Your ANT2050X antenna comes with a switchable amplifier which is

designed to operate over a wide range of signal strengths. The default

setting is the DX (distance setting) which is set at the factory and

allows maximum amplifier gain. Normally there will be no need to

change this setting to the LOC (Local) position, however if the

television picture is snowy, or has diagonal lines that appear to move,

or has poor reception on some UHF channels, even though the

signal is known to be adequate in the area for the affected station.

These conditions can sometimes be the result of too much signal at

the amplifier input and can often be remedied by switching to the

LOC setting.

In cases where there is a desire to experiment with the picture

quality, the switch should be changed from the preset DX setting to

the LOC setting.

To change the switch setting, remove the rubber plug and move the

switch with your finger to the desired setting (see diagram K).

Some or Most Channels Are Poorly Received: Loosen the 2 bolts

on the “L” shaped pipe where it meets the straight pipe. Next, slight-

ly rotate the antenna’s upper assembly, then check TV picture. Repeat

process until the best picture is achieved, then retighten the 2 bolts

on the “L” pipe. In extreme cases, the upper assembly of the antenna

can be removed from the “L” pipe and rotated 180 degrees before

replacing assembly in “L” pipe. Then the above rotating procedure is

repeated as described above. Another option is to move the

ANT2050X to a different place, such as another side of the house or

to a higher location. Obstructions such as trees, other houses and

mountain sides between the antenna and TV transmitters normally

impair reception. Generally, best results occur when the antenna is

mounted at the highest available point.

Picture Has Ghosting (Shadows or Double-images): Check to

make sure that none of the coaxial cables have any sharp bends or

kinks in them (a common cause of ghosting). If ghosting persists,

check entire system connections for tightness. Also, make sure anten-

na is not positioned near the house's electric supply lines on the roof

or in the attic. It is recommended that the antenna be repositioned in

cases where the problem persists. When ghosting cannot be elimi-

nated, consult with a TV or electronics repair shop.

TROUBLESHOOTING

Thomson Consumer Electronics will replace this antenna if found to

be defective in materials or workmanship. Return it postage prepaid

to the address below for prompt, no change replacement with a cur-

rent equivalent antenna.

This replacement is TCE’s sole obligation under this warranty. TCE

will not be responsible for any incidental or consequential damages,

or for any loss arising in connection with the use or inability to use

this product.

This warranty gives you specific legal rights, and you may also have

other rights which vary from State to State.

Product Exchange Center

11721 Alameda Ave.

Socorro, Texas, 79927

ONE YEAR LIMITED WARRANTY

Dish Diameter: 11.6"

Dipole Length: 35.9"

Height: Adjustable

Included Accessories: 2 - 7 ft. RG-6 weather resistant cables,

2 - Diplexers

Frequency Range: 54-800 MHz

Current: Less than 50mA

Voltage: 10-21 VDC

Gain: 12 dB

IP3: +28 dBm

Loss DBS: Max: 1.1 dB at 975 MHz Typical: 0.7 dB

DBS Attenuation: Max: 62 dB at 975 MHz Typical: 38 dB

Noise Figure: Typical 3.0 dB

Other: Integral High Pass Interference Filter

Box Dimensions: 23 7/8" x 15 7/8" x 3 1/8"

Unit Weight: 6.5 lbs.

SPECIFICATIONS

Removable

Rubber Cover Preset

Position

Switch to Desired

Position with

Finger

Return the

Rubber Cover

When Finished

ANT2050X

Omni-Directional

DBS Off-Air Antenna

Direct

Broadcast

Satellite

WARNING!

USE EXTREME CAUTION WHEN INSTALLING AN

OUTDOOR ANTENNA CLOSE TO OVERHEAD WIRES.

IF THE ANTENNA STARTS TO FALL, LET IT GO! IF

ANY PART OF THE ANTENNA MAKES CONTACT

WITH OVERHEAD POWER LINES, TOUCHING THE

ANTENNA, MAST, CABLE OR GUY WIRES CAN CAUSE

ELECTROCUTION AND DEATH. CALL THE POWER

COMPANY TO REMOVE THE ANTENNA. DO NOT

ATTEMPT TO REMOVE IT YOURSELF.

IMPORTANT SAFETY PRECAUTIONS:

Please read and follow these important safety precautions:

• Be sure to select an antenna site well away from any

overhead wires.

• Do not try to guess which overhead wires carry high voltage.

• Always check with the power company whenever

overhead wires are involved.

• If you notice anything making contact with the overhead wires,

call the power company to have the item removed properly.

• Do not run the downlead cable over power wires.

• If there is any doubt of clearing overhead wires, only a

qualified professional should remove an old antenna.

• Never install the antenna outdoors in windy conditions.

• Make sure the antenna downlead cable is connected to

suitable lightning arresters if antenna is not mounted on

the DBS Antenna.

• Make sure the antenna installation is secure.

LIGHTNING PROTECTION:

When ANT2050X is not mounted on the pole of the DBS

antenna, a copper ground wire (not included) should be

installed from the “To TV” F connector on antenna to a

grounding block (not included). This grounding block

should be as close as possible to where the down lead

enters the house.

CAUTION
