2. Network Setup
Internet connection can be setup via Wired LAN or Wireless LAN (WiFi).
Your Tuner requires a broadband Internet connection through wired Ethernet or WiFi.
The easiest way is use a CAT 5 or CAT 6 cable to connect through wired Ethernet to
a Wi-Fi router, which connects to a modem or NBN router provided by your ISP.
Wired LAN (Ethernet)
For Wired Ethernet connection to a router with DHCP enabled, the network
configuration for Internet connection is automatically done and the Tuner can be used
for Internet radio and UPnP sharing without user interaction. When the
network is connected, the Ethernet icon will appear on the top left corner.
Wireless LAN (Wi-Fi)
• Connect the Wi-Fi antenna to the connector on the rear side of the tuner. If this is first
time use, the Configure Network wizard will be displayed. Choose Yes to start configuring
network. Press the [Back/ ◄ ] button to highlight Yes and press
[Tune/Select] to confirm.
Configure Network?
< Yes> No
• Select Add/Remove AP from the list, use the [Tune/Select] knob to scroll and
press it to confirm, then choose Add AP (Scan):
Add/Remove AP
AP:[ ]
Add AP
Remove AP
• It will start scanning the available Wi-Fi routers around. Scroll to your network and press
[OK] to confirm. If your wifi network has a security code protected, it will ask you to enter
the passphrase/password. Please refer to the above section 'How to input security code
for your wireless network' on P.3.
Note: The password is case sensitive. Please consult with the one who setup your
network if you don't know the password.
• When the Wi-Fi connection is successful, the Association Complete will be shown
briefly. The wifi signal bar will appear on the top left corner of the display:
Wi-Fi signal bar
-06-
