RS2606EA 7/16/02 5:29 PM Page 1

POWER

DECK-1

REC/PLAYBACK

PHONES

SOUND SYSTEM

KEVLAR

5 DISC CHANGER

DIGIT

ALAUDIO SYSTEMRS2531

SIMULTANEOUS PLAY AND LOAD SYSTEM

COMPACTDISC AUDIO

CD-RW COMPATIBLE

CLOCKTIMER

BUIL

-IN POWEREDSUBWOOFERSYSTEM

CUSTOM/FLATROCK/CLASSIC

POP/JAZ

DIRECT DISC ACCES

DISC

SOURCE

BAND

AUTOPROG.

AUTOMATIC RECORDLEVEL/ AUTOSTOPC

SURROUND

KEVLARWOOFER

EQCONTROL

DISCSKIP

OPEN/CLOSE

POWERED SUPER WOOFER

Thomson multimedia Marketing Australia Pty Ltd.

Level 6, 7 Macquarie Place

SYDNEY NSW2000

AUSTRALIA

55523540

TIMER

AUTO PROG.

STANDBY

DIGITAL AUDIO SYSTEM

ROCK

/CLASSIC CUSTOM/FLAT POP

DIGITAL AUDIO SYSTEM RS2602

RS2606EA 7/16/02 5:30 PM Page 2

DEMO

DIMMER

DECK-2

PLAYBACK

SUB

WOOFER

VOLUME

HANGER

TEMRS2531

AND LOAD SYSTEM

PROG. SET

REPEAT

SUBWOOFERSYSTEM

CUSTOM/FLAT

POP/JAZZ

CT DISC ACCESS

DISC

UTOSTOPCONTINUOUSPLAY/TAPEDUBBING2 - 1

SURROUND

VLARWOOFER

EQCONTROL

TUNE/PRESET

DISC

POWERED SUPER WOOFER

CD DISPLAY

usermanual

RS2606EA

TUNE/PRESET

OPEN/CLOSE

O SYSTEM

CLOCK PROG./SET

USTOM/FLAT POP/JAZZ VOLUME

RS2606EA 7/16/02 5:30 PM Page 3

Safety Information

WARNING:TO PREVENT FIRE OR ELECTRICAL

SHOCK HAZARD, DO NOT EXPOSETHIS PRODUCT

TO RAIN OR MOISTURE.

SEE MARKING ON BOTTOM / BACK OF PRODUCT

CAUTION

RISKOFELECTRICSHOCK

DONOTOPEN

THE EXCLAMATION

POINT WITHIN THE

TRIANGLE IS A

WARNING SIGN

ALERTING YOU OF

IMPORTANT

INSTRUCTIONS

ACCOMPANYING

THE PRODUCT.

THE LIGHTNING

FLASH AND ARROW-

HEAD WITHIN THE

TRIANGLE IS A

WARNING SIGN

ALERTING YOU OF

"DANGEROUS

VOLTAGE" INSIDE

THE PRODUCT.

CAUTION: TO REDUCE THE

RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER

(OR BACK). NO USER-

SERVICEABLE PARTS IN-

SIDE. REFER SERVICING

TO QUALIFIED SERVICE

PERSONNEL.

CAUTION!

Invisible laser radiation when open. Avoid exposure to

beam. Class 1 laser product. This system must be

opened only by qualified technicians to prevent acci-

dents caused by the laser beam.

LASER λ= 780 nm, P max = 5 mW

Rating Information: At bottom of the unit

this unit comply with the existing requirements

In accordance with the rating plate of the unit, this

unit complies with current standards concerning elec-

trical safety and electromagnetic compatibility.

Please respect the environment Before throwing any

batteries away, consult your distributor who may be

able to take them back for specific recycling.

Have a Blast- Just Not in Your Eardrums

Make sure you turn down the volume on the unit

before you put on headphones. Increase the volume to

the desired level only after headphone are in place.

ADVARSEL!

USYNLIG LASERSTRÅLNING VED ÅBNING NAR

SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION.

UNGDÅ UDSAETTELSE FOR STRÅLNING.

VORSICHT!

UNSICHTBARE LASERSTRALUNG

WENN ABDECKUNG GEÖFFNET UND SICHERHEITS–

VERRIEGELUNG ÜBERBRÜCKT.

NICHT DEM LASERSTRAHL AUSSETZEN!

CLASS 1 LASER PRODUCT

LASER KLASSE 1

APPAREIL A LASER

DE CLASSE 1

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

CAUTION – INVISIBLE LASER RADIATION

WHEN OPEN AND INTERLOCKS FAILED OR

DEFEATED. AVOID EXPOSURE TO BEAM.

ATTENTION –

RAYONNEMENT LASER INVISIBLE

DANGEREUX EN CAS D'OUVERTURE ET LORSQUE

LA SECURITE EST NEUTRALISEE.

EXPOSITION DANGEREUSE AU FAISCEAU.

VARNING–

OSYNLIG LASERSTRÅLNING NÄR DENNA DEL

ÄR ÖPPNAD OCH SPÄRRAN ÄR URKOPPLADE.

BETRAKTA EJ STRÅLEN.

VARO!

AVAT T AESSA JA SOUJALUKITUSOHITETT

AESSA

OLET AL

TTIINA NÄKYMÄTTÖMÄLLE.

LASERSÄTEILYLLE ÄLÄ KATSO SÄTEESEEN.

AC Power

Important: This set operates

on power 240V~50Hz and

the power cord is supplied

with SAA plug. It complies

with AS/NZS 3250.

FOR ALL YOUR SERVICE NEEDS AND ENQUIRIES

ABOUT THIS PRODUCT, RING 1-800-000-155.

(ONLY APPLICABLE IN AUSTRALIA).

RS2606EA 7/16/02 5:30 PM Page 4

Safety Information

Installation . . . . . . . . . .2

Controls & Indicators

Main Unit . . . . . . . . . . . . . . .3

Tape Player . . . . . . . . . . . . . .3

Remote Control . . . . . . . . . .4

Display

Showing the Demonstration

. . . . . . . . . . . . . . . . . . . . . . . .5

Display Timer/Clock . . . . . . .5

Setting the Time . . . . . . . . .5

Setting the Timer . . . . . . . . .5

Activating the Timer . . . . . .5

Adjusting the Display

Brightness . . . . . . . . . . . . . . .5

Sleep Mode . . . . . . . . . . . . . .5

Sound Features

Using Preset Equalizer Curves

. . . . . . . . . . . . . . . . . . . . . . . .6

Creating a Custom Curve

. . . . . . . . . . . . . . . . . . . . . . . .6

Bass Boost . . . . . . . . . . . . . . .6

Muting Audio . . . . . . . . . . . .6

X- Surround . . . . . . . . . . . . . .6

CD Player

Loading Discs . . . . . . . . . . . .6

Playing Discs . . . . . . . . . . . . .6

Shuffling the Play Order . . .6

Sampling Tracks . . . . . . . . . .6

Repeating the Play Order . .7

Setting Up a CD program . .7

Playing a Program List . . . . .7

Displaying the Program list

. . . . . . . . . . . . . . . . . . . . . . . .7

Deleting a Program List . . .7

Skipping a Disc . . . . . . . . . . .7

Searching through a CD . . .7

Tuner

Tuning to a Station . . . . . . .8

Using Presets . . . . . . . . . . . .8

Auto Preset Program (for FM

only) . . . . . . . . . . . . . . . . . . . .8

Setting Presets . . . . . . . . . . .8

Suppressing Stereo Signal

. . . . . . . . . . . . . . . . . . . . . . . .8

Tape Player

Playing a Tape . . . . . . . . . . .9

Continuous Play . . . . . . . . . .9

Recording . . . . . . . . . . . . . . .9

From Tuner . . . . . . . . . . . . . .9

From CD . . . . . . . . . . . . . . . .9

Tape to Tape . . . . . . . . . . . . .9

From an Auxiliary Input . . .9

Troubleshooting Tips

. . . . . . . . . . . . . . . . . . .10

Maintenance

Cleaning . . . . . . . . . . . . . . .11

CD Player . . . . . . . . . . . . . . .11

Tape Player . . . . . . . . . . . . .11

More Information . . . .12

Contents

RS2606EA 7/16/02 5:30 PM Page 5

Installation

TIMER

AUTO PROG.

TUNE/PRESET

OPEN/CLOSESTANDBY

DIGITAL AUDIO SYSTEM

CLOCK PROG./SET

ROCK

/CLASSIC CUSTOM/FLAT POP/JAZZ VOLUME

To ensure sufficient ventilation, keep the spacings shown below free from other surfaces:

10 cm 10 cm

10 cm 5 cm

10 cm

1. AM Loop Antenna Connector

2. Auxiliary Connector

3. Surround Speaker Jacks

4. Main Speaker Jacks

5. Subwoofer Speaker Jacks

6. FM Antenna Jack

Unpacking the system:

You should have:

• one main unit (with 2 speakers);

• surround speakers

• one remote control;

• one AM loop antenna;

• T-Type FM antenna wire;

• one user’s guide;

Ω

AM LOOP

R L

AUX IN

SURROUND SPEAKERS 8

Ω

MAIN SPEAKERS 6

Ω

R L

+ +

- -

WOOFER SPEAKERS 6

Ω

+ R - - L +

Release tab to lock wire in

the terminal.

NOTE: Make sure the insulation is completely removed from the

ends of the Antenna and speaker wires at all connection

points.

Antenna and Speaker Wire Connection

Push terminal tab down to

insert wire.

RS2606EA 7/16/02 5:30 PM Page 6

Controls and Indicators

Main Unit

OPEN/CLOSE —Opens or closes

the disc tray.

DISC 1 - DISC 5 —Selects disc 1,

2, 3, 4, or 5

DISC SKIP —Skips to the next CD

in the tray

STANDBY/POWER —Turns

power on or off (STANDBY mode).

PHONES —Jack for connecting

headphones

SOURCE—Selects the CD player/

tuner/ tape player/ external source

DIMMER/DEMO —Turns the fea-

ture demonstration on or off,

adjusts display brightness.

STOP / TUNE / PRESET—

Stops CD track, sets tune

or preset mode

SKIP FORWARD —

Increments radio fre-

quency, CD tracks or set-

ting options.

SKIP BACKWARD —

Decrements radio fre-

quency, CD tracks or set-

ting options

PLAY/PAUSE —Plays or

pauses CD

CLOCK —Shows clock time and

enters clock setting mode.

TIMER —Enters timer setting

mode and turns the mode on/off.

BAND/AUTO PROG.

—Changes

between FM and AM tuner

bands. Enters auto preset pro-

gram in FM mode.

REPEAT - Selects among repeat

modes.

PROG./SET- enters program or

setting mode for CD & tuner

mode.

BASS BOOST —Turns Bass boost

on or off

ROCK/CLASSIC, CUSTOM/FLAT,

POP/JAZZ —selects among the

different EQ modes.

X-SURROUND —Press once to

display current setting, press

again while the setting is

shown on display to toggle

Bass Boost on / off.

VOLUME

—I

ncreases/ decreases

volume.

Tape Player

RECORD

PLAY

REWIND

FAST-FORWARD

STOP/EJECT

PAUSE

TIMER

AUTO PROG.

TUNE/PRESET

OPEN/CLOSESTANDBY

DIGITAL AUDIO SYSTEM

CLOCK PROG./SET

ROCK

/CLASSIC CUSTOM/FLAT POP/JAZZ VOLUME

Tip: In STANDBY mode (press

POWER off), the system dis-

plays the time. Press POWER to

turn the system on in the previously used

mode. Press CD, TAPE, TUNER, or AUX

(Remote Only) to select the corresponding

mode. Look at the display icons to identify

the current mode.

RS2606EA 7/16/02 5:30 PM Page 7

Controls and Indicators

Remote Control

POWER —Turns power on or off (STANDBY mode).

TUNER —Selects tuner

CD —Selects CD player

TAPE —Selects tape player

AUX —Selects external input.

B-BOOST - Turns B BOOST on or off

VOL+ or VOL- —Increases/ decreases volume

EQ —Selects equalizer presets

PLAY/PAUSE —Plays or pauses current CD

STOP —Stops playing CD

NEXT/FWD —Increments CD track; searches through CD

PREV/REV—Decrements CD track; searches through CD

(Press NEXT/FWD or PREV/REV to tune up/ down tuner frequen-

cy)

DISC SKIP —Skips to next CD

REPEAT —Repeats a track, CD, or all CDs.

MUTE - mutes sound

SHUFFLE —Turns on/off random listening

FM ST. - Toggles between FM stereo and mono

INTRO - Turns INTRO mode on or off to play the first 10 seconds

of each track.

PRESET UP/DOWN —Selects next/ previous preset station

OPEN/CLOSE —opens/closes cd tray door

SLEEP - selects the time interval in minutes before the unit turns

off

X-SURROUND - enables/disables X-surround feature

TUNER TAPE

AUX

SOURCE

E Q

B BOOST

VOL

REV

FWD

DISC SKIP

PRESET

REPEAT

MUTE

SHUFFLE

SLEEP

FM ST.

DOWN

INTRO

POWER X-SURROUND

OPEN/CLOSE STOP

Battery Size:

“AAA” or “UM-4” or “R03”

RS2606EA 7/16/02 5:30 PM Page 8

Showing the Demonstration

Not operational in CD mode. Press DIMMER/DEMO

to turn on/off demonstration mode. The demonstra-

tion scrolls through all display operations.

DISPLAY TIMER/CLOCK

Setting the Time

1. Press and hold CLOCK until the hour flashes on

the display.

2. Press SKIP BACKWARD or SKIP FOR-

WARD to set the hour and then press

CLOCK to shift to minute digits.

3. Press SKIP BACKWARD or SKIP FOR-

WARD to set the minute.

4. Press SET to save settings and STOP to quit set-

ting.

Note: When system is ON, you can press CLOCK to

display the current time for about 2 seconds.

Setting the Timer

1. Press and hold TIMER until the ON appear with

the hour flashing ( ON - timer on time )

2. For setting time, press SKIP FORWARD /

BACKWARD to set the hour and then

press TIMER to shift to minute digits.

3. Press SKIP FORWARD / BACKWARD

to set the minute.

4. Press TIMER to change to OF (timer off time) with

hour flashing. Repeat steps 2 & 3 for timer off time

setting.

5. Press TIMER to select source. Press SKIP FOR-

WARD / BACKWARD to select

between CD /TUNER / TAPE)

6. Press TIMER to set volume. Rotate the VOLUME

knob to set desired volume level.

7. Press SET to save settings or STOP to quit setting.

Activating the Timer

Press and release TIMER to turn on/off

the alarm. The alarm is active when the

clock icon indicator is lit.

Adjusting the Display Brightness

1. Press and hold DIM-

MER/DEMO for more

than 2 seconds.

2. While the dimmer is dis-

played, press and release

DIMMER/DEMO to select the desired level (DIM 0 -

3).

Sleep Mode

You can select the time interval in minutes before

the unit turns off automatically. Press SLEEP on the

remote to select among 120, 90, 60, 45, 30, 15 & 5

minutes. (Remote Only)

Display

DIM 2

RS2606EA 7/16/02 5:30 PM Page 9

CD PLAYER

Loading Discs

1. Press SOURCE repeatedly to select CD mode.

2. Press OPEN/CLOSE to open the drawer.

3. Insert up to five discs with label face up. (Press DISC

SKIP to rotate the disc carrier.)

4. Press OPEN/CLOSE to close the drawer. Loaded disc

position icon lights.

Playing Discs

Press PLAY/PAUSE to begin or pause play, and STOP

to stop play.

Select a specific disc by pressing DISC 1 - DISC 5.

Press SKIP FORWARD / BACKWARD

to select a specific track.

Play and load simultaneously by:

1. Press OPEN/CLOSE to open the tray while a CD is

playing

2. Load/change discs for available trays by pressing

DISC SKIP.

3. Press OPEN/CLOSE to close the tray.

Shuffling the Play Order

Press SHUFFLE to turn on/off the playing of tracks in

random order. (Remote Only)

Sampling Tracks

Press INTRO to play the first 10 seconds of each track

on the current disc, all discs in the tray, or turn INTRO

mode off. (Remote Only)

(Note: You may also press REPEAT to select 1 disc or

all discs before activating INTRO & SHUFFLE func-

tions)

5 DISC CHANGER

DIGITALAUDIO SYSTEM

SIMULTANEOUS PLAY AND LOAD SYSTEM

COMPACTDISC AUDIO

CD-RWCOMPATIBLE

Using Preset Equalizer Curves

Press ROCK/CLASSIC, CUSTOM/FLAT, POP/JAZZ on the

main unit or EQ on the remote to toggle among

FLAT, ROCK, JAZZ, POP, CLASSICAL & CUSTOM. The

display shows briefly the selection.

Creating a Custom Curve

1. Press CUSTOM/FLAT to select CUSTOM mode.

2. While "CUSTOM" is displayed, press SKIP FOR-

WARD / BACKWARD to cycle

among displayed bass-, and treble - range levels.

3. While BAS or TRE is dis-

played, adjust VOLUME

to set the associated gain

between -10 - +10.

Boosting the bass

Press Bass Boost to turn on/off boosting the bass

frequency.

Muting Audio

Press MUTE on the

remote to cut the sound. (Remote Only)

X-Surround

Press X-SURROUND to enjoy enriched sound quality.

This feature gives you:

1. Better width and depth for vocal and instrumental

sound.

2. More powerful presence for studio recording.

3. Enhanced surround effects with greater flexibility

in positioning speakers.

Tip: While playing a CD, press

and hold SKIP-FORWARD or

BACKWARD for more than 2 sec-

onds to search through the CD.

TRE+08

MUTE

Sound Features

RS2606EA 7/16/02 5:30 PM Page 10

Table des matières

Autres manuels RCA Intervenants

RCA

RCA SP1420 Manuel du propriétaire

RCA

RCA PRO-X44AV Manuel utilisateur

RCA

RCA RTS635 Manuel utilisateur

RCA

RCA Two-Way Bookshelf Speaker Manuel utilisateur

RCA

RCA PRO-LS200 Manuel utilisateur

RCA

RCA RS2001 Manuel utilisateur

RCA

RCA RTS7131B Manuel utilisateur

RCA

RCA RTS635 Manuel utilisateur

RCA

RCA WSP250 Manuel utilisateur

RCA

RCA LC-1A Manuel utilisateur

RCA

RCA PRO-X55AV Manuel utilisateur

RCA

RCA PRO-X33AV Manuel utilisateur

RCA

RCA PRO-LS100 Manuel utilisateur

RCA

RCA WSP200 Manuel utilisateur

RCA

RCA Digital Satellite Receiver Manuel utilisateur

RCA

RCA ras2866b2 Manuel utilisateur

RCA

RCA j1000 Manuel utilisateur

RCA

RCA WPBT1 Manuel utilisateur

RCA

RCA PRO LX5 II Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
