Raymarine ST40 Guide de l'utilisateur
Distributed by
Any reference to Raytheon or
RTN in this manual should be
interpreted as Raymarine.
The names Raytheon and RTN
are owned by the
Raytheon Company.
ST40 Compass
Instrument
Owner’s
Handbook
Document number: 81161_2
Date: 1st May 2001
161_2cov.p65 01/05/01, 16:501
Copyright © Raymarine Limited 2001
161_2cov.p65 01/05/01, 16:502
Preface i
Important information
WARNING
Although your ST40 instrument is designed to give accurate and
reliable performance, it should serve only as an aid to navigation
and should never lead to the erosion of good seamanship. Always
maintain a permanent watch and be aware of situations as they
develop.
EMC conformance
All Raymarine equipment and accessories are designed to the best
industry standards for use in the leisure marine environment.
The design and manufacture of Raymarine equipment and accessories
conform to the appropriate Electromagnetic Compatibility (EMC)
standards, but correct installation is required to ensure that performance
is not compromised.
Handbook information
To the best of our knowledge, the information in this handbook was
correct when it went to press. However, the Raymarine policy of
continuous product improvement may change product specifications
without notice. Consequently, unavoidable differences may occur
between the product and the handbook from time to time, for which
Raymarine cannot accept liability.
161_2pre.p65 01/05/01, 16:501
ii ST40 Compass Instrument Owner’s Handbook
161_2pre.p65 01/05/01, 16:502
Preface iii
Contents
Important information .......................................................... i
WARNING ......................................................................... i
EMC conformance ............................................................. i
Handbook information ....................................................... i
Preface..................................................................................... v
Parts supplied ................................................................... vi
Chapter 1: Operation ............................................................. 1
1.1 Introduction ................................................................. 1
1.2 Operating procedures .................................................. 1
Silencing alarms .......................................................... 1
Backlighting and contrast adjustment ......................... 3
Compass heading screen ............................................. 4
Locked heading screen ................................................ 4
1.4 Alarms ......................................................................... 5
Off course active alarm ............................................... 5
Enabling/disabling alarm ....................................... 5
Man overboard alarm (repeated) ................................. 5
Chapter 2: Maintenance and Fault Finding ........................ 7
2.1 Maintenance ................................................................ 7
Servicing and safety .................................................... 7
Instrument .................................................................... 8
Transducer ................................................................... 8
Cabling ........................................................................ 8
2.2 Fault finding ................................................................ 8
Preliminary procedures ............................................... 8
Fixing faults ................................................................. 8
Assistance .................................................................. 10
161_2pre.p65 01/05/01, 16:503
iv ST40 Compass Instrument Owner’s Handbook
Chapter 3: Installation......................................................... 11
3.1 Planning your installation ......................................... 11
EMC installation guidelines ...................................... 11
Suppression Ferrites ........................................... 12
Connections to Other Equipment ......................... 12
Tools required ........................................................... 12
Site requirements ....................................................... 13
Fluxgate Compass transducer .............................. 13
Instrument ............................................................ 14
3.2 Procedures................................................................. 15
Fitting Fluxgate Compass transducer ........................ 15
Introduction ......................................................... 15
Stand alone instrument ................................... 15
System requirements ...................................... 15
Installation ........................................................... 15
Running transducer cable .................................... 16
Connections to the instrument ................................... 17
Stand-alone connections ...................................... 18
SeaTalk connections ............................................ 19
Fitting the instrument................................................. 19
Desktop Mounting Bracket .................................. 21
3.3 Calibration requirement ............................................ 22
Chapter 4: Calibration ......................................................... 23
4.1 Introduction ............................................................... 23
EMC conformance .................................................... 23
4.2 User calibration ......................................................... 23
4.4 Dealer calibration ...................................................... 25
Instrument Specification .................................................... 27
Glossary ................................................................................. 29
Index ...................................................................................... 31
161_2pre.p65 01/05/01, 16:504
Preface v
Preface
Thank you for purchasing a Raymarine product. We are sure your
ST40 instrument will give you many years of trouble-free operation.
This instrument is designed to provide reliable performance, even
under the most demanding conditions.
D4809-2
161_2pre.p65 01/05/01, 16:505
vi ST40 Compass Instrument Owner’s Handbook
Parts supplied
Fluxgate compass transducer
D4771-2
ST40
Compass
Instrument
Owner's
Handbook
Worldwide
Distributors
ST40 Compass instrument
Fixing
stud
Thumb
nut
Gasket
1 m (3 ft) power cable
Instrument Cover
Owner’s Handbook.
Warranty document and fitting
templates included in Handbook
Worldwide Service Centre
Handbook.
Quick Reference Guide
Clamping bracket
COMPASS
ST40
Note:
The items shown here are supplied for an ST40 Compass system. If an instrument is purchased separately, a transducer
is not included. If any item is not present, contact your Raymarine Dealer.
Adjusting display backlighting/contrast
Normal operation
ST40 Compass Instrument - quick reference guide
orTo exit adjust mode press or wait for 5 second timeout
LEVEL 1 LEVEL 1
OFF LEVEL 2LEVEL 3LEVEL 2
To enter adjust mode,press for 1 second to adjust BACKLIGHTING and a further 1 second to adjust CONTRAST
SWITCH ON
Compass
heading
3 seconds
Set
alarm
level
Alarm on/off
Times out to the
Compass heading
screen after
5 seconds.
Off course
alarm
values
Locked
heading
Auto locked
heading
Course computer
sets auto lock
Course computer
sets auto lock
+
-
Momentary
With Set alarm level screen displayed,
to save the alarm level and return to
normal operation.
and keys simultaneously
press the
161_2pre.p65 01/05/01, 16:506
Chapter 1: Operation 1
Chapter 1: Operation
1.1 Introduction
Your ST40 Compass instrument:
• Provides true and magnetic bearing information.
• Enables a locked bearing to be defined either manually, or
automatically by a course computer. In this mode, the instrument
shows the deviations from the locked bearing and the direction to
steer to achieve the locked bearing.
CAUTION
Your instrument is calibrated to factory (default) settings when
first supplied and must therefore be calibrated before use, to
ensure optimum performance on your vessel. Do NOT use the
instrument until the calibration procedures have been
satisfactorily completed, using the procedures in Chapter 4,
Calibration.
Coloured bezel and Desktop Mounting Bracket options are available
for your ST40 instrument. Contact your Raymarine dealer for further
information.
1.2 Operating procedures
Operating information is presented in flow chart form. The flow charts
show the various operating screens and key presses necessary to carry
out the various instrument functions. Key presses are momentary unless
otherwise stated.
Silencing alarms
To silence an alarm (see the Alarms section, later in this chapter),
momentarily press any one of the instrument keys.
161_2c01.p65 01/05/01, 16:511
