Razer BLACKSHARK V2 Manuel utilisateur
FOR GAMERS . BY GAMERS .™
1
If esports is everything, give it your all with the Razer BlackShark V2.
Introducing a triple threat of amazing audio, superior mic clarity, and
supreme sound isolation. Fitted with titanium-coated drivers, a USB sound
card, softer ear cushions and THX Spatial Audio, your time to turn pro is
now.
FOR GAMERS . BY GAMERS .™
2
CONTENTS
1. WHAT’S INSIDE / WHAT’S NEEDED........................................................................................................3
2. LET’S GET YOU COVERED .......................................................................................................................5
3. TECHNICAL SPECIFICATIONS ..................................................................................................................6
4. CONNECTING THE HEADSET ..................................................................................................................7
5. USING THE RAZER BLACKSHARK V2 .......................................................................................................9
6. CONFIGURING YOUR RAZER USB SOUND CARD..................................................................................12
7. SAFETY AND MAINTENANCE................................................................................................................26
8. LEGALESE..............................................................................................................................................27
FOR GAMERS . BY GAMERS .™
3
1. WHAT’S INSIDE / WHAT’S NEEDED
WHAT’S INSIDE
▪Razer BlackShark V2
A. Adjustable padded headband
B. Ultra-soft memory foam ear
cushions
C. 3.5 mm audio + mic jack
D. Volume control knob
E. Mic mute button
▪Removable RazerTM HyperClear cardioid mic
▪USB sound card
▪Important Product Information Guide
FOR GAMERS . BY GAMERS .™
4
WHAT’S NEEDED
PRODUCT REQUIREMENTS
▪Devices with a free USB port
▪Devices with 3.5 mm audio + mic combined jack*
RAZER SYNAPSE REQUIREMENTS
▪Windows® 10 64-bit (or higher)
▪Internet connection for software installation
*Compatible with PC / Mac / Switch / PS4 / Xbox One (Xbox One Stereo Adapter may be required,
purchased separately).
FOR GAMERS . BY GAMERS .™
5
2. LET’S GET YOU COVERED
You’ve got a great device in your hands, complete with a 2-year limited warranty coverage. Now
maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com
Got a question? Ask the Razer Support Team at support.razer.com
Your product’s serial
number can be found here.
FOR GAMERS . BY GAMERS .™
6
3. TECHNICAL SPECIFICATIONS
HEADPHONES
▪Frequency response: 12 Hz - 28 KHz
▪Impedance: 32 Ω @ 1 KHz
▪Sensitivity (@1kHz): 100 dB SPL / mW,1KHz
▪Drivers: Customized Dynamic 50 mm Driver
▪Inner ear cup diameter: 65 mm x 40 mm / 2.56 in x 1.57 in
▪Connection type: 3.5 mm with USB sound card
▪Cable length: 1.8 m / 5.91 ft
▪Approx. weight: 262 g / 0.6 lbs
▪Oval ear cushions: Breathable memory foam cushions
MICROPHONE
▪Frequency response: 100Hz - 10KHz
▪Signal-to-noise ratio: 60 dB
▪Sensitivity (@1kHz) -42 dB V/Pa,1KHz
▪Pick-up pattern: Unidirectional
▪Mute Function: Click-to-mute
FOR GAMERS . BY GAMERS .™
7
4. CONNECTING THE HEADSET
TO YOUR PC VIA USB PORT
1. Plug your headset to the USB Sound Card, and then to your PC.
2. On your PC, right-click on the sound icon on the system tray, and then select Open Sound
settings.
FOR GAMERS . BY GAMERS .™
8
3. On the Sounds window, set Razer USB Sound Card as the default Output and Input device.
TO OTHER DEVICES VIA USB PORT
Plug your Razer BlackShark V2 to the Razer USB Sound Card*, and then to your device. Make sure the
Razer USB Sound Card is set as the default input and output device.
*Compatible with PC / Mac / Switch / PS4.
TO DEVICES VIA 3.5MM COMBO PORT
If your device has a 3.5mm audio + mic combined port, simply plug the 3.5mm audio + mic connector
from your headset to your device’s audio port.
FOR GAMERS . BY GAMERS .™
9
5. USING THE RAZER BLACKSHARK V2
USING THE MICROPHONE
Plug the Razer™HyperClear Cardioid Mic to the headphone, then bend until it is parallel to your
mouth. Make sure the mic diaphragm is in front and the air vent is facing away from your mouth.
MUTING / UNMUTING THE MICROPHONE
Press the mic mute button to mute or unmute the microphone.
Mic diaphragm
Air vent
