RCA RLC2226 Manuel utilisateur

RLC2226

Incaseofsmoke,strangenoiseorstrangesmell

fromtheunit:

Turnoffthepowerswitchimmediately;

Disconnectthepowerplugfromthepoweroutlet;

Contact yourdealerorservicecentre.Never

attempt tomakerepairsyourself becausethis

couldbedangerous.

High Voltage

Donot open

Risk of electronicshock,donotopen.

Donotattempttoservicethisproductyourself

asopeningorremoving coversmayexpose

youtodangerousvoltage orotherhazards.

Referallservicingtoqualifiedservicepersonnel.

CAUTION

ImportantSafetyInstructions

ImportantSafetyInstructionsandMaintenance

Neverpushobjectsofanykindintotheset

throughthecabinetslotsastheymaytouch

dangerousvoltagepointsorshort-circuitpartsthat

couldresultinafireorelectricshock.Neverspill

liquidof anykindontheset. Usespecialcaution

inhouseholdswherechildrenarepresent.The

apparatusisnotsuitableforchildrenunder3-year

tooperate.

Thisproductisequippedwithapolarizedplug(aplug

havingonebladewiderthantheother).

Thisplugwillfit intothepoweroutletonlyoneway,

thisisaSafetyfeature.If youareunabletoinsert the

plugfullyintotheoutlet, trytoreversetheplugandif

theplugshouldstillfailtofit, contact yourelectrical

techniciantoreplaceyourobsoleteoutlet.

Donotdefectthesafetypurposeof thepolarizedplug.

Powersupplycordsshouldberoutedsafetyto

preventlifeandpropertyfromdangerouswith

damagedcord.

Mainsplugisusedasthedisconnect device. It

shallremainreadilyoperableandshouldnotbe

obstructedduringintendeduse. Tobe completely

disconnected theapparatusfromsupplymains, the

mainsplugoftheapparatusshall bedisconnected.

Toreducetheriskoffireorelectricshock, donot

exposethisproduct torainormoisture.

Theapparatusshallnotbeexposedtodripping

orsplashingandnoobjectsfilledwithliquids,

suchasvases,shall beplacedontheapparatus.

ImportantSafetyInstructionsandMaintenance

ImportantSafetyInstructions

Always turntheset offwhen itisnotbeingused.

Unplugtheapparatusfromthe ACoutlet whenit will

notbeusedforalongperiodoftime.Andwhenthere

isalightning,unplugtheunit fromtheACoutlet

immediately.Nevertouchtheantennawireduring

lightning.

Anoutsideantennasystemshouldnotbelocatedin

thevicinityof overheadpowerlinesorotherelectric

light orpowercircuits,orwhereitcan fall intosuch

powerlinesorcircuits. Wheninstallinganoutside

antenna system,extremecareshouldbe takentokeep

fromtouchingsuchpowerlinesorcircuitsascontact

withthemmightbefatal.

Installation

Theventilation should not beimpededbycovering the

ventilationopeningwithitems, suchasnewspapers,

tablecloths,curtains, etc.

Atleast10cmspaceshouldbe left aroundthe

apparatusforsufficient ventilation.

Theproduct shouldbesituatedawayfromheat

sourcessuchasradiators,heat registers,stoves,or

otherproducts(includingamplifiers)thatproduceheat.

Placetheapparatusinsuchapositionthatthescreen

isnotexposedtodirect sunlight.It isbest tohavesoft

indirectlightingwhilewatchingand avoidcomplete

darkenvironmentandreflectionfromthescreenas

thesemaycauseeyefatigue.

Keepthe product awayfromhighmagneticfield(i.e.

power-amplified powerspeaker)toavoidaffectingthe

tint;

Donotpull theplugout bythewire;

Nevertouchthe plugwithwethands.

Excessivesoundpressurefromearphonesand

headphonescancausehearingloss.

Toavoidthefire,nonakedflamesource,

suchaslightedcandles, shouldbe

placedontheapparatus.

ImportantSafetyInstructionsandMaintenance

Installation

Donotplacethisapparatusnearwater, forexample,

nearabathtub,washbowl, kitchen sink,orlaundry

tub;inawet basement;oraswimmingpool;and

thelike;

Cleaning

WhentheTVbeingmovedinfromcoldplace, it needs

somerighttimefordewinsideunitevaporatingfully

beforeturnontheunit;

UnplugthisapparatusfromtheACoutletbefore

cleaning.Donot useliquidcleanersoraerosol

cleaners.Useadampclothforcleaning;

Donotplacethesetonanunstable cart,stand, table

orshelf.Thesetmayfall, causingseriouspersonal

injuryaswellasdamagetotheproduct.Useonlywith

thecart, stand,tripod,bracket, ortablespecifiedby

themanufacturer,orsoldwiththeapparatus.An

applianceandcartcombination shouldbemovedwith

care. Quick stops, excessiveforce,anduneven

surfacesmaycausetheapplianceandcart

combinationtooverturn.

Topreventinjury,thisapparatusmustbesecurely

attachedtothefloor/wall inaccordancewiththe

installation instructions.

Move

Foryourprotection, pleasereadthisinstructioncompletely,andkeep thismanualfor

futurereference.

Generaldescription 5

Specificationsandaccessories 6

Overview 7

Basicoperation 10

Externalconnection 12

Basicoperation 14

Troubleshooting 23

Picturedefectsand countermeasures 24

Basicoperation

Contents

Generaldescription

Feature:

lZeroXradiationcompliestogreen environmentprotectionrequirement

lAutotuningandfinetuning

lOnecompositevideo inputsockets(back)

lOneS-Video input socket

lOnePCVGAinputsocket

lOne YPbPr inputsocket

lOneHDMI inputsocket(HDMI1.3)

lOne AVoutputsocket

lHeadphone

lMulti-languageOSD

lProgrammableTVsleeptimer

lNo-signalautomaticpowerofffunction

lPCVGAmode: VGA,SVGA, XGA

lYPbPrmode:480i,480P, 576P, 720P,1080i,1080P

lHDMImode:480P,576P,720P,1080i,1080P

Note:

1. Incaseofanydesign change,anoticewillnotbe released.

2.ThecompositevideooutputfunctiononlysupportTVand AVinput.

Specification

Specifications:

Accessories:

l User smanual l Remotecontrol

l Wall-mountedaccessories:Two wall-mountedbrackets,fourfixedscrews

andfourfixed sleeves.(Optional)

Note:

1.DuetoTVmaybeusedwithdifferent displayscreen,weightmarkedinthis

user'smanual orinpackaging boxaresubjecttochangewithoutnotice.

2.The illustrationsandon-screendisplaysinthisusersmanualarefor

explanationpurposesandmayvaryslightlyfromactualoperations.Incaseof

anydesignchange,anoticewillnot bereleased.

Specificationsandaccessories

1366X768

2WX2

50W

AC~120V60Hz

Description RLC2226

Dimensions

(LXWXH) TVwithstand

TVwithoutstand

530209393XXmm

53077XXmm359

TVwithstand

TVwithoutstand

4.6Kg

5.0 Kg

22Diagonal(max.)

Overview

1. Power indicator

Green: Normalplayingstatus.

Red:Standbystatus.

2. IRremotesensor

Pointremotecontrolatthissensorto

conductremotecontrol.

4. MENU

Pressthisbutton todisplayOSDmenu.

3. INPUT

Pressthisbutton todisplaythe selectable

signalsourcefor mainsource.

Pressthisbutton toenterstandbymode

undernormalplay,andpressthisbutton

toenternormalplaymode understandby

mode.

5. PROG /

Pressthesetwobuttonstoselectchannel

or operatemenu.

6. VOL/

Pressthesetwobuttonstoincreaseor

decreasethe volumeoroperatemenu.

1.Powerindicator

2.IRremotesensor

Overview

AVAUDIOOUT

Audioout forexternal devices.

AVVIDEOOUT

Videooutforexternaldevices.

YPb/CbPr/Cr

ConnecttoYPbPr/YCbCrvideo.

Overview

Remotecontrol

Loading batteries:

1) Remove thelidofthebatterycompartment.

2) Insert 2sizeAAAbatterieswithpolarities as indicatedinside thecompartment.

3) Replacethelid.

Note:

1) Oneloading ofbatteries willlast1yearundernormaluse.

2) If youdon tintendtousetheremotecontrolforalong period oftime, remove

themtoavoiddamageduetoleakage.

3) Donotmixoldandnewbatteries,ordifferent types.

4) Don t throwthe batteriesintofireor water.

5) The batteries(batterypackorbatteriesinstalled)shallnotbe exposed toexces-

siveheatsuch assunshine,fireorthe like.
