RealTrace RT100 V8BT Manuel utilisateur
1
Realtrace RT100 V8BT
ISO FDXB tag compatible with the possibility to write additional
data A name and a phone number to datachips
Application PetScan on iPhone and Android
In/out button (1)
Mini USB
interface
LED blue Bluetooth activated
LED red charging battery
LED green battery charged
Display OLED
128×64 pixels
Scroll up button (2)
Mid button (4)
( Enter)
Scroll down button (3)
Battery charge level
2
Table of contents
Characteristics of the V8BT…………………………………….. pages 1/3
Menu « Settings » ……………………………………………….. page 4
Enable and disable Bluetooth …………………………………... page 5/6/7
Changing the choice of language……………………………….. page 8
Reading a chip « SCAN »……………………………………….. page 9
The memory of the V8BT………………………………… ……. page 10
- enable the memory………………………………………... page 11
- disable the memory ………………………………………. page 12
- erase the memory ………………………………………… page 13
Datas transmissions with a PC………………………………….. pages 14/17
RealTrace Terminal……………………………………………… pages 20/25
Customization of the V8BT : Displaying and Time out……….. pages 26/27
Android mobile phone software for RT250-V8BT and V8M…. pages 28/36
iOS mobile phone software for RT250-V8BT and V8M..……….. pages 37/51
Bootloader…………………………………………………………... pages 52/54
Tools for development……………………………………………… pages 54
System “Woosit” …………………………………………………… pages 55/56
3
Reader characteristics
Frequency
134.2kHz Read and write ISO 14223
Protocol
ISO11784/5 FDX-A, FDX-B, EM4102, HDX
Reading range
Up to 13 cm（12mm×2mm, glass tag）FDXB
10cm (12mm x 2mm glasstag FDXA)
18/20cm ear tag FDXB (depends of the provider)
15/18cm ear tag HDX (depends of the provider)
Display
128×64，black and white，OLED
Keys
4 buttons
Indication
Battery charge control and Bluetooth . Buzzer
USB port
USB virtual comport，bluetooth virtual com.port
Power supply
Lithium battery，1500mAh，3.7V
Dimension
155mm (L)×82(W)×33(H)
Net weight
155g
Charging mode
Mini USB
Accessories
Mini USB cable, Product instructions. Battery.
Compliance certifications
FCC, CE certification
Memory
Up to 800 ID numbers
The V8BT is delivered with English language configured. To change the language see
chapter hereunder « Menu Language »
4
Menu “Settings”
Seven languages
Max 800 ID numbers
Enable and disable
Displaying hexadecimal or decimal
***********
******
*
Settings
Languages
Memory
Bluetooth
HEX
Enter menu settings
To be able to transmit the tag numbers read or the numbers recorded in the memory (maximum 200), via
Bluetooth or using the USB cable, the user needs to have installed the appropriate driver* on his PC. This
driver can be downloaded free of charge from :
http://www.swissplusid.com/downloads/RTDriver.zip
Once the driver is installed on your PC you will need to have application software to view and
potentially record the data sent by the reader.
You can use Hyperterminal if your operating system is XP or Realtrace Terminal with XP or Windows
7/8/10.
With a mobil phone you can use the V8BT after installing “PetScan” from PlayStore or AppStore.
5
Bluetooth V8BT reader
All readers are delivered with integrated Bluetooth technology. The Bluetooth function consumes energy. It
is therefore recommended to activate this function only for the time necessary for its use.
To stop Bluetooth communication, simply select the “Bluetooth” menu and disable the function.
Communication via Bluetooth is limited to around 10/15 meters and depends on the environment of your
PC. To enable Bluetooth on your PC, please consult your computer user manual. Don’t forget to disable the
security of Bluetooth on your PC because the V8BT don’t ask a security code. If your PC need a code, enter
1234.
Data transmission by Bluetooth or via the USB cable
*A driver is a program enabling an operating system, in this case Windows XP or Windows 7/8/10 on a
PC, to recognise a hardware peripheral and use it.
6
Synoptic Menu « Scan »
Synoptic Menu “SCAN”
SCAN
After 25 seconds After 60 seconds
Reading
20 seconds max.
No transonder
Found!
FDXB
939 2784879521125
Charging indicator light
Scan
Button In/Out
Settings
Continuous Scan
7
Synoptics Menu “Bluetooth ”
Bluetooth
Enable
Bluetooth enabled
Charging indicator light
Scan
Enable Bluetooth
Bluetooth
Button IN/OUT
1
4
3
2
1
8
Bluetooth
Disable
Scan
Disable Bluetooth
Bluetooth
Button IN/OUT
Scan
1
2
3
4
5
9
Synoptic Menu « Scan »
Synoptic Menu “SCAN”
SCAN
After 25 seconds After 60 seconds
Reading
20 seconds max.
No transonder
Found!
FDXB
939 2784879521125
Charging indicator light
Scan
Button In/Out
Settings
Continuous Scan
10
Using the V8BT Memory
The V8BT reader has a memory enabling it to store 800 identifiers (tag numbers).
This function must be activated by the user if he wishes to use it.
Storage of numbers read by the V8BT reader
The V8BT allows the user to store the numbers of the tags read in order to transfer them subsequently to
a PC using the USB cable included with the reader or with Bluetooth.
To use this function, you must first activate the “Memory” function (see block diagram: “Memory 1”).
When the Memory is activated each time a new tag is read, the reader displays the number but if the
same tag is read twice by mistake the reader indicates this by emitting a characteristic beep and
displaying “DUP” on the right of the screen.
This number will not be stored a second time.
If the reader is switched off, the memory function will still be activated when it is switched on again.
Deactivating the memory
The memory can be deactivated via the “Memory” menu.
Two cases may arise:
First case:
Numbers are recorded in the reader’s memory (Block diagram: Memory 3)
In this case you must transmit the list of recorded numbers actually or virtually (without plugging in
the USB cable) and then erase them.
Second case:
The memory has been previously activated but no number has been recorded.
In this case simply “deactivate” the memory (block diagram: “Memory 2”)
Erasing the memory
To erase the contents of the memory to avoid errors, you must select the “Memory” menu and transmit
the list of recorded numbers actually or virtually (without plugging in the USB cable) and then erase
them (see Block Diagram: Memory 3).
