setting for the Ear volume control is

where the level of the headphones is the same as that of the main

speakers (the volume level on the Ear should be approximately 13:00

hours on the dial).

ear english manual:ear.qxd 22/11/2007 10:47 Page 4

Rega Research Limited., England

ear english manual:ear.qxd 22/11/2007 10:47 Page 3

Method 3

Used in between the amplifier pre-amp output and power amplifier input

- the Ear will amplify any signal fed to the pre-amplifier output sockets of

the Mira and Luna amplifiers. The volume on the amplifier will control the

headphone level and the main speakers can be muted via the Ear.

How?

Connect the two sockets on the back marked INPUT (Red = Right, Black

= Left) to the pre-amplifier output sockets on the back of the main

amplifier. The two sockets on the back marked LINK (Red = Right, Black

= Left) are connected to the power amplifier input sockets on the back

of the main amplifier. Remove the lid of the main amplifier and switch the

pre-power sockets link switch (located at the back of the Mira and Luna

amplifier) to OFF.

The mute on the front panel of the Ear will mute the signal to the

speakers connected to the main amplifier. The volume control on the

amplifier and the volume control on the Ear will affect the volume level

of the headphones. The best setting for the Ear volume control is where

the level of the headphones is the same as that of the main speakers

(the volume level on the Ear should be approximately 13:00 hours on the

dial).

ear english manual:ear.qxd 22/11/2007 10:47 Page 2

Method 1

The Ear can act as a stand alone amplifier that will amplify any

signal fed into the input sockets.

How?

Connect the two sockets on the back marked INPUT (Red = Right, Black

= Left.) to the source output sockets (CD, Cassette, Tuner etc.) The

sockets on the back marked LINK (Red = Right, Black = Left) could be

used to feed the signal to another amplifier if required. The volume

control on the Ear may be used to adjust the level of the headphones.

Method 2

Used in between the Tape output on the amplifier and the cassette or

tape recorder. The Ear will amplify any signal fed to the tape output

sockets. However, the volume control on the amplifier will not control the

headphone level.

How?

Connect the two sockets on the back marked INPUT (Red = Right, Black

= Left) to the amplifier tape output sockets. The two sockets on the back

marked LINK (Red = Right, Black = Left) are connected to the Tape

input (record) sockets on the cassette or tape recorder. The mute on the

front panel will mute the signal to the cassette or tape recorder. The

volume control on the amplifier will not affect the volume level of the

headphones; use the volume control on the Ear to adjust the level of the

headphones.

ear english manual:ear.qxd 22/11/2007 10:47 Page 1
