Red Sea ReefATO+ Manuel utilisateur
ReefATO+
ENG | DE | FR
User Manual
Red Sea ReefATO+
3
ENG
User Manual
Smart ATO – Temperature Sensor – Leak Detector
ReefATO+
Red Sea ReefATO+
4
Red Sea ReefATO+
5
ENG
Contents
Introduction................................................................................6
Safety..........................................................................................7
Components of the ReefATO+ system.....................................8
Guide to the ReefATO+ Controller ............................................9
How the ReefATO+ Auto-Fill system works ..........................11
Introduction to the ReefBeat app ..........................................12
Installing the ReefATO+ system .............................................12
Setting up the ReefATO+.........................................................16
Device Maintenance................................................................20
Troubleshooting .......................................................................21
Warranty ...................................................................................22
Red Sea ReefATO+
6
Introduction
Congratulations on your purchase of Red Sea’s 3-in-1 ReefATO+ smart
Reef Aquarium ATO system, plus temperature monitor and leak detector.
The ReefATO+ is designed to maintain a stable salinity and water volume
in a reef aquarium by automatically replenishing the water lost due to
evaporation.
The ReefATO+ consists of a slim-line, multi-input, solid-state water level
sensor, bespoke DC pump, wi-fi connected controller and a complete set
of accessories required to install the system. In addition, the ReefATO+
provides two other critical aquarium health indicators; a fully featured
on-line digital temperature monitor that is embedded in the level sensor
and an external leak detector.
The ReefATO+ is part of Red Sea’s suite of smart devices that are
operated via Wi-Fi by Red Sea’s ReefBeat®App, which needs to be
installed on a smart mobile device with internet connectivity.
Welcome to Red Sea’s smart reef-keeping.
The Red Sea Team
Red Sea ReefATO+
7
ENG
Safety
PLEASE READ AND FOLLOW ALL SAFETY INSTRUCTIONS
THIS DEVICE IS INTENDED FOR INDOOR USE ONLY.
DANGER: To avoid possible electric shock, special care should be taken
when handling a wet aquarium. For each of the following
situations, do not attempt repairs yourself; return the appliance
to an authorized service facility for service or discard the
appliance.
WARNING: To guard against injury, basic safety precautions should be
observed, including the following:
Do not operate any appliance if it has a damaged cord or plug, if it is
malfunctioning, or if it is dropped or damaged in any manner.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory, or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
The appliance is only to be used
with the power supply unit
provided with the appliance.
Close supervision is necessary
when any appliance is used by
or near children.
To avoid injury, do not contact
moving parts.
Always unplug an appliance
from an outlet when not in use, before putting on or taking off parts, and
before cleaning. Never pull the cord itself to remove the plug from the
outlet. Grasp the plug and pull to disconnect.
Do not use an appliance for anything other than its intended use.
The use of attachments not recommended or sold by the appliance
manufacturer may cause unsafe conditions.
Do not install or store the appliance where it will be exposed to the
weather or to temperatures below freezing point.
Make sure an appliance is securely installed before operating it.
Read and observe all the important notices on the appliance.
Note: A cord rated for less amperes or watts than the appliance rating
may overheat. Care should be taken to arrange the cord so that
it cannot be tripped over or pulled accidentally.
Do not use if cord is damaged. In case of need, do not attempt
to replace or repair yourself; return the appliance to an
authorized service facility for service or discard the appliance.
In case of need, do not attempt to replace yourself; return the
appliance to an authorized service facility for service or discard
the appliance.
Red Sea ReefATO+
8
Components of the ReefATO+ system
R35623
ATO sensor magnetic corner mounting bracket
(not included with the ReefATO+ kit for Reefer Aquariums)
R35625
ReefATO+
Corner Bracket
Magnets
(not included with the
ReefATO+ kit for
Reefer Aquariums)
R35628
Leak Detector
R35626
Silicone Tubing
R35627
Syphon Breaker
R35621
ATO
Pump
R35624
Tube Holder
R35620
ReefBeat
Connected
ATO+ controller
R35629
Sensor holder
R35622
ATO Level &
Temperature
Sensor
Red Sea ReefATO+
9
ENG
Guide to the ReefATO+Controller
Settings
Indicator LED
Leak Detector
Status LED
ATO Sensor
Status LED
ATO Pump
Status LED
Power
Status LED Leak Detector
Port
ATO Sensor
Port
ATO Pump
Port
DC inlet
Port
Settings Button
Manual Pump
Button
Red Sea ReefATO+
10
LED Indicators
Settings LED Indicator:
• Solid Red light – Controller is connected to the home-network.
• Blinking Red light – Controller is in Wi-Fi Access Point (AP) mode (can
be discovered by Wi-Fi devices).
• Rapid Blinking Red light – Controller cannot access the home-network
(network name and/or password are incorrect or known network has
become unavailable)
• No Red light – Controller Wi-Fi is off.
• Double blink – indicates change of status / end of process.
Leak Detector Status LED Indicator:
• Solid Red light –Leak detection is enabled
• No Red light – Leak detection is disabled
• Blinking Red light – Leak has been detected and Auto-Fill has been
disabled
ATO Sensor Status LED Indicator:
• Solid Red light –Auto-Fill is enabled
• No Red light –Auto-Fill is disabled
• Blinking Red light – ATO Sensor is missing
Pump Statu¬s LED Indicator:
• Solid Red light – Pump is on.
• No Red light – Pump is off.
• Blinking Red light – Pump malfunction (missing, stalled, or running
dry)
Power LED Indicator:
• Solid Red light –PSU is attached.
• No Red light –PSU is not attached.
Settings Button – Function
If settings indicator LED is off (ReefATO+ Controller Wi-Fi is off): Pressing
button for 5 seconds (until double blink) activates Wi-Fi AP mode.
If settings indicator LED is blinking (ReefATO+ Controller Wi-Fi is in AP
mode): Pressing button for 5 seconds (until double blink) switches Wi-Fi
off.
If indicator LED is on (ReefATO+ Controller Wi-Fi is connected to a Wi-Fi
network): Pressing button for 5 seconds (until double blink) disconnects
the ReefATO+ from the network and switches it to Wi-Fi AP mode. (Note:
before disconnecting a ReefATO+ from a network, delete it from the
ReefBeat App via the Device Manager.) Note: All settings are retained
and can be restored when reconnecting to the ReefBeat.
Reboot: Pressing and releasing the button for less than 2 seconds will
cause the unit to shut down and restart. User settings are not affected.
Clear Settings: Pressing the button for 15 seconds (until double blink)
deletes all user settings and switches the Wi-Fi to AP mode. Complete
the reset process by disconnecting and reconnecting the DC power.
Manual Pump Button - Function
Pressing on the manual pump button will operate the pump for as
long as it is pressed. The pump status LED will be on while the pump is
running. In the event that the Auto-fill has been automatically disabled
by the controller (such as if the RO reservoir has run out of water) a
short press on pump button will reinstate the Auto-fill function.
