:: Introduction
Thank you for purchasing Reedy’s 121VS Nitro Engine.
Designed in-house by our esteemed engineering staff, this engine is
produced using state-of-the-art materials and high-tech manufacturing
processes. The result is a powerful, user-friendly engine suitable for
organized competition or casual driving sessions with your friends.
Please read the Owner’s Manual thoroughly before starting your engine
for the first time.
The following items are required to set up and start your engine:
• Model Car Fuel w/20% lubricant • 8.0mm Glow Plug Wrench
• Glow Igniter • 3mm Flat Tuning Screwdriver
• Fuel Bottle • MC59 Standard Glow Plug
• Air Filter Oil
Required Equipment
3
: a e ec ical a
:: Features & Technical Data
• ABC Construction
• Precision Ball Bearings
• Machined Aluminum
Heatsink Head
• 2-Needle Carburetor
• Uses Standard Glow Plug
• Reliable Pull-Start system
Part # 802
Displacement 3.49cc
Maximum RPM 36,000
Stroke 16.8mm
Bore 16.26mm
Cylinder ABC
Crankshaft Dia. 14.0mm
Glow Plug Type Standard
4
: af I ct n a d r g
:: Safety Instructions and Warnings
This product is a powerful internal combustion engine. It is not a toy.
As the owner, you are responsible for the safe and proper operation of
the engine and the vehicle in which it is installed.
• Because deadly carbon monoxide gas will be released in the engine’s
exhaust, it should only be operated outdoors.
• During operation, the engine will become dangerously hot to the touch.
Contact with the engine or parts connected to the engine could result in
a serious burn.
• This engine must only be operated with fuels designed for R/C car
engines.
• R/C fuels are highly flammable. Always keep fuel away from exposed
flames or other sources of ignition. Carefully read the warnings on the
R/C fuel container before use.
• Mount the engine securely and set throttle linkages as explained in the
R/C vehicle’s owner’s manual. Always utilize a throttle return spring.
5
: af I ct n a d r g (co )
:: Safety Instructions and Warnings (cont.)
:: Installation
:: Installation
• Never stop the engine by slowing the flywheel with fingers or other
objects. Never attempt to plug the exhaust outlet with your fingers.
With the engine running at neutral, pinch the fuel supply line to stop the
flow of fuel to the carburetor.
• Keep spectators and small children at a safe distance when starting the
engine and operating the vehicle.
Please consult the R/C vehicle’s owner’s manual for proper installation of
the engine, clutch assembly, exhaust, and linkages. Start with final drive
ratio of 12.4:1. Depending upon the track layout and surface, the
optimum ratio may fall between 11.6:1 and 13.2:1.
