Real-El S-50 Manuel utilisateur

S-50

2.0 USB MULTIMEDIA

SPEAKER SYSTEM

OPERATION MANUAL

Technical support www.real-el.com

Operation Manual

S-50

ENG

BUYER RECOMMENDATIONS

•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the

device for damage; if the product was damaged during transportation, address the ﬁrm, which

carried out the delivery; if the product functions incorrectly, address the dealer at once.

•Check up the package contents and availability of the warranty card. Make sure the warranty card

has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods

number corresponds to that in the warranty card. Remember that at the loss of warranty card or

lack of coincidence of numbers you are deprived the right on warranty repair.

• Do not switch on the product immediately after you bring it into a room from environment with

negative temperature! After unpacking, the product should be kept in conditions of room tempe-

rature for at least 4 hours.

2. PACKAGE CONTENTS

• Speaker system — 1 pc

• User’s manual — 1 pc

• Warranty card — 1 pc

Congratulations on your purchase of the TM REAL-EL speaker system!

Please read this Operation Manual before using the unit and retain this Operation Manual in a safe

place for future reference.

TRADEMARKS

All trademarks are the property of their legal holders.

Laptop Volume

adjustment

+/-

USB

mini jack

Ø 3.5 mm

Аudio cable

Fig. 1

Technical support: www.real-el.com

2.0 USB Multimedia Speaker

System

ENG

S-50

3. SAFETY PRECAUTIONS

• Do not open the multimedia speaker system (MSS) and do not perform repairs by yourself.

Service and repairs should be performed only by qualiﬁed specialists at authorized service centers.

The list of authorized service centers is on www.real-el.com

• Make sure that foreign objects do not get inside the holes of the MSS.

• Protect the MSS from high humidity, water and dust.

• Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose it

to direct sunlight.

•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.

• If the MSS does not operate, unplug USB cable it and address your dealer.

4. TECHNICAL DESCRIPTION

S-50 2.0 USB Multimedia Speaker System is an easy and reasonable solution for your computer

sound. In addition, the MSS is compatibility with notebooks, mobile devices and other sound

sources. The speaker with built-in ampliﬁer, built-in signal and USB cables is named an active

speaker.

MSS special features

• Compact design

• High quality speaker driver

• Improved sound transmission system

• Compatibility with PC, notebooks, mobile devices and other sound sources

• USB powered (from a notebook, PC or power unit)

• Volume adjustment on cable

Technical support: www.real-el.com

ENG

Operation Manual

S-50

Rear panels

aVolume knob

bBult-in signal cable

cBult-in USB cable

dBult-in audio cable

5. PREPARATION AND OPERATION

Speaker placement

•Place the speakers symmetrically to the listener at least one meter away.

•Place MSS far away from monitors and TV sets, as insigniﬁcant image distortion in these

supersensitive devices is possible.

MSS Connecting

S-50 Multimedia Speaker System (MSS) can be connected to USB port on your computer or laptop

(see connection diagram, ﬁg. 1).

• Plug USB cable cto the USB-port on your computer (laptop) or power unit.

• Plug signal cable mini-jack bto PC sound card or to audio output of the audio source.

• Adjust speaker volume level by Windows tools or using volume wheel aon the rear panes of active

speaker at your own discretion.

• Please unplug USB cable cafter shutting down your laptop or PC.

Note: Connect the speakers to USB port of your laptop or PC otherwise please use active

USB-hub.

Technical support: www.real-el.com

ENG

2.0 USB Multimedia Speaker

System

S-50

6. TROUBLESHOOTING

Attention! If none of the above methods can solve the problem, please seek professional

advice at your nearest service center. Never attempt to repair the product yourself.

Problem

The MSS does not

turn on.

No sound or sound

of speakers is too

quiet.

Distortion of

sound.

Cause

The MSS isn’t connected to a USB port.

Volume level is set at its minimum value.

Improperly connected audio source.

Large amplitude of the input signal.

Solution

Check the connection.

Adjust the volume control knob.

Connect audio sources correctly.

Turn down the source volume

and the MSS volume.

Parameter, measurement unit

Output power (RMS), W

Frequency range, Hz

Speaker dimensions, mm

Power supply

Case material

Dimensions (one speaker), mm

Weight, g

Value

6 (3 + 3)

120 – 19.000

Ø 50

USB / 5V DC

plastic

76 × 71 × 76

310

7. TECHNICAL SPECIFICATIONS

Notes:

• Technical speciﬁcations given in this table are supplemental information and cannot give

occasion to claims.

• Technical speciﬁcations and package contents are subject to change without notice due to

the improvement of REAL-EL production.

Models: S-50

Manufacturer: ENEL GROUP OU, Harju maakond, Rae vald, Jüri alevik, Aruküla

tee 55a, 75301, Estonia. Made in China.

® Registered Trademark of ENEL GROUP OU. Estonia.
